To replace nylon line.
For your convenience it is recommended you buy spool
and line complete. Nylon line only is also available. Both
are available from Electrolux Outdoor Products stockists.
To fit spool and line complete:
1. Remove the cap.
2. Remove old spool.
3. Place spool into spoolholder.
4. Release one line from cleat.
5. Secure line into slot (U1).
6. Repeat for second line.
•
Ensure spool is fully located by gently rotating it dur-
ing fitment, whilst keeping the spoolholder steady.
7. Refit the cap.
To fit nylon line only:
•
Remember ! Your Flymo Trimmer is designed to use
only nylon line with a maximum diameter of 1.5mm.
Use only genuine Flymo nylon line.
1. IMPORTANT - Always wind the line onto the
upper section of the spool first.
Take approximately 5 metres of line. Insert 15mm of
line into one of the holes in the upper section of the
spool (U2) and wind line in the direction of the arrows
on the top of the spool. Leave approximately 100mm
of line unwound and place into cleat as illustrated in
figure U3. Repeat on lower section of spool.
2. Care should be taken to ensure that the line is neat-
ly coiled on the spool. Failure to do so will impair the
efficiency of the automatic line feed.
3. Then fit spool as described in 'To fit spool and line
complete', section above.
After you have finished using your Flymo Multi-Trim fol-
low the procedure below:
AVOID ACCIDENTAL STARTING. REMOVE PLUG
FROM MAINS AND KEEP FEET AWAY FROM THE
SWITCH LEVER WHEN:- CLEANING AROUND THE
INSIDE OF THE SAFETY GUARD, REMOVING OR
REFITTING SPOOL CAP, MANUALLY FEEDING OR
REPLACING NYLON LINE. (SEE FIGS V & W)
1. Disconnect from the mains electricity supply.
2. Never clean your trimmer with water, cleaning fluids,
or solvents, just remove debris with a suitable tool, a
soft brush or dry cloth.
3. Using the scraper provided (Multi Trim 200 only),
clean around the inside of the safety guard to remove
any grass and debris. (Fig X).
4. Using a soft brush, clean around the inside of the
safety guard, the cutting head and the motor hous-
ing. (Fig Y).
5. Inspect the trimmer carefully, especially the parts of
the cutting head.
6. If your trimmer is damaged in any way contact your local
Electrolux Outdoor Products approved service centre.
•
Never use a damaged trimmer.
7. Wind cable carefully to avoid kinking.
8. Store in a cool, dry place and out of reach of children.
Electrolux Outdoor Products are manufactured under an Environmental Management System (ISO 14001) using,
where practical, components manufactured in the most environmentally responsible manner, according to company
procedures, and with the potential for recycling at the end of the products' life.
•
Packaging is recyclable and plastic components have been labelled (where practical) for categorised recycling.
•
Awareness of the environment must be considered when disposing of 'end-of-life' product.
•
If necessary, contact your local authority for disposal information.
•
Your product is uniquely identified by a silver and black product rating label.
•
We strongly recommend that your product is serviced at least every twelve months, more often in a professional
application.
Spool Cap and Nylon Line (2 Lines) cont.
Maintenance
Environmental Information
Service Recommendations
U2
upper section
lower section
U3
SECURING LINE INTO CLEATS
V
X
Multi Trim 200 only
6
W
Y
