  • Page 1 LCM-5600NP 5.6" Active Matrix LCD Monitor Owner’s Manual...

  • Page 2: Explanation Of Graphic Symbols

    EXPLANATION OF GRAPHIC SYMBOLS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE REFER SERVICING TO QUALIFIED SERVICE PERSONNEL The lightning flash with the arrowhead within a triangle is intended to alert tell the user that parts inside the product are capable of producing an electric shock .

  • Page 3: Specifications

    SPECIFICATIONS 1. Type: Color Liquid Crystal Display (LCD) Monitor 2. Display Screen Size: 5.6 inches (114.2 x 83mm) ( W x H ) Element : TFT LCD Format : 480 (W) x 234 (H) dot Total 112,320 dot 3. Back Light: Cold Cathode Fluorescent Lamp 4.

  • Page 4: Controls And Indicators

    CONTROLS AND INDICATORS FRONT PANEL 1. Power On LED Indicator 2. Power On/Off Switch 3. Remote Control Sensor 4. Picture Select 5. On Screen Adjustment Up Button 6. On Screen Adjustment Down Button...
  • Page 5 To IR Tansmitter (Optional) REAR PANEL To Optional IR Transmitter Part Number IRT456 NOTE(B) 7. Power Input Connector: Red = +12 VDC Black = ground 8. Video Signal Input Connector 9. IR Repeater Connector 10. IR Repeater Transmitter 11. Audio Right Channel Input Connector 12.

  • Page 6: Operation

    IR Wireless Transmitter use (IRT456). IR Wireless Transmitter is a device for transmitting (audio sound without using wires) to IR Headphones. Please contact Audiovox dealers for this optional ac- cessory. OPERATION 1. Connect the monitor power input plug (7) to a DC power source (Red plug +12 VDC, Black plug (-) to ground).

  • Page 7: General Installation Information

    GENERAL INSTALLATION INFORMATION 1. Installation will vary from vehicle to vehicle, as headrests in vehicles are not standard. 2. This unit is intended for installation by professional installers. 3. The kit consists of the screen assembly, a mounting hous- ing, key to remove screen from housing, wiring harness, remote control unit and remote control unit batteries.

  • Page 8: Remote Control Functions

    3. Always seek qualified personnel to perform repairs. Never attempt your own repairs. 4. Do not drop the monitor or expose to strong impacts. 5. Do not expose to direct sunlight for extended periods of time. © 2001 Audiovox Electronics Corp., Hauppauge, NY 128-5973A...
