Summary of Contents for Audiovox LCM5869NP
- Page 1 ® ELECT RONICS CORP . LCM5869NP & LCM7069NP Remote Controlled Color Display Monitor 5.8-Inch Color Display Monitor 7-Inch Color Display Monitor Installation and Owner's Manual 128-6324 Released: 03-27-02. 1 of 22...
-
Page 2: Explanation Of Graphic Symbols
EXPLANATION OF GRAPHIC SYMBOLS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with the arrowhead within a triangle is in- tended to alert tell the user that parts inside the product are capable of producing an electric shock . -
Page 3: Materials List
Remote Control Unit (136B2156, used with LCM5869NP and LCM7069NP) with Lithium Battery, 3V,CR 2025 (1pc.) Interconnect Box (136B2183, used with LCM5869NP and LCM7069NP) (1pc.) Monitor Cable, 8' (112B3151, used with LCM5869NP and LCM7069NP) (1pc.) Headrest Mounting Tray (LCM5869NP=102C3739) or (LCM7069NP=102B3738) (1pc.) -
Page 4: System Overview
SYSTEM OVERVIEW The LCM5869NP is comprised of a 5.8" Thin Film Transistor (TFT) Liq- uid Crystal Display ( LCD) Monitor. The LCM7069NP is comprised of a 7" Thin Film Transistor (TFT) Liquid Crystal Display ( LCD) Monitor. The Monitor for both of these systems have a 16:9 Aspect Ratio display that allows the user to select between two video sources (Not Supplied). - Page 5 NOTE: The following IRT board installation procedure should be per- formed between steps 10 and 11of the Headrest Mounting procedure on page 10. Insert the IRT boards into their respective compartments in the Headrest Mounting Tray and insert the plug into the IRT board. When the user switches the video source utilizing the ON/OFF/MODE switch, the A/B switch (see illustration below) on the IR2CHS Headphones must also be switched to select the desired audio source.
-
Page 6: Vehicle Preparation
VEHICLE PREPARATION 1) Decide on the system configuration and the options that will be in- stalled (i.e. what components, VCP, DVD, TV Tuner, Video Game, Monitor, FM Modulator, etc.). 2) Read the manuals and get familiar with the electrical requirements and connections. -
Page 7: Tools And Materials Required
10) After verifying the proper operation of the system, proceed to mount each component. 11) The mounting method, and the location will vary from vehicle to vehicle; this manual will focus on typical Headrest installation pro- cedures. 12) The best location for the system components is: a) Monitor: Headrest or bracket (optional) mounted onto a flat surface. - Page 8 2) Slide monitor onto Surface Mount Bracket and then tighten the fasten wheel. Monitor Fastener Wheel Surface Mount Fastener Mounting Bracket 3) Adjust viewing angle of monitor by tightening the fastener at the side. Surface Mount When the system components are mounted, test the system to verify that it is functioning correctly.
-
Page 9: Headrest Mounting
Headrest Mounting: 1) Remove the headrest from the Mounting Trim Monitor Headrest Tray Ring vehicle for easiest installation. 2) Lay headrest on a flat surface. 3) Center trim collar on headrest as shown. NOTE: Depending on the angle of the headrest the Trim Ring and housing may be mounted upside down. - Page 10 6) Using the utility knife, cut the head- rest material along the “X” lines. Do not cut the material along the other lines at this time. 7) This will leave you with an “X” cut as shown. 8) Pull the flaps up and cut the foam beneath the material to the proper depth.
- Page 11 NOTE: The Mounting Tray will need to be secured to the headrest, either by using tie straps, screws, etc. 10) Lay the flaps of headrest material down into the recess and insert the Mounting Tray into the recess. Check for fit. If it does not fit prop- erly, you may need to remove some more foam.
-
Page 12: Electrical Connection
ELECTRICAL CONNECTION (Wiring Diagram) AV Output Video Source Input (1&2) Not Used AUDIO OX 128-6324 12 of 22... -
Page 13: Monitor Removal
Monitor Removal: The following procedure is to remove the Monitor from the Mounting Tray using the supplied Removal Tool. NOTE: Use care when per- forming this procedure not to scratch any exposed surfaces with the edges of the Removal Tool. Masking tape applied to the two tips or legs of the Removal Tool will help prevent scratching. -
Page 14: Controls And Indicators
CONTROLS AND INDICATORS Headphone AUDIO OX OPERATING INSTRUCTIONS POWER ON/OFF/MODE Press the POWER button to turn power on. Pressing the POWER button again momentarily will change video inputs. Press the for NTSC input. Press the for PAL input. Press and hold the POWER button for three seconds to turn power off. -
Page 15: Maintenance
Scroll Down Button This button is used to move Down through the selected menu items (Color, Bright, Tint, [NTSC] Only) this button will also switch selected items (DIM, RESET, FORMAT). MENU Button Press the MENU button once to display the menu On Screen Display. -
Page 16: Remote Controller
REMOTE CONTROLLER NOTE: The Remote Controller supplied with this system is a standard remote control, which is used to operate other systems. The Remote Controller is not a universal remote and will only perform the functions described herein. Only the Keys highlighted on the Remote Controller image bellow are used to operate this system. - Page 17 MENU FUNCTION KEY: The MENU Key is used to navigate between the Color, Bright and Tint adjustment modes. When the MENU Key is pressed an On Screen Display(OSD) will appear as shown bellow. COLOR BRIGHT TINT DIMMER FORMAT RESET Press release and tap the MENU Key until the desired adjustment mode is selected.
- Page 18 VIDEO SOURCE MODE KEY: To switch between Video Input Sources (AV1 and AV2) press and re- lease the MODE Key. NOTE: Select either *NTSC or PAL, press the F or G Keys (CH/ DISK/SET). 128-6324 18 of 22...
-
Page 19: Display Mode
Display Mode 1. Press MENU to get the On Screen Display (OSD). 2. Select FORMAT. 3. Press the or the to switch the screen aspect ratio. FULL: 16:9 picture is fully displayed. ZOOM: Picture is stretched vertically and horizontally. NORMAL: When 4:3 pictured is displayed on a wide screen, black bands appear on the right and left of the picture 128-6324... - Page 20 Replacement of Remote Controller Battery: Use a small coin to pry open battery holder from compartment. Remove old battery and put in a new one with positive sign “ + “ facing upward. Push compartment into position. Precaution: Dispose of used battery properly. Do not misuse battery by short - circuiting the “...
-
Page 21: Specifications
SPECIFICATIONS LCM5869NP: LCD Panel Size (Diagonal) ......... 5.8" LCD Panel Format ..........1200 x 234 dots LCD Panel Resolution ......... 280,800 pixels LCD Backlight Life ..........10,000 hrs Image Aspect Ratio ..........16:9 Video Input Signal ..........NTSC/PAL Composite Video Power Source ............ - Page 22 36 MONTH LIMITED WARRANTY Applies to Audiovox Mobile Video Products AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 36 months from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
