Alliance Laundry Systems HX18PVQM6 Operation & Maintenance Manual
Alliance laundry systems washer-extractors cabinet freestanding operation/maintenance
Hide thumbs
Also See for HX18PVQM6:
- Service manual (78 pages) ,
- Programming manual (63 pages) ,
- Installation manual (57 pages)
Table of Contents
Advertisement
Washer-Extractors
NOTA: Para bajar una
copia de estas instrucciones
en español, visite
www.comlaundry.com.
Keep These Instructions for Future Reference.
(If this machine changes ownership, this manual must accompany machine.)
Cabinet Freestanding
Refer to Page 2 for Model Identification
www.comlaundry.com
CFD13C
Part No. 9001001R6
September 2008
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Alliance Laundry Systems HX18PVQM6
Summary of Contents for Alliance Laundry Systems HX18PVQM6
- Page 1 Washer-Extractors NOTA: Para bajar una copia de estas instrucciones en español, visite www.comlaundry.com. Keep These Instructions for Future Reference. (If this machine changes ownership, this manual must accompany machine.) Cabinet Freestanding Refer to Page 2 for Model Identification www.comlaundry.com CFD13C Part No.
-
Page 3: Table Of Contents
All rights reserved. No part of the contents of this book may be reproduced or transmitted in any form or by any means without the expressed written consent of the publisher. 9001001 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Introduction... Model Identification ... -
Page 4: Model Identification
SX25PVQM7 HX25PVXM6 SX25PVXM6 HX25PVXM7 SX25PVXM7 HX35PVQM6 SX35PVNM7 HX35PVQM7 SX35PVQM6 HX35PVXM6 SX35PVQM7 HX35PVXM7 SX35PVXM6 SX35PVXM7 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Introduction UX18PVNA6 HX18PVQU6 UX18PVNA7 HX18PVXU6 UX18PVPA6 UX18PVPA7 UX18PVQA6 UX18PVQA7 UX18PVQM6 UX18PVQM7 UX18PVXA6 UX18PVXA7 UX18PVXM6... - Page 5 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001 continued HX55PVNU6 SX55PVNU6 HX55PVNU7 SX55PVNU7 HX55PVQU6 SX55PVPU6 HX55PVQU7 SX55PVPU7 HX55PVXU6 SX55PVQU6 HX55PVXU7 SX55PVQU7 SX55PVXU6 SX55PVXU7 HX75PVNU6 SX75PVNU6 HX75PVNU7 SX75PVNU7 HX75PVQU6 SX75PVQU6 HX75PVQU7 SX75PVQU7 HX100PVNU6 SX100PVNU6 HX100PVNU7 SX100PVNU7...
-
Page 6: Nameplate Location
Nameplate Figure 1 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Replacement Parts If literature or replacement parts are required, contact the source from which the machine was purchased or... - Page 7 Electrical Characteristics Design Series Option Identification (varies from machine to machine) 0001 * Denotes Brand 50 60 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001 Model Number Familiarization Guide Sample Model Number: *X55PVXM60001 X55PVXM60001 2/3+PE...
-
Page 8: Safety Information
NOTE: The word “NOTE” is used to communicate installation, operation, maintenance or servicing information that is important but not hazard related. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Safety Information Important Safety Instructions To reduce the risk of fire, electric shock,... - Page 9 If this occurs, have washer checked by a qualified service person. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001 20. If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or its service agent.
-
Page 10: Safety Decals
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Be careful around the open door, particularly when loading from a level below the door. Impact with door edges can cause personal injury. -
Page 11: Operator Safety
Excessively high water level is evident. c. Machine is not connected to a properly grounded circuit. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001 Do not bypass any safety devices in the machine. Never operate the machine with a bypassed or disconnected balance system. -
Page 12: Preliminary Information
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Power Failure Recovery If a cycle is in process and the power fails, cycle status is saved in memory without power being applied. -
Page 13: Control Identification
Control Identification Keypad Display Emergency Stop Button © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001 Figure 3 Preliminary Information Key Switch Serial Port M172... -
Page 14: Operation
2. Load the drum to the specified capacity. 3. Close the door by pushing the door handle towards the machine. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Operation For 100 - 165 models: 1. Push on the doorlock system to open the door. -
Page 15: Start A Program
Please close door Restaurant 2 S01 C23 0:04:59 80°F High © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001 After powering up the control, “Cycle 00” will show on the display. Press the desired program number (example: program 23). -
Page 16: Special Options In Run Mode
Level : 2.5 cm 62°F 40rpm L S01 C23 0:04:59 80°F High © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT While the machine is running press the “Display Temp” button. Level: 2.5 cm: Water level in the bath. If the machine is filling with water this value will increase. -
Page 17: Stop The Machine
10.2 cm Coast down Please open door Done Cycle 23 © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001 Press the “Stop” button. If there is water in the machine the display will show “Waterlevel xx.x cm” while the machine is draining the water. -
Page 18: Error Messages
(CC = cycle number; N = step number in which the alarm occurred). © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Door Error If the door is closed after start the control will try to lock the door. If the door will not lock “Door error”... - Page 19 During step N (CC = cycle number; N = step number in which the alarm occurred). © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001 Fill Alarm (Continued) Possible Faults: Wiring is not connected properly to the inlet ●...
- Page 20 Speed detection error © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT If there was a problem during heating in a step at the end of the program, the control will show “Temperature sensor error”. The temperature was never reached in this cycle.
-
Page 21: Maintenance
When possible, space is provided on the checklists for this purpose. The following maintenance procedures must be performed regularly at the required intervals. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001 Maintenance Daily Beginning of the day 1. -
Page 22: Weekly
7. Check the alignment of the out-of-balance switch to make sure it is centered in the tilt detector plate cut-out. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Weekly 1. Check the machine for leaks. a. Start an unloaded cycle to fill the machine. -
Page 23: Yearly
10. If necessary, tighten the bearing housing’s mounting bolts. 11. If necessary, tighten the shock absorber’s mounting bolts. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001 Yearly 1. Replace the automatic lubricator (only for 75- 100-135-165 machine). -
Page 24: Daily Preventive Maintenance Checklist
NOTE: Unload the machine promptly after each completed cycle to prevent moisture buildup. NOTE: Leave loading door open after each completed cycle to allow moisture to evaporate. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Checks... -
Page 25: Weekly Preventive Maintenance Checklist
Start an unloaded cycle to fill the machine. b. Verify that door and door gasket do not leak. c. Verify that the drain valve is operating. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001 Checks... -
Page 26: Monthly Preventive Maintenance Checklist
9. Verify that insulation is intact on all external wires and that all connections are secure. 10. If necessary, tighten the bearing housing’s mounting bolts. 11. If necessary, tighten the shock absorber’s mounting bolts. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT Checks Observe All Safety Warnings! Month... -
Page 27: Yearly Preventive Maintenance Checklist
1. Replace the automatic lubricator (only for 75-100-135-165 machines). 2. Check if the machine is working properly. If you see or hear any abnormal function on the machine call a service technician. © Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT 9001001 Checks...
