Parts Identification
Tiger 800XC
1
2
14
13
1. Headlight
2. Front indicator
3. Electrical accessory socket
4. Fuel tank and fuel filler cap
5. Battery and fuse boxes
6. Tool kit/Accessory U-lock storage
location
7. Seat lock
14
3
4
5
12
11
8. Rear wheel adjuster
9. Drive chain
10.Side stand
11. Gear-change pedal
12.Radiator/Coolant pressure cap
13.Front brake caliper
14.Front brake disc
6
7
10 9
8
