CS2400
®
Alterra
Freestanding
Wood Stove
Owner's & Installation Manual
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
918-926a
02/15/12
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
Advertisement
Table of Contents
Related Manuals for Regency Alterra CS2400
Summary of Contents for Regency Alterra CS2400
- Page 1 CS2400 ® Alterra Freestanding Wood Stove Owner's & Installation Manual Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference. 918-926a 02/15/12 FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4...
- Page 2 The pride of workmanship that goes into each of our products will give you years of trouble-free enjoyment. Should you have any questions about your product that are not covered in this manual, please contact the REGENCY DEALER in your area.
-
Page 3: Safety Label
SAFETY LABEL This is a copy of the label for reference only, that accompanies each CS2400 Wood Stove. We have included a copy of the contents here for your review. NOTE: Regency units are constantly being improved. Check the label on the unit and if there is a difference, the label on the unit is the correct one. -
Page 4: Table Of Contents
Optional outdoor Air kit installation ......22 Blower/Fan installation ..........23 Fan Operation..............23 Fan wiring ..............23 OPERATING INSTRUCTIONS Operating Instructions ..........24 First Fire ..............24 Draft Control ..............24 Ash Disposal..............25 Safety Guidelines And Warnings .........26 Fan maintenance ............26 Regency CS2400 Freestanding Wood Stove... -
Page 5: Dimensions
DIMENSIONS UNIT DIMENSIONS 26-3/8” 21-1/2” 8-5/16” 6" fl ue collar Shown with optional fan installed. 17-3/16” 26-5/16” 25-15/16” Regency CS2400 Freestanding Wood Stove... -
Page 6: Installation Checklist
CAUTION: The chimney should be the same size Ash Drawer Installation as the fl ue outlet on the stove. The chimney must be 13) Your Regency Wood stove is not to be connected Ashlip Installation listed as suitable for use with solid fuels. For other to any air distribution duct. -
Page 7: Minimum Clearance To Combustible Materials
Mobile Home Close Clearance (To be installed with required pipe components) "C" Vent single wall pipe is not approved for Mobile Home installations. (Refer to Mobile Home Instructions.) From Unit From Corner From Flue Center-line CS2400 15" 6.5" 6" 28" 14-7/8" 18-11/16" Regency CS2400 Freestanding Wood Stove... - Page 8 MEASUREMENTS "FROM UNIT" ARE FROM THE SIDE SHIELDS OF THE STOVE TO A SIDE WALL OR TO A CORNER, AND FROM THE REAR HEAT SHIELD TO A BACK WALL The Regency Freestanding models have been alcove approved and must be installed with a listed double wall connector to the ceiling level.
-
Page 9: Step By Step Chimney And Connector Installation
6) Fasten the raincap with spark screens (if re- quired) to the top of your chimney. 7) For optimum effi ciency when installing into a masonry chimney, size accordingly, i.e. the 6" (152mm) fl ue dia. is 28.28 sq.in. Horizontal Installation Regency CS2400 Freestanding Wood Stove... -
Page 10: Masonry Chimney
The chimney must be the required height above the roof or other obstructions for safety and proper draft operation. The space heater is to be connected to a factory-built chimney conforming to CAN/ULC-S629, Standard for 650 C Factory-Built Chimneys. Regency CS2400 Freestanding Wood Stove... -
Page 11: Combustible Wall Chimney Connector Pass-Throughs
24 gage minimum sheet metal supports. See that the supports are fastened securely to wall surfaces on all sides. Make sure fasteners used to secure chimney fl ue liner. Regency CS2400 Freestanding Wood Stove... -
Page 12: Recommended Heights For Woodstove Flue
= 4 ft. one "T" = 3 ft. Total Addition (at sea level) = 9 ft. Recommended Flue Height Elevation Example a) Example b) 1000' 18.72' 21.84' 2000' 19.44' 22.68' 5000' 21.60' 25.20' 8000' 23.76' 27.72' Regency CS2400 Freestanding Wood Stove... -
Page 13: Mobile Home Installation
1) Bend the tabs on the rear heat shield outwards 90 degrees. 2) Secure the tabs on the top of the rear heat shield with ¼” hex screws, supplied. Left and right tabs - bent at 90° Installed Pipe Shield Regency CS2400 Freestanding Wood Stove... -
Page 14: Listed Components For Mobile Home Installation
MOBILE HOME INSTALLATION The Regency CS2400 is approved for installation in a Mobile Home if one of the following pipe systems is used. A chimney complying with the requirements for type HT chimney, factory built, Residential type and Building Heating appliance, (UL103, ULCS629, OR2) code- approved masonry chimney with a fl ue liner U.S. -
Page 15: Stainless Steel Smoke Defl Ector Installation
WARNING: Operation of the unit with out proper installation of smoke defl ector will void warranty. Ensure defector is seated so bolts are situated at the top of the keyhole before tightening. Regency CS2400 Freestanding Wood Stove... -
Page 16: Flue Baffl E & Secondary Air Tube Installation
fl ue. If it is not enough space then remove the middle air in wood storage area. tube (reverse the procedure in step 1) above), and baffl e and then replace everything when cleaning is completed. Regency CS2400 Freestanding Wood Stove... -
Page 17: Side Panel Installation
Failure to do this will result in burn stains on panels which you will be unable to remove. Not protected by product warranty. 4) Install Regency logo on to the 1) Bend the metal tab (located in the top front corner of the side panels to left side panel - by snapping a 45°... -
Page 18: Ash Drawer Option
- it is directly below the upper ash dump plate.) by removing the two nuts and bolts holding the 2 plates together from underneath the stove. Ash Dump Plates Ash Plug Keep ash removal tool handy for maintenance - see ash disposal in operating instructions. Regency CS2400 Freestanding Wood Stove... -
Page 19: Lower Surround Door Reversal
5) Remove and rotate both the male part of the latch 180° - located on the inside of the lower surround door. Install the latch on the opposite side of the door. Door latch - male portion Regency CS2400 Freestanding Wood Stove... -
Page 20: Cast Door Reversal
4) Flip the door hinge 180° - install on the left side of the unit with 2 bolts. 5) Reattach the door catch assembly on the right side with 2 bolts from step Door 9) Reattach the door to the door hinge. Hinge Door Catch Regency CS2400 Freestanding Wood Stove... -
Page 21: Wood Storage
Note: Please refer to local codes. (B365, NFPA 211) and your local jurisdiction.. Tabs on ashlip Store wood behind opening ASHLIP INSTALLATION 1) Open lower surround door. 2) Ashlip to be positioned just below the ashdrawer (if installed). Final install of Ashlip Ashlip to be positioned here Regency CS2400 Freestanding Wood Stove... -
Page 22: Optional Outdoor Air Kit Installation
Secure with 4 self tapping screws. plate. 3) Reinstall the backing plate over the air kit pipe. Secure with 4 screws removed from step 1. 4) Slide cap over end to pipe to complete the installation. Regency CS2400 Freestanding Wood Stove... -
Page 23: Blower/Fan Installation
CAUTION: Label all wires prior to disconnection hazard and should be plugged directly into a properly when servicing controls. Wiring errors can cause grounded three-prong receptacle. Do not cut or remove improper and dangerous operation. the grounding prong from this plug. Regency CS2400 Freestanding Wood Stove... -
Page 24: Operating Instructions
fl ue to establish the fi re. (Leaving Regency Stove causing a draft down your the door slightly open will help your fi re start chimney. If this occurs, slightly open a window more rapidly.) -
Page 25: Ash Disposal
2) Always leave 1/2 to 1 inch of ash in the bottom of the fi rebox. This helps in easier starting and a more uniform burn of your fi re. Replace ash plug when ashes have been removed. Regency CS2400 Freestanding Wood Stove... -
Page 26: Safety Guidelines And Warnings
Failure to do so can result in a serious chimney fi re. 7) Your Regency stove can be very hot. You may be seriously burned if you touch the stove while it is operating, keep children, clothing and furniture away. -
Page 27: Maintenance
4) A small hot fi re is preferable to a large smoul- dering one that can deposit creosote within the system. Your Regency stove is supplied with 5 mm Neoceram ceramic glass that will withstand the highest heat 5) Check the chimney at least twice a month dur- that your unit will produce. - Page 28 Use only high temperature anti seize lube. (ie. never seize) Check glass for cracks Replace if required. Clean blower motor Disconnect power supply. Remove and clean blower. *DO NOT LUBRICATE* Inspect and clean chimney Annual professional chimney cleaning recommended. Regency CS2400 Freestanding Wood Stove...
-
Page 29: Parts List
Ash Drawer Assembly 156-523 Door Catch Assembly 146-517 Heat Shield Assembly 146-517 Back Shield Assembly 146-512 Firebox Assembly 146-011 Top/Bottom Vents 146-008 Side Support 948-216 Regency Logo plate 076-022 Ashlip 820-482 Stainless smoke defl ector Regency CS2400 Freestanding Wood Stove... -
Page 30: Fire Brick / Air Tube / Baffl E
Fan Bracket Left Hand 200-229 Fan Housing Back 910-157/P Fan 910-142 Thermodisc FIRE BRICK / AIR TUBE / BAFFLE Part # Description 020-960 Firebrick Set 033-953 Air Tube - 3/4" (Qty: 4) 020-957 Baffl e (set) Regency CS2400 Freestanding Wood Stove... -
Page 31: Warranty
The authorized selling dealer is responsible for all in-fi eld service work carried out on your Regency product. FPI will not be liable for results or costs of workmanship from unauthorized service persons or dealers. - Page 32 ® Register your Regency warranty online www.regency-fi re.com Reasons to register your product online today! • View and modify a list of all your registered products. • Request automatic email notifi cation of new product updates. • Stay informed about the current promotions, events, and special offers on related products.
