Tiger 800XC (continued)
15 16
30 29
15.Rear light
16.Rear brake fluid reservoir
17. Oil filler cap
18.Handguards
19.Mirror
20.Headlight adjuster
21. Screen
22.Coolant expansion tank
23.Front fork
18
17 19 20
28
27 26 25
24.Clutch cable
25.Engine oil level sight glass
26.Rear brake pedal
27.Rear suspension pre-load adjuster
28.Rear suspension rebound damping
adjuster
29.Rear brake caliper
30.Rear brake disc
Parts Identification
