Perfect Flame Ultimate PF30LP Owner's Manual

4-burner lp gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

WARNING
Improper installation, adjustment,
alteration, service or maintenance
can cause injury or property
damage.
Read the installation, operation and
maintenance instructions thoroughly
before installing or servicing this
equipment.
DANGER
Failure to follow these
insructions could result in fire
or explosion that could cause
property damage, personal injury
or death.
DANGER
DO NOT use gas grill for indoor
cooking or heating. TOXIC fumes
can accumulate and cause
asphyxiation. DO NOT use in or
on boats or recreational vehicles.
PROP 65 WARNING
Chemicals known to the state of
California to cause cancer, birth
defects or other reproductive
harm are created by the
combustion of propane.
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only
(Outside any enclosure)
4-Burner LP Gas Grill
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE. IF YOU ARE ASSEMBLING THIS UNIT
FOR SOMEONE ELSE, GIVE THIS MANUAL TO HIM
OR HER TO SAVE FOR FUTURE REFERENCE.
FOR CUSTOMER SERVICE, EMAIL TO
SALESHELP@SUREHEAT.COM OR
CALL 1-800-229-5647 (TOLL-FREE) BETWEEN
8:00 AM AND 5:00 PM EASTERN TIME, MONDAY
THROUGH FRIDAY
PF30LP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultimate PF30LP and is the answer not in the manual?

Questions and answers

Related Manuals for Perfect Flame Ultimate PF30LP

Summary of Contents for Perfect Flame Ultimate PF30LP

  • Page 1 DO NOT use gas grill for indoor cooking or heating. TOXIC fumes can accumulate and cause asphyxiation. DO NOT use in or on boats or recreational vehicles. PF30LP PROP 65 WARNING Chemicals known to the state of California to cause cancer, birth defects or other reproductive harm are created by the combustion of propane.

  • Page 2: Grill Operation

    Always read and understand the WARNINGS and INSTRUCTION that are contained in this manual before attempting to use this gas barbecue grill, to prevent possible bodily injury or property damage. Always keep this manual for convenient future reference. PF30LP Owner's Manual...

  • Page 3: Table Of Contents

    For Your Safety....................4 Grill Features......................6 Getting Started.....................7 Grill Assembly......................8 Grill Location......................12 Gas Requirements....................13 Pre Operation Leak Testing................15 Lighting the Grill....................16 Using the Rotisserie Burner................17 Rotisserie Lighting.....................18 Grill Light Maintenance..................19 Care and Maintenance..................20 Troubleshooting Guide..................22 Warranty Information..................24 PF30LP Owner's Manual...

  • Page 4: For Your Safety

    4. Move gas hoses as far away as possible from hot surfaces and dripping hot grease. 5. Never keep a filled gas container in a hot car or car trunk. Heat will cause the gas pressure to increase, which could open the relief valve and allow gas to escape. PF30LP Owner's Manual...
  • Page 5 G E N E R A L IN F O R M A T IO N 1. A propane gas cylinder is required for operation. Valve Orifice 2. This gas grill is NOT intended for commercial use. PF30LP Burner Tube Owner's Manual...

  • Page 6: Grill Features

    Grill Features 1. Roll top grill hood 11. Bread warming rack 2. Rotisserie kit 12. Rear Infrared burner 3. Grilling/cooking surface 13. Side burner 4. Side shelf 14. Control Knob: Side burner 5. Storage drawer 15. Push button igniter 6. Control knob: Rear infrared burner 16.

  • Page 7: Getting Started

    Getting Started Self-tapping screw x 2 Phillips pan head screw x 2 Getting Started 1. Please follow the steps in the order that they are presented. 2. Assemble the grill where you plan to use it. 3. You may want to place an old towel or cloth at the assembly site to prevent nuts and bolts from becoming lost.

  • Page 8: Grill Assembly

    Grill Assembly LEFT SHELF ASSEMBLY Fig. 1 1. Pull the drawer all the way out, press the black plastic drawer slide release levers to remove the drawer. (See Fig. 1) release lever 2. Loosen the four hex head bolts on the side of the Fig.
  • Page 9 Grill Assembly SIDE BURNER PARTS ASSEMBLY Fig. 6 1. Remove side burner valve assembly from packaging. Feed the valve assembly through the large cut out in the side of the cart. Loosen the four hex head bolts on the side of the grill by approximately 1/4".Attach the side burner by inserting the four bolt heads into the holes on the side burner.
  • Page 10 Grill Assembly Fig. 11 SIDE BURNER PARTS ASSEMBLY 6. Use two screws remvoed in step 5 to secure the orifice backet on the side burner tray. (See Fig. 11) Screws Note: Add lock washer when installing the screws in position. Orifice bracket underneath the side burner tay 7.
  • Page 11 Grill Assembly Fig. 14 INTERIOR PARTS ASSEMBLY Flavor grids 1. Place the flavor grids in position. (See Fig. 14) 2. Place the anti-flare screen mesh in position. (See Fig. 15 Anti-flare screen mesh Fig. 15) Fig. 16 Main cooking grate 3.

  • Page 12: Grill Location

    Grill Location Do not use the grill in garages, breezeways, sheds or any enclosed area. Never operate the grill ▲ WARNING in enclosed areas as this could lead to a carbon monoxide buildup, which could result in injury or death. Place the grill on a level surface. Avoid moving the grill while it is in operation. NOTE: The grill will operate best if it is not facing directly into the wind.

  • Page 13: Gas Requirements

    Gas Requirements GENERAL INFORMATION ▲ Never attach an unregulated gas line to the appliance. Connection to WARNING an unregulated gas line can cause excessive heat or fire. Verify the type of gas supply to be used, either Natural Gas (N.G.) or Liquid Propane (L.P.), and make sure the serial plate agrees with that of the supply.
  • Page 14 Gas Requirements L.P. GAS INSTALLATION Perfect Flame™ Gas Grills that are set to operate with L.P. gas come with a high capacity hose and regulator assembly. (Note: Only use the pressure regulator and hose assembly supplied with the grill or a replacement pressure regulator and hose assemblies specified by the manufacture).

  • Page 15: Pre Operation Leak Testing

    Pre Operation Leak Testing GENERAL INFORMATION Although all gas connections on the grill are leak tested prior to shipment, a complete gas tightness check must be performed at the installation site due to possible shifting during shipment, installation or excessive pressure unknowingly being applied to the unit. Periodically check the whole system for leaks and immediately check the system if the smell of gas is detected.

  • Page 16: Lighting The Grill

    Lighting the Grill Do not attempt to "Light" the grill if the odor of gas present!! BEFORE LIGHTING Fig. 18 ▲ Important! Before Lighting: WARNING • Check the gas supply line for cuts, wear or abrasion. • Always keep your face and body as far away from the grill as possible when lighting.

  • Page 17: Using The Rotisserie Burner

    Using the Rotisserie Burner The grill rotisserie system is designed to cook items from the back using infrared heat. The rotisserie burner is an infrared type which provides intense searing radiant heat. Preferred by chefs over other cooking methods, this intense heat sears in the natural juices and nutrients found in quality cuts of meats.

  • Page 18: Rotisserie Lighting

    Rotisserie Lighting ROTISSERIE LIGHTING Fig. 27 Open the lid. Push and turn the control knob for the rotisserie counter-clockwise to the “HIGH” position. Continue push the knob and wait 5 seconds. You’ll hear a snapping sound. If the burner does not light in 4 seconds, turn the control knob to "OFF"...

  • Page 19: Grill Light Maintenance

    Grill Light Maintenance The light bulb in your grill will need to be replaced ocassionally. Only use the light bulb supplied with the grill or a replacement lamp specified by the manufacture. Light bulb replacement instructions: 1, Unplug the light cord. 2, Open the lid, remove the self-tapping screw holding the glass cover in place.

  • Page 20: Care And Maintenance

    Care and Maintenance IMPAIRED VENTILATION OF HOT AIR FROM GRILL - In order for the burners to function properly, hot air created by the burners must have a way to escape, the burners may become deprived of oxygen, especially if the burner output is set at HIGH. This is the reason your grill was designed with ventilation louvers.
  • Page 21 Care and Maintenance DRIP TRAY The drip tray should be cleaned periodically to prevent heavy buildup of debris. NOTE: Allow the drip tray to cool before attempting to clean. Important: Do not leave the grill outside during inclement weather unless it is covered. Rain water can collect inside of the grill, the grill cart or the drip tray if left uncovered.

  • Page 22: Troubleshooting Guide

    Troubleshooting Guide Problem Possible Solution 1. Push the igniter button and check for sparks. 2. If there is a spark, check to make sure gas is supplied to the burner. a. Purge the line of any trapped air. b. Check to see if you can match-light the burner. Grill will not light c.
  • Page 23 Troubleshooting Guide Problem Possible Solution The propane regulator assembly incorporates an excess flow device designed to supply the grill with sufficient gas flow under normal conditions, yet control excess gas flow. Rapid changes in pressure can trgger the excess flow device, providing a low flame and low temperature.
