Cascades™ Series
Owners &
Installation Manual
Freestanding Woodstove
French Manual Download: https://bit.ly/3sXQtLI
www.regency-fire.com
Manuel en Français : https://bit.ly/3sXQtLI
MODEL: F2500-1
Tested by:
Installer: Please complete the details on the back cover
and leave this manual with the homeowner.
Homeowner: Please keep these instructions for future reference.
0219WS029S
920-643
FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. 6988 Venture St., Delta, BC Canada, V4G 1H4
06.27.23
Advertisement
Related Manuals for Regency Cascade Series
Summary of Contents for Regency Cascade Series
- Page 1 Cascades™ Series Owners & Installation Manual Freestanding Woodstove French Manual Download: https://bit.ly/3sXQtLI www.regency-fire.com Manuel en Français : https://bit.ly/3sXQtLI MODEL: F2500-1 Tested by: Installer: Please complete the details on the back cover and leave this manual with the homeowner. Homeowner: Please keep these instructions for future reference.
- Page 2 Tested to Method 28R, E2780 - 10, E2515 - 11. Model Regency F2500-1 - 1,4 g/hr. “This manual describes the installation and operation of the Regency F2500-1 catalytic equipped wood heater. This heater meets the 2020 U.S. Environmental Protection Agency’s crib wood emission limits for wood heaters. Under specific test conditions this heater has been shown to deliver heat at rates ranging from 13,580 BTU/hr.
-
Page 3: Table Of Contents
CAUTION: To avoid burns or wood splinters, when opening/closing the fuel door or adding wood to the fire, you should always wear appropriate protective gloves to protect your hands from the heat being emitted from this fireplace. F2500-1 Regency Freestanding Woodstove... -
Page 4: Safety Decal
CONNECTOR - MOBILE HOME CONNECTOR - MOBILE HOME Approuvé et testé à la méthode 28R, E2780-10, E2515-11. Modèle Regency F2500-1 – 1,4 g/h. Cet appareil de chauffage au bois doit être inspecté périodiquement et réparé SIDEWALL A 369 mm / 14.5 in... -
Page 5: Dimensions
635mm " 635mm 163mm 163mm 23" " 584mm 23" 23" 556mm 584mm 584mm Outside Air Dimensions " " 115mm " 115mm " 115mm " 173mm " 173mm 173mm With Pedestal With Bottom Heat Shield & Legs F2500-1 Regency Freestanding Woodstove... -
Page 6: Installation
Do installation instructions within this manual. not confuse a chimney with a type “B” Venting 2. Select a position for your Regency Stove. Consult System used for gas appliances as suitable for the minimum clearance chart for your model 12. -
Page 7: Modular Installation Options
WARNING: ONLY USE SPECIFIED COMPONENTS. The following items are required when assembling your Regency Stove. F2500-1 unit - the Rear Heat Deflector is supplied with the stove, but if you choose not to use it you must use the Airmate instead... -
Page 8: Pedestal Assembly Installation
Blanking Plate Knockout Hang operating handle after use Shown with Classic door Logo Installation 1. Push the Regency logo into the two holes in the front bottom left corner of the pedestal cover plate. Note: Any paint touch up should be done prior to placing logo on pedestal. -
Page 9: Bottom Heat Shield And Legs Installation
Screw Diagram 4 Diagram 1 8) Hook control tool onto tool holder as shown below. Note : The control tool will be with the manual package inside of the unit. Control Tool Diagram 2 908-010b 06/14/23 F2500-1 Regency Freestanding Woodstove... -
Page 10: Room Air Important
From Corner From Flue Center-Line Medium F2500-1 with Airmate 14.5" (369mm) 7" (178mm) 4.75" (121mm) 27" (686mm) 13.5" (343mm) 17" (432mm) with Rear Deflector 14.5" (369mm) 9" (229mm) 4.75" (121mm) 27" (686mm) 15.5" (394mm) 17" (432mm) F2500-1 Regency Freestanding Woodstove... -
Page 11: Minimum Alcove Clearance & Clearance To Combustible Materials
Minimum Alcove Clearance and Clearance to Combustible Materials The Regency Freestanding models have been alcove approved and must be installed with a listed double wall connector to the ceiling level. Note: Minimum alcove ceiling height - 83" (2108 mm) (Measured from base of appliance) Maximum depth of alcove - 48"... -
Page 12: Floor Protection (Corner Installation)
25-1/16" (637mm) 40-3/8" (1026mm) 59-5/8" (1515mm) 52-1/4" (1327mm) 23-11/16" (602mm) Residential Close Clearance (To be installed with required pipe components) Canada 40-3/8" (1026mm) 58-13/16" (1494mm) 51-5/8" (1312mm) 23-1/16" (586mm) 40-3/8" (1026mm) 56-13/16" (1443mm) 50-1/4" (1276mm) 21-11/16" (551mm) F2500-1 Regency Freestanding Woodstove... -
Page 13: Step-By-Step Chimney And Connector Installation
Secure the flashing to your roof with nails or screws. 5. Place the storm collar over the flashing, sealing the joints with a silicone caulking. Horizontal Installation F2500-1 Regency Freestanding Woodstove... -
Page 14: Masonry Chimney
Maintain proper clearance to the structure as recommended by the manufacturer. The chimney must be the required height above the roof or other obstructions for safety and proper draft operation. The space heater is to be connected to a factory-built chimney conforming to CAN/ULC-S629, Standard for 650 C Factory-Built Chimneys. F2500-1 Regency Freestanding Woodstove... -
Page 15: Combustible Wall Chimney Connector Pass-Throughs
Cover opening with and support chimney section on both sides with 24 gage minimum sheet metal supports. See that the supports are fastened securely to wall surfaces on all sides. Make sure fasteners used to secure the metal chimney connector do not penetrate chimney flue liner. F2500-1 Regency Freestanding Woodstove... -
Page 16: Mobile Home Installation (Usa Only)
11. WARNING: DO NOT INSTALL IN A SLEEPING ROOM OF A MOBILE HOME. 12. Use silicone to create an effective vapour barrier at the location where the chimney or other component penetrates to the exterior of the structure. F2500-1 Regency Freestanding Woodstove... -
Page 17: Recommended Heights For Woodstove Flue
Example b) 1000' 18.72' 21.84' 2000' 19.44' 22.68' 5000' 21.60' 25.20' 8000' 23.76' 27.72' WARNING: CAUTION: The structural integrity of the mobile home DO NOT INSTALL IN SLEEPING floor, wall and ceiling/roof must be maintained. ROOM F2500-1 Regency Freestanding Woodstove... -
Page 18: Optional Outside Air Kit
"Clearances to Combustibles" section of the manual. Pipe fresh air into the pedestal area by using a minimum 4" (102 mm) duct pipe with a mesh grill at the outside termination. In this application, the blanking plate remains. Do not remove. Rear View F2500-1 Regency Freestanding Woodstove... -
Page 19: Brick Installation
Brick Partial: 1-1/4" x 2" x 9" NOTE: This kit contains one spare brick in case of breakage. NOTE: The "AD" brick covers the Ash Dump hole that is used when the Ash Drawer Kit is installed. F2500-1 Regency Freestanding Woodstove... -
Page 20: Removing Wooden Handle
Firebrick is included to extend the life of your stove and radiate heat more Your Regency stove is supplied with 5 mm Neoceram ceramic glass that will evenly. Check to see that all firebricks are in their correct positions and have withstand the highest heat that your unit will produce. -
Page 21: Wood Handle & Door Assembly
(Refer to Diagram 1) Door hinges Wood handle Door Door handle Hinge Cap Cover Diagram 2 tooltip Diagram 3 F2500-1 Regency Freestanding Woodstove 919-967a 04.03.19... -
Page 22: Flue Baffle & Secondary Air Tube Installation
2. Tilt the second baffle on top of the 2 air tubes and lock it in place with the already placed baffle. Front View Front View Important: Push both baffles so they are tight against the back wall. Front View F2500-1 Regency Freestanding Woodstove... -
Page 23: Fan Installation
Wiring errors can cause improper and dangerous operation. Neutral Green Manual/ Live Ground Auto 120V AC Switch Switch 60 Hz Fan Thermodisc (normally open) Black Black Black Ground Wiring Diagram 908-126a 04/08/14 F2500-1 Regency Freestanding Woodstove... -
Page 24: Stainless Steel Smoke Deflector Installation
WARNING: Operation of the unit with out proper installation of smoke deflector will void warranty. Ensure deflector is seated so bolts are situated at the top of the keyhole before tightening. F2500-1 Regency Freestanding Woodstove... -
Page 25: Seasoned Firewood
Left - Open Right - Closed below ashlip WARNING: To build a fire in ignorance or to disregard the information contained in this section can cause serious permanent damage to the unit and void your warranty!! F2500-1 Regency Freestanding Woodstove... -
Page 26: First Fire
NOTE: These steps are crucial to ensure proper your home, a downdraft may be created by your charcoalization and coal bed prior to loading Regency wood stove causing a draft down your High, Med and Low fire loads. chimney. If this occurs, slightly open a window near your unit. -
Page 27: Fan Operation
Cover Plate a serious chimney fire. hot embers. 8. Your Regency stove can be very hot. You may 2. Please take care to prevent the build-up of ash CAUTION: HOT WHILE IN be seriously burned if you touch the stove around the start-up air housing located inside OPERATION. -
Page 28: Maintenance
Place combustor in a partially open position after a hot fire has been started to burn off the soot accumulation. Burning coal will cause a sulfur-based compound to coat the catalyst. Revert to burning wood and fire the combustor to elevated temperatures for one hour. F2500-1 Regency Freestanding Woodstove... -
Page 29: Maintenance
If the door gasket requires replacement 7/8" diameter other organic vapours combine with moisture to fireplace stove, including burning seasoned wood material must be used. Regency uses a 7/8" gasket rope form creosote. The creosote vapours condense in and maintaining a clean stove and chimney system. -
Page 30: Catalytic Combustor Part#022-040
(by- and inspect the flue system for any signs of creosote buildup. pass open) through the combustor. A clean flue helps prevent chimney flue fires. F2500-1 Regency Freestanding Woodstove... -
Page 31: Bypass Rod Replacement
Catalyst slide Bypass rod Retaining clip 4. Slide bypass rod out. 5. Replace with a new bypass rod. 6. Reverse Steps 3 and 2. F2500-1 Regency Freestanding Woodstove... -
Page 32: Combustor Assembly Removal/Replacement
7. Pull down catalyst assembly to remove. Front View 4. Tilt the second baffle forward and carefully slide it out of the unit in the same manner as step 2. Catalyst 8. Reverse steps to reinstall catalyst. Side View F2500-1 Regency Freestanding Woodstove... -
Page 33: Secondary Air Tube Removal/Installation
NOTE: Replacement combustors can be retrieved from Applied Ceramics 3. Remove the fragile two piece Baffles, then remove the 2 tubes. or contact your local Regency Dealer—see warranty information at 4. Grasp front secondary air tube firmly with vise grips, using a hammer tap the back of this manual for details. -
Page 34: Parts List
Black with Nickel Accent Door - Complete 846-515 Fan Assembly Complete 910-138 2 Way Switch 910-140 3 way Switch 022-912 Airmate 910-142 Fan Thermodisc 075-073F Tool Hanger 181-040 Control Tool 948-223 Regency Logo Plate 910-157/P Fan Motor Only With Squirrel cage F2500-1 Regency Freestanding Woodstove... - Page 35 F2500-1 Regency Freestanding Woodstove...
-
Page 36: Bases
5/16" x 6 1/2 " Long Hex Head Bolt (Each) 022-025 Metal Washer 820-456 Metal Spacer/Support Bracket (Each) Part # Description 022-915 Pedestal Complete 022-011 Pedestal Door 904-257 Magnetic Catch (Each) 075-910 Ashdrawer Pedestal 904-023 5/16 x 1-1/2 Hex Head Bolt (Each) F2500-1 Regency Freestanding Woodstove... -
Page 37: Brick Kit
Brick - Regular Full Size: 1-1/4" x 4-1/2" x 9" Brick Partial: 1-1/4" x 2" x 4-1/2" Brick Partial: 1-1/4" x 4-1/2" x 3-1/2" Brick Partial: 1-1/4" x 2" x 9" NOTE: This kit contains one spare brick in case of breakage. F2500-1 Regency Freestanding Woodstove... -
Page 38: Catalytic Combustor
Complete catalyst assembly without the catalyst 022-546 Catalyst housing 846-689 Graphite Md-500 Rope Gasket (6') (936-236) 075-043 Rod Lock 022-040 5.83" diameter metal foil combustor 075-044 Cat cradle 022-033 Offset flame shield 075-103 Rod clip lock F2500-1 Regency Freestanding Woodstove... - Page 39 F2500-1 Regency Freestanding Woodstove...
-
Page 40: Warranty
At all times FPI reserves the right to inspect reported complaints on location in the field claimed to be defective prior to processing or authorizing of any claim. Failure to allow this upon request will void the warranty. Revision Date: July 2019 Regency Wood Products Warranty F2500-1 Regency Freestanding Woodstove... - Page 41 Freight damages for products or parts are not covered under the terms of the warranty. Products made or provided by other manufacturers and used in conjunction with the FPI appliance without prior authorization from FPI may void this warranty. Revision Date: July 2019 Regency Wood Products Warranty F2500-1 Regency Freestanding Woodstove...
- Page 42 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form at http://www.regency-fire.com/Customer-Care/Warranty-Registration.aspx...
- Page 43 Product Registration and Customer Support: Thank you for choosing a Regency Fireplace. Regency strives to be a world leader in the design, manufacture, and marketing of hearth products. To provide the best support for your product, we request that you complete a product registration form found on our Web Site under Customer Care within ninety (90) days of purchase.
-
Page 45: Catalytic Combustor Warranty Coverage
All warranty claims must be sent to: Regency Fireplace Products By Authorized Regency Dealer * Prices subject to change. Regency reserves the right to reject any claim if it is determined the damage is a result of misuse, abuse or improper cleaning/ handling. F2500-1 Regency Freestanding Woodstove... - Page 46 F2500-1 Regency Freestanding Woodstove...
- Page 47 F2500-1 Regency Freestanding Woodstove...
- Page 48 Dealer Name & Address: _____________________________ _________________________________________________ Installer: _________________________________________ Phone #: _________________________________________ Date Installed: _____________________________________ Serial #: __________________________________________ Printed in Canada Regency is a trademark of FPI Fireplace Products International Ltd. © Copyright 2023, FPI Fireplace Products International Ltd. All rights reserved.
