- Page 1 OWN ER’S MAN UAL DC - X...
- Page 2 The following manual is designed to ensure you enjoy your new World Cat for many years to come. We have made every effort to ensure you and your family are safe, enjoy the unique features of a World Cat, and continue to love the World Cat ride that no other boat company can offer.
-
Page 3: Table Of Contents
1.5 Manual Legend .................................6 Chapter 2: Boat Information ..............................7 Chapter 3: Boat Specifications ..............................8 3.1 280DC-X Standard Boat Specs ..........................8 3.2 280DC-X Standard and Optional Features ......................9 Chapter 4: Safety and Regulations ............................10 4.1 Operator Responsibilities ............................. 10 4.2 Registration ................................10 4.3 Coast Guard Required Safety Equipment ......................10 4.4 Recommended Safety Equipment ........................ - Page 4 5.8.7 Boating Tips ................................21 5.9 Performance Factors ............................. 21 5.9.1 Engine Efficiency ..............................21 5.9.2 Propeller Condition ............................... 21 5.9.3 Weather Conditions .............................. 22 5.9.4 Load ..................................22 5.9.5 Marine Growth ............................... 22 5.9.6 Bottom Paint ................................22 Chapter 6: Systems Information ............................23 6.1 Overview .................................
- Page 5 2020 World Cat 280DC-X Owner’s Manual Chapter 7: Maintenance and Service ..........................34 7.1 Overview ................................. 34 7.2 Gelcoat Maintenance ............................34 7.2.1 Cleaning ................................... 34 7.2.2 Waxing ..................................34 7.2.3 Repair ..................................35 7.3 Bottom Paint ................................35 7.4 Upholstery care - Standard upholstery ......................36 7.5 Trim / Plexiglass / Polyethylene .........................
-
Page 6: Chapter 1: Customer Information
Chapter 1: Customer Information 1.1 Owner's Portfolio To help you enjoy the many features, benefits, and accessories on your new World Cat, we have provided you with the following materials: • World Cat Owner's Manual (model specific) • Vendor Supplied Manuals for various accessories •... -
Page 7: Owner's Responsibilities
It is your responsibility to return your boat to an Authorized World Cat Dealer for warranty work. In the event there is no World Cat dealer within a 100 mile radius of your boating location, it is your responsibility to present the boat to a marine professional in your area as directed and approved by World Cat. -
Page 8: Chapter 2: Boat Information
Chapter 2: Boat Information Please fill out the following information and leave in this manual for reference. This information will be im portant for your Authorized Dealer to provide fast and accurate service. To locate an authorized dealer call 866-485-8899 or email service@worldcat.com. BOAT Model: HIN:... -
Page 11: Chapter 4: Safety And Regulations
When completing registration forms you will be asked for the Hull Identification Number (HIN). On your World Cat, the HIN is located on the starboard side of the transom. This number is unique to your boat and will be important for registering your vessel, as well as communicating with your dealer and our service department. -
Page 12: Recommended Safety Equipment
4.4.1 NMMA Yacht Certification The NMMA seal means your World Cat is certified by the National Marine Manufacturers Association. With this tag, you are assured your fuel system, electrical system, lighting, ventilation, and steering are not only in compliance with US Coast Guard regulations, but also meet the more stringent standards of the NMMA. -
Page 13: Disposal Of Plastics / Dunnage / Garbage
Do not allow individuals under the age of 16 to operate the vessel. Maintain direct supervision of inexperienced op erators. • Ensure that all passengers are safely seated while underway, and are using the hand rails World Cat has provided to remain securely in their seats. -
Page 14: Returning
4.8 Anchoring World Cat supplies an anchor and anchor windlass as standard equipment on the 280DC-X. The anchor we supply is known as a plow style. However, there are several types of anchors available, each designed to operate in specific bottom conditions. -
Page 15: Shallow Water
4.9 Shallow Water Although your World Cat draws a small amount of water for its size, shallow water should be a concern of all boaters. To avoid this hazard, pay particular attention to navigational markers and know the area you are operating in. -
Page 16: Weather
4.10.5 Weather Pay attention to weather patterns. If you find yourself in the path of a storm, seek shelter immediately. If you cannot reach a dock, seek refuge inside the boat while the storm advances. Never get in the water and stay clear of metal components on your boat. -
Page 17: Chapter 5: Performance
2020 World Cat 280DC-X Owner’s Manual Chapter 5: Performance 5.1 Overview This chapter will provide information on the performance characteristics of your catamaran. This is not a substitute for seamanship training or hands-on experience. First time boat owners should use the resources detailed in Chapter 4 to learn proper methods of boat operation. -
Page 18: Steering Controls
The design of a catamaran hull requires a special steering system which features a “liquid tie-bar”, as opposed to the mechanical version used in conventional boats. For this reason your World Cat is equipped with a hydraulic steering system, featuring steering cylinders mounted on each engine and a steering system valve. -
Page 19: Power Steering System Diagram
2020 World Cat 280DC-X Owner’s Manual 5.6 Power Steering System Diagram This is a representation of a typical World Cat power steering system. The lengths of the steering hoses and pigtails will vary depending on the model. 2018 World Cat 280CC-X Owners Manual... -
Page 20: Power Steering System - Bleeding Instructions
NOTICE World Cat strongly suggests you have your dealer or trained marine technician perform routine maintenance or repairs on your steering system. Improper repairs may result in impaired or unresponsive steering, which could pose risk of damage or injury. -
Page 21: Handling Characteristics
Speed and economy suffer however, since more of the hull is submerged. World Cat has taken the best characteristics of these two designs and incorporated them in the VectorFlo™ hull. Our proven design provides a superior ride, excellent handling characteristics in a variety of conditions, and speed with economy of operation. -
Page 22: Keep The Boat Level
Experience is the best way to determine the handling characteristics of your catamaran. Operating the boat in multiple sea conditions and under various loads will help you predict how the boat will perform in any situation. World Cat provides the following recommendations regarding the performance of your catamaran: •... -
Page 23: Weather Conditions
2020 World Cat 280DC-X Owner’s Manual 5.9.3 Weather Conditions Barometric pressure and humidity can affect the output of your engines. For example, on an extremely hot and humid day, your engine can experience as much as a 10 percent loss in horsepower. Although you should monitor your engines’... -
Page 24: Chapter 6: Systems Information
Chapter 6: Systems Information 6.1 Overview This chapter will provide you with basic information for all the systems on your boat. Understanding this information is imperative, as it directly contributes to the safety and enjoyment of your trips on the water. If you need further information on any of these systems talk with your dealer. -
Page 25: Fuel System
2020 World Cat 280DC-X Owner’s Manual 6.3 Fuel System Due to the nature of the hull design, your World Cat is equipped with a port and starboard fuel system. These systems act independently, providing fuel to the engine on their respective side. Tanks are constructed of polyethylene material to prevent corrosion. -
Page 26: Fuel Distribution System
6.3.4 Fuel Distribution System The fuel is delivered from the tank to the engine through the “Integrated Fuel Demand Valve” (IFDV), anti-siphon valve, and the fuel line. The IFDV prevents the built up pressure inside the tank from being transferred to the engine while still allowing fuel to flow as the engine requires it for operation. The anti- siphon valve is a safety feature designed to prevent the fuel from siphoning out of the tank if the fuel line were to be cut or broken below the level of the fuel in the tank. -
Page 27: Pressure Relief Fuel System Diagram
2020 World Cat 280DC-X Owner’s Manual 6.3.6 Pressure Relief Fuel System Diagram 6.3.7 Troubleshooting Tips Possible Failures Loss of prime on the engine and / or fuel starvation: • Engine stalls out • Engine runs lean • Engine does not draw fuel properly Find possible leakage points and take corrective action: •... -
Page 28: Ethanol-Blended Fuel
6.6 Battery System Your World Cat is equipped with three standard batteries. Two additional batteries are optional, depending on accessories. Two of the batteries are Type 27 “cranking batteries”; the third is a Type 31 “house” battery. -
Page 29: Voltage Sensitive Relays (Vsr)
2020 World Cat 280DC-X Owner’s Manual The photo above show 6.6.2 Voltage Sensitive Relays (VSR) There are two voltage sensitive relays (VSR) on the distribution panel. Once the engines are cranked, the alternator sends electrical current back to the cranking batteries to recharge them. -
Page 30: Battery Selection
6.6 Battery Selection World Cat supplies the original batteries onboard your vessel. For this model we use both Group 27 and Group 31 batteries. In the event of a failure, replacements must be of equal size and specifications (see below):... -
Page 31: Wiring And Circuit Protection
2020 World Cat 280DC-X Owner’s Manual 6.8 Wiring and Circuit Protection Your World Cat is wired using marine grade tin coated copper wire, instead of standard copper wire. Tin coated copper is manufactured to withstand the harsh saltwater environment better than standard copper, which is used for residential applications. -
Page 32: Accessories
They are controlled through the mechanical push button switches on the dash panel. 6.10.6 Docking Lights The bow of your World Cat 280DC-X is equipped with integrated high-intensity LED docking lights, which are operated from the main dash control panel. These lights can help with maneuverability in low-light conditions while docking. -
Page 33: Marine Head Switch
The windlass breaker is located on the battery management panel. The 280DC-X integrated windlass system is made possible by an advanced feed system for the anchor rode. Once entering the bow of the boat, the anchor rode is routed to the starboard side of the boat into a hidden windlass. -
Page 34: Engines / Gauges
The intake and discharge of water is integral to several of the features and accessories provided on your boat, including livewells, fishboxes, sanitation devices, and water systems. World Cat installs the plumbing components for these systems using high quality marine hoses and stainless clamps. However, this does not eliminate the need for routine checks of plumbing components or connections. -
Page 35: Chapter 7: Maintenance And Service
This chapter provides basic information for maintaining the original appearance and dependable performance of your World Cat. Although your vessel is constructed of the finest materials available, the harsh saltwater environment and other factors, including geography and usage rate, will affect its finish and function over time. -
Page 36: Repair
This will help to prevent, but not eliminate, gelcoat blistering on the hull, which is not warranted by World Cat. Your dealer can provide information on bottom painting to protect against environmental toxins in your area. Anti-fouling paints are made to dissolve over time, so inspect and... -
Page 37: Upholstery Care - Standard Upholstery
2020 World Cat 280DC-X Owner’s Manual 2018 World Cat 280CC-X Owners Manual 7.4 Upholstery Page 52... -
Page 38: Trim / Plexiglass / Polyethylene
7.9 Cockpit Drains Your World Cat has five drains located in the cockpit, two on both the starboard and port sides and one forward of the helm seat. These drains are designed to quickly evacuate the cockpit should the boat become swamped. -
Page 39: Winterization
2020 World Cat 280DC-X Owner’s Manual 7.11 Winterization • Routine maintenance checks should be performed prior to each trip in accordance with Chapter 1, but a broader assessment should be done before winterizing your catamaran and prior to the first trip of the season. -
Page 40: Maintenance Schedule
7.12 Maintenance Schedule Maintenance Each Use Weekly Monthly Quarterly Yearly As Needed Clean hull below the waterline Bottom paint the hull Check / replace sacrificial anodes Wash boat hardware and canvas Wax exterior gelcoat Clean & protect hardware Clean exterior upholstery Clean cabin &... -
Page 41: Windlass (Winch) Safety Guidelines
2020 World Cat 280DC-X Owner’s Manual 7.13 Windlass (Winch) Safety Guidelines This section provides some universal guidelines on winch safety and correct anchoring procedures. Only persons who are completely familiar with the controls and those who have been fully made aware of the correct use of the windlass should be allowed to use it. -
Page 42: Anchoring Procedure
7.14 Anchoring Procedures Books on seamanship all have a section on how to properly and safely anchor your boat. The summary below is intended only as a basic guide to acceptable anchoring technique. Leading windlass manufacturers recommend that correct anchoring technique be researched and understood thoroughly before going to sea. Tips and Guidelines: •... -
Page 43: Maintenance Log
2020 World Cat 280DC-X Owner’s Manual 7.15 Maintenance Log Service Date Engine Hours Dealer Service / Repairs... -
Page 44: Chapter 8: Hurricane / Moored / Anchored Preparations
Chapter 8: Hurricane Preparedness Customer Checklist Equipment To Be Kept On Board: □ Chafing gear □ Two sufficient anchors with 300’ or □ Fenders more oversized rode □ Flashlight with spare batteries □ Battery-operated radio Check Monthly: □ Exterior lights operable □... - Page 45 2020 World Cat 280DC-X Owner’s Manual Moored Boat Preparations Make Plans To Have Someone Pick You Up From Your Boat Before The Storm Arrives □ Strip all removable items, including spare rigging □ Clear self-bailing cockpit drains □ Close all through hull fittings □...
- Page 46 Anchored Boat Preparations Make Plans To Have Someone Pick You Up From Your Boat Before The Storm Arrives □ Strip all removable items, including spare rigging □ Clear self-bailing cockpit drains □ Close all through-hull fittings □ Remove portable fuel and oil storage containers □...
-
Page 47: Chapter 9: Model Year 2020 Warranty Policy
Hull Identification Number (“HIN”), which is unique to every boat and is located on the stern. It is important to understand what a limited warranty does. It is an agreement between you and World Cat that your vessel will be free from substantial defects in material and workmanship for a specified length of time. - Page 48 2020 MODEL YEAR LIMITED WARRANTY World Cat will not be responsible for damage or to continue to repair or replace your boat or any part of it if your continued use prior to repair causes additional damage; If you believe a claim has been denied in error or the dealer has performed the warranty repairs in an unsatisfactory manner, the owner must notify the World Cat Customer Service Department in writing within thirty (30) days of the repair attempt at the address listed below under “Notice.”...
- Page 49 World Cat will discharge its obligations under this warranty as quickly as possible, but we cannot guarantee any specific completion date. This is due to the potential complexity of the repair or the availability of parts from sources over which World Cat has limited control. You agree that the time for repairs does not include time spent waiting for parts or the time your boat may end up stored at our factory or at a dealer for your convenience or due to scheduling.
-
Page 50: Chapter 10: 280Dc-X Operation
10.1.1 Battery Layout and Management Your 280DC-X is equipped with three batteries, which are located in the aft starboard bilge area. A cranking battery is installed on each side, and a dedicated house battery is installed in the center. Wire leads run through the hull harness to the battery management panel which is below the helm seat. -
Page 51: Freshwater System
When open, the handle will be parallel to the valve. In the closed position the handle is perpendicular to the valve (see picture above). World Cat valve (see picture above). World Cat recommends that the seacocks remain in the closed... -
Page 52: Livewell System
60psi. The pump will cycle on and off as needed to maintain this pressure. Most owners leave the pump in the on position throughout the day and use the system when necessary. On the 280DC-X the raw water pump is switched on by a push button mechanical switch located on the dash area. The 280DC-X... -
Page 53: Wiper With Rinse
2020 World Cat 280DC-X Owner’s Manual 10.1.8 Wiper with Rinse (Optional) The windshield wiper switch on the dash of the 280DC-X allows you to operate the windshield wiper system on the vessel if this optional feature was purchased. This switch is a pushbutton style switch and has three buttons located on the face of the switch as well as three LED lights that show the user what mode and speed it is currently operating at. -
Page 54: Initial Start Up
10.1.9.1 Initial Start Up On each trip, prior to using the head, complete the following steps: • Turn on the freshwater system. • Fill 1/3 of the bowl with water using the lower switch on the control panel. • Hold down the flush switch for 5 seconds to evacuate the bowl and refill with water. 10.1.9.2 Normal Use Use the steps below for normal operation: •... -
Page 55: Anchor Windlass
Outriggers enhance the fishability of your catamaran and can be a great asset when hunting a trophy catch. World Cat offers Taco™ outriggers as an option. The units are mounted on the fiberglass hardtop and operated using the handles above and outboard of the walkthrough. Use the information provided in section 7.6 to maintain the aluminum on the outriggers and grease the telescoping joints frequently to prevent... -
Page 56: Electronics Package
The hydraulic pumps and the PCM are mounted on the 280DC-X in the starboard aft mechanical room. The PCM is protected by a 50 amp fuse for the port and starboard sides and these are located beside the PCM. The Smart Cylinders are mounted in front of each engine similar to a standard hydraulic steering cylinder. -
Page 57: Sureshade Pull-Out Boat Shade
2020 World Cat 280DC-X Owner’s Manual 10.3.9 SureShade Pull-Out Boat Shade The SureShade is mounted underneath the fiberglass hardtop in the aft cockpit of the vessel. To operate the shade, make sure the vessel has come to a complete rest. You will need to rotate the hand crank located in the starboard aft upper corner of the hardtop. -
Page 58: System Diagrams
10.4 System Diagrams 10.4.1 Battery Panel Wiring Diagram DEUTSCH 10RD CUSTOMER: POWERCAT GROUP Pacer Marine TITLE: PANEL, BATTERY MANAGEMENT CUSTOME MODEL: 280DC 20300398 Engineering Inc. PART NO. : PCG-006-B ZP-PCG-066APC PACER MRP#: ZP#: 6/12/2017 CREATOR: M.HERRERA PAGE: 1 OF 1 DATE:... -
Page 59: Dash Wiring Diagram
2020 World Cat 280DC-X Owner’s Manual 10.4.2 Dash Wiring Diagram FROM STBD HULL HARNESS DEUTSC H 14BL/RD "165 GNNL LTS RED" 16 ORG/BLK LABEL: "PORT WIPER HIGH" 16 ORG: LABEL "PORT WIPER LOW" 14RD "PP4 LVWLL SYS PWR" DASH GRD 14RD "66 U/W LTS PWR"... -
Page 60: Hardtop Panel Wiring Diagram
10.4.3 Hardtop Panel Wiring Diagram... -
Page 61: Inverter Diagram
2020 World Cat 280DC-X Owner’s Manual 10.4.4 Inverter Diagram... -
Page 62: Freshwater And Marine Head Systems Diagram
10.4.5 Freshwater and Marine Head Systems Diagram... -
Page 63: Raw Water And Livewell Systems Diagram
2020 World Cat 280DC-X Owner’s Manual 10.4.6 Raw Water and Livewell Systems Diagram... -
Page 64: Notes
Notes... - Page 65 2020 World Cat 280DC-X Owner’s Manual Notes...
- Page 66 DC - X 07.2018 © 2019 World Cat | All rights reserved | Tarboro, NC | WorldCat.com...
