Operating Instructions
GAS POWERED PISTON COMPRESSORS
EMAX designs and manufactures products for safe operation. However, operators and maintenance persons are
responsibile for maintaining safety. All safety precautions are included to provide a guideline for minimizing the
possibility of accidents and property damage while equipment is in operation. Keep these instructions for reference.
EMNG000001 0810
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Emax EGPS0817WL
Summary of Contents for Emax EGPS0817WL
-
Page 1: Operating Instructions
Operating Instructions GAS POWERED PISTON COMPRESSORS EMAX designs and manufactures products for safe operation. However, operators and maintenance persons are responsibile for maintaining safety. All safety precautions are included to provide a guideline for minimizing the possibility of accidents and property damage while equipment is in operation. Keep these instructions for reference. -
Page 2: Table Of Contents
Truck Installation ....6 Battery Component ....6 EMAX Gas Powered, Piston Air Compressors Model... -
Page 3: Description
Operating Instructions Description Unit configuration and appearance varies by model. Callouts are for general identification. Gas tank Electric start Intercooler Air filter Head unloader valve Engine start pull cord Raised motor mounting Check valve plate Air receiver / Tank Oil site glass Tank drain valve Ball valve (Air outlet) Pressure gauge... -
Page 4: Breathable Air
7. Make sure to put compressor on a level surface that property damage could occur. can support the weight of the compressor and load- A forklift may be necessary for unloading the EMAX ing equipment. compressor. Use all forklift safety measures and require a certified forklift operator. -
Page 5: Installation
Operating Instructions Damage may result in bursting and cause injury or Minimum Pipe Size For Compressed Air Lines property damage. (Pipe size shown in inches) Installation Length Of Piping System SCFM 25 ft. 50 ft. 100 ft. 250 ft. Area 1. -
Page 6: Truck Installation
Battery Component sure there are no oily rags, trash, leaves, litter or other combustible Most EMax compressors are equipped with an electric materials in operating area. Keep starter but require a customer supplied, 12V battery suitable, fully charged fire extinguishers nearby for operation. -
Page 7: Start Up
Operating Instructions 7. Make sure to provide adequate ventilation and use proper lubricant while operating the compres- 1/2” deflection sor. If lubricant or other combustible substances are spilled, clean up immediately. 8. When checking or adding lubricant or when refill- ing air line anti-icer systems with antifreeze com- pound, shut off compressor and allow it to cool. -
Page 8: Maintenance
EMAX Gas Powered, Piston Compressors 7. Start engine by turning key or with pull start Inspect belt tension after first 30 hours of operation cord. then every 30 days. 1. Proper belt tension is determined by pressing If ignition fails to start engine... -
Page 9: Safety Valve
Operating Instructions Safety Valve NEVER attempt to regulate or tamper with safety valve. Valve is Pull ring on safety valve sealed and certified by ASME code before each use. and is designed to relieve system pressure when necessary. Check proper operation of safety valve before each Figure 7: Safety Valve use. -
Page 10: Troubleshooting
Low air pressure Pilot valve not set properly Call EMAX Service or local dealer to adjust valve Head unloader sticking Lubricate valve with industrial grade grease Intake or exhaust valves not... -
Page 11: Troubleshooting
Operating Instructions Troubleshooting Chart (continued) Problem Possible Causes Resolutions Overheating Excessive use Don’t use it so much man! Head valve(s) not seating Clean or replace properly Blown cylinder head gasket(s) Replace gasket(s) Restriction in head, intercooler Clear blockage or check valve Low oil Add oil. -
Page 12: Warranty
(at Purchaser’s expense) to have a redundant DRYER UNIT. Warranty repairs shall not include freight costs. Purchaser is responsible for returning unit to Emax, Inc. Each DRYER UNIT must have a coalescing filter attached to the intake of the dryer to remove any oil or dirt before air enters the dryer.
