- Page 1 CLUX-C61C 6 by 1 HDMI V1.3 Switcher with CEC Operation Manual CLUX-C61C...
-
Page 2: Copyright Notice
Cypress Technology assumes no responsibility for any inaccuracies that may be contained in this document. Cypress also makes no commitment to update or to keep current the information contained in this document. -
Page 3: Safety Precautions
Trademark Acknowledgments All products or service names mentioned in this document may be trademarks of the companies with which they are associated. Safety Precautions Please read all instructions before attempting to unpack or install or operate this equipment, and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: ... -
Page 4: Table Of Contents
Table of Contents Introduction …………………………………………........ Applications......…………………………………………… Package Contents.....………………………………………………. System Requirements ....………………………………….….. Features ......……………………………………………… Specifications ............……………………… Operation Controls and Functions....…………………..…….. 7.1 Front Panel....……..………......………….. 7.2 Rear Panel....……..………......………….. Remote Control................... RS-232 Protocol................... 9.1 Pin Definitions....…..………......………….. 9.2 RS-232 Commands....………......………….. Connection and Installation.............. -
Page 5: Introduction
1. Introduction This is a high performance HDMI switcher that allows for various HDMI sources to share one HDTV display. This device features CEC control functions and supports deep color, xvYCC and RS-232 control. Simply press one button select your desired HDMI source to display on the HDTV or use remote control to control your sources from a distance. -
Page 6: Features
5. Features HDMI 1.3 and HDCP 1.1 compliant Supports deep color display RGB/YCbCr 4:4:4 24/30/36 bits Supports color space YCbCr 4:2:2 16/20/24 bits Supports high definition audio – Dolby Digital True HD and DTS-HD ® ® Signal Enhancement feature allows signal quality improvement after ... -
Page 7: Specifications
6. Specifications Frequency Bandwidth 2.25Gbps(single link) Input Ports 6 x HDMI female ports (Type A connector) Output Ports 1 x RS232 1 x HDMI female port (single link) Color Space YCbCr 4:2:2 16/20/24 bits Deep Color RGB / YCbCr 4:4:4 24/30/36 bits ESD Protection Human body model: ±... -
Page 8: Operation Controls And Functions
7. Operation Controls and Functions 7.1 Front Panel CLUX-C61C 6x1 HDMI v1.3 Switcher xvYCC HD Audio Deep Color HDMI IN 1 INPUT POWER ON/Bypass ① ② ③ ④ ⑤ ① Remote control sensor. ② HDMI IN 1~2: These slots connect to the HDMI/DVI output ports of your source equipments. -
Page 9: Rear Panel
7.2 Rear Panel RS-232 DC 5V HDMI IN HDMI OUT ① ② ③ ④ ① HDMI OUT: This is the slot where you connect the HDMI output of the switcher to the HDMI input of your display using a HDMI cable. ②... -
Page 10: Remote Control
8. Remote Control ② ① Power: This button turns on the unit or set the device POWER to standby mode. ① ② CEC: This button turns on the CEC function of the unit or set it to bypass mode. Please refer to section 6.1 for more details. -
Page 11: Rs-232 Commands
8.2 RS-232 Command Command Code Function “ I ” + “ 1 ” PORT 1 ON “ I ” + “ 2 ” PORT 2 ON “ I ” + “ 3 ” PORT 3 ON “ I ” + “ 4 ” PORT 4 ON “... -
Page 12: Connection And Installation
9. Connection and Installation DVD2 DVD1 ° ° POWER INPUT CR-63 DVD1 DVD3 LCD TV DVD2... - Page 13 Acronyms Acronym Complete Term Consumer Elelctronics Control Digital Theater System HDCP High-bandwith Digital Content Protection HDMI High-Definition Multimedia Interface HDTV High-Definition Television Red Green Blue SVGA Super Video Graphics Array SXGA Supper Extended Graphics Array UXGA Ultra Extended Graphics Array Video Graphics Array Extended Graphics Array...
- Page 15 20090703 MPM-CLUXC61C...
- Page 16 CYPRESS TECHNOLOGY CO., LTD. Home page: http://www.cypress.com.tw...
