Summary of Contents for HighSecLabs K202B
-
Page 1: User Manual
K202B/D 2-Port Secure KVM Switch User Manual Models: K202B – Secure 2-port DVI-I KVM Switch w/audio K202D – Secure 2-port DVI-D KVM Switch w/audio Rev: 2.3 Doc No : HDC06143 K202B/D Secure KVM Switch User Manual... -
Page 2: Table Of Contents
Nov 20, 2011 Internal review for CC evaluation Dec 30, 2011 Released for customers Section 4 – Operation Feb 4, 2012 Added security procedures text Operation April 19, 2012 Added support for composite device K202B/D Secure KVM Switch User Manual... -
Page 3: Section 1 - Introduction
If the unit’s enclosure appears disrupted or if the two channel-select LEDs flash continuously, please remove product from service immediately and contact HSL Technical Support. K202B/D Secure KVM Switch User Manual... -
Page 4: Section 2 - Overview
The Switch features custom firmware that is not reprogrammable, placed on the switch enclosure to provide a visual indication if the preventing the ability to remotely attack the KVM control logic. switch has been opened or compromised. K202B/D Secure KVM Switch User Manual... - Page 5 The Switch is listed by the Common Criteria organization. It is Common Criteria validated to EAL 4+ (Evaluation Assurance Level 4) to assure the highest level of protection. Product complies with standard higher than NIAP Protection Profile 2.1. K202B/D Secure KVM Switch User Manual...
-
Page 6: Operational Features
DVI-I and HDMI Support The K202B model supports both digital (DVI-D and HDMI) and analog video (VGA) displays and video cards. Audio Support Switch support audio out switching. Microphone switching not supported to prevent analog leakages through audio ports. -
Page 7: Equipment Requirements
VGA output to DVI-D KVM input to enable legacy video mix with newer DVI computers and display. Note (K202B only): If VGA display will be used then all computers Important: The use of cables other than those provided by HSL is must be connected through VGA interface. - Page 8 HSL RFE740 Secure Remote Fiber Extender device • USB Mouse console port connected to the switch console ports. The Switch USB mouse console port is compatible with the following types of devices: K202B/D Secure KVM Switch User Manual...
- Page 9 Use only HSL power supply provided with the switch. In case of a power supply failure, order a replacement unit from HSL. Order No.: EU – CPN06175 • US – CPN06174 • UK - CPN06176 • K202B/D Secure KVM Switch User Manual...
-
Page 10: Safety Precautions
The product is exposed to excessive moisture or water. The product is not working well even after carefully following the instructions in this user’s manual. The product has been dropped or is physically damaged. K202B/D Secure KVM Switch User Manual... -
Page 11: Front Panel Features
1 – Heavy-duty steel enclosure 2 – Channel #1 selected LED 3 – Channel #1 select push-button 4 – Channel #2 select push-button 5 – Channel #2 selected LED 6 - Holographic Tamper Evident Label K202B/D Secure KVM Switch User Manual... -
Page 12: Rear Panel Features
4 – Console USB Mouse jack 5 – Computer #1 group interface area 6 – DC Power input jack – barrel type 7 – Computer #1 group DVI-I (K202B) / DVI-D (K202D) video input connector K202B/D Secure KVM Switch User Manual... -
Page 13: Tamper Evident Labels
If for any reason one or more tamper-evident label is missing, appears disrupted, or looks different than the example shown here, please call HSL Technical Support and avoid using that product. HSL Holographic Tampering Evident Label K202B/D Secure KVM Switch User Manual... -
Page 14: Product Specifications
Console Mouse Input USB Type-A female connector Console Audio Out 3.5mm stereo jack CPU Keyboard/Mouse Ports USB Type-B jack CPU Audio Input 3.5mm stereo jack CPU Video Input Port DVI-I dual-link female Port Select push-buttons K202B/D Secure KVM Switch User Manual... -
Page 15: Section 3 - Installation
Keyboard and mouse cables length. Cables typically may be • extended to a distance of 4 meters. Display cable length. Typically may be extended to around • 10 meters without video quality degradation (still depends K202B/D Secure KVM Switch User Manual... -
Page 16: Installation
• Note: If computer is having more than one video output connector Note: K202B - If user display is only VGA – first test for video output availability by connecting a display Verify that all computers are having either VGA or DVI-I directly to that port. - Page 17 If you encounter an error, check your cable connections for that computer and reboot. If the problem persists, please refer to the Troubleshooting section in this User Manual. K202B/D Secure KVM Switch User Manual...
- Page 18 Section 3 - Installation Typical system installation diagram (K202B) K202B/D Secure KVM Switch User Manual...
-
Page 19: Section 4 - Operation
2. Switch between computers using keyboard shortcuts You can select which computer you wish to control by typing key combinations on the keyboard. To switch KVM to another channel press CNTL+CNTL+ “Channel number” for example for computer #2 press CNTL+CNTL+2. K202B/D Secure KVM Switch User Manual... -
Page 20: Section 5 - Troubleshooting
Connect the display directly to the PC to confirm that video Solutions: Device anti-tampering system was triggered. Change unit • output is available and that good image is shown. and call HSL technical support. K202B/D Secure KVM Switch User Manual... - Page 21 Problem: Keyboard does not work (all channels) Solutions: Check that the keyboard you are using is connected • properly to the Switch. Check that the USB cable between the Switch and the • computer is completely connected. K202B/D Secure KVM Switch User Manual...
- Page 22 These are not supported by the switch due to security policy. If the computer is coming out of standby mode, allow up to • one minute to regain mouse function. Try a different mouse. • K202B/D Secure KVM Switch User Manual...
-
Page 23: High Sec Labs Warranty Programs
High Sec Labs Service delays the start of any coverage by 60 days. Center. If the unit was not registered, you should enclose a written receipt for the product, showing the date of purchase, K202B/D Secure KVM Switch User Manual... - Page 24 This warranty excludes power supply, cables, mouse and adapters its original package or an equivalent. The Customer will pay purchased with the device. incoming freight charges and is responsible for any loss or damage K202B/D Secure KVM Switch User Manual...
-
Page 25: High Sec Labs Security Procedures
HSL QA, HSL provides an High Sec Labs will not be held obligated to support the product email to the following list of users based on affected product: under its Warranty or Extended Warranty terms and conditions. K202B/D Secure KVM Switch User Manual... -
Page 26: Copyright And Legal Notice
High Sec Labs on the issues discussed as of the date of change without prior notice. publication. Because High Sec Labs must respond to changing market conditions, it should not be interpreted to be a commitment Images are for demonstration purposes only. K202B/D Secure KVM Switch User Manual...
