AOM562A
OPERATION
1. POWER
Press to turn the AOM562A on.
2. SELECT
Press to toggle the active display image between
AV1 and AV2.
3. BRIGHTNESS -/+
Press BRIGHTNESS- to darken the picture.
Press BRIGHTNESS+ to brighten the picture.
4. VOLUME
/
Press VOLUME
to decrease the volume.
Press VOLUME
to increase the volume.
POWER
SELECT
BRIGHTNESS- BRIGHTNESS+
VOLUME
1
2
3
VOLUME
4
