Fuse Identification

A blown fuse is indicated when all of the
systems protected by that fuse become
inoperative. When checking for a blown fuse,
use the tables to establish which fuse has
blown.
1
OPEN
6 EMPTY
5 15A
ACC
4
10A
3 10A
2
15A
1 15A
cebw
1. Front fuse box cover
2. Front fuse box
3. Spare fuses
Front fuse box
Circuit Protected Position
Cooling fan
Accessory lights
Auxiliary lighting
Heated Grips
Accessory sockets
Not used
Maintenance and Adjustment
The fuse identification numbers listed in the
tables correspond with those printed on the
fuse box covers, as shown below. Spare fuses
are located at right angles to the main fuses
and should be replaced if used.
2 4
15
10
3
10
15
15
Front of Motorcycle
4. Rear fuse box
5. Rear fuse box cover
Rear fuse box
Rating Circuit Protected
(Amps)
1 15
2 15
3 10 Alarm, instruments, ECM
4 10 Engine management
5 15 Alarm, diagnostic connector,
instruments
6 -
Dip and main beam
headlights, starter relay
5
Position Rating
(Amps)
ABS 1 20
ABS 2 20
3 10
4 20
5
6 15
5
