Battery Charging - Icom IC-F43TR Instruction Manual

8

BATTERY CHARGING

D Rapid charging with the BC-121N+AD-106
The optional BC-121N allows up to 6 battery packs to be
charged simultaneously. The following are additionally re-
quired.
• Six AD-106 charger adapters
• An AC adapter (BC-157)
AC adapter
(Purchase
separately)
24
Transceiver
Turn power OFF
Battery
pack
AD-106 charger
adapters are installed
in each slot.
DC power cable (OPC-656)
(Connect with the DC power supply;
13.8 V/at least 7 A)
IMPORTANT: Battery charging
Ensure the guide lobes on the battery pack are correctly
aligned with the guide rails inside the charger adapter.
(This illustration is described with the BC-119N.)
