NetXtreme II
T O
EAMING AND
• Checksum Offload
• IEEE 802.1p QoS Tagging
• Large Send Offload
• TCP Offload Engine (TOE)
• Jumbo Frames
• IEEE 802.1Q VLANs
• Wake On LAN
• Preboot Execution Environment
Before creating a team, adding or removing team members, or changing advanced settings of a team member, make sure
each team member has been configured similarly. Settings to check include VLANs and QoS Packet Tagging, Jumbo
Frames, and the various offloads. Advanced adapter properties and teaming support are listed in
Adapter Properties
Checksum Offload
IEEE 802.1p QoS Tagging
Large Send Offload
TCP Offload Engine (TOE)
Jumbo Frames
IEEE 802.1Q VLANs
Wake on LAN
Preboot Execution environment (PXE)
a
All adapters on the team must support this feature. Some adapters may not support this feature if ASF/IPMI is also enabled.
b
Must be supported by all adapters in the team.
c
Only for Broadcom adapters.
d
As a PXE sever only, not as a client.
A team does not necessarily inherit adapter properties; rather various properties depend on the specific capability. For
instance, an example would be flow control, which is a physical adapter property and has nothing to do with BASP, and will
be enabled on a particular adapter if the miniport driver for that adapter has flow control enabled.
NOTE: All adapters on the team must support the property listed in
property.
Page 36

Teaming and Other Advanced Networking Properties

A
THER DVANCED
Table 7: Advanced Adapter Properties and Teaming Support
Bro adco m C orp or atio n
N P
ETWORKING
Supported by Teaming Virtual Adapter
Yes
No
a
Yes
b, c
Yes
b
Yes
c
Yes
No
d
Yes
Table 7
User Guide
January 2010
ROPERTIES
Table 7.
in order for the team to support the
Document ENGSRVT52-CDUM100-R
