NetXtreme II
P D
ERFORMING
At the MS-DOS prompt, type uxdiag (for BCM5706/BCM5708/BCM5709 network adapters) or uediag (for BCM57710
network adapters) followed by the command options. The uxdiag command options are shown in
command options are shown in
C:\>uxdiag -c 1 -t b
NOTE: You must include uxdiag or uediag at the beginning of the command string each time you type a command.
Command Options
uxdiag
uxdiag -c <devnum>
uxdiag -cof
uxdiag -F
uxdiag -fbc <bc_image>
uxdiag -fib <ib_image>
uxdiag -fibc
uxdiag -fibp
uxdiag -fipmi <ipmi_image>
uxdiag -fmba <mba_image>
uxdiag -fncsi <ncsi_image>
uxdiag -fnvm <raw_image>
uxdiag -fump <ump_image>
uxdiag -help
uxdiag -I <iteration num>
uxdiag -idmatch
uxdiag -log <file>
uxdiag -mba <1/0>
uxdiag -mbap <n>
Page 228 Performing Diagnostics
IAGNOSTICS
Table 2. For example, to run all diagnostic tests on adapter #1 except Group B tests:
Table 1: uxdiag Command Options
Description
Performs all tests on all Broadcom NetXtreme II adapters in your system.
Specifies the adapter (devnum) to test. Use all in place of a specific device number to test
all adapters.
Allows tests to continue after detecting a failure.
Forces an upgrade of the image without checking the version.
Specifies the bin file to update the bootcode.
Specifies the bin file for iSCSI boot.
Programs the iSCSI configuration block. Used only with -fib <ib_image>.
Programs the iSCSI configuration software. Used only with -fib <ib_image>.
Specifies the bin file to update IPMI firmware.
Specifies the bin file to update the MBA.
Specifies the bin file to update the NCSI firmware.
Programs the raw image into NVM.
Specifies the bin file to update UMP firmware.
Displays the Broadcom NetXtreme II User Diagnostics (uxdiag) command options.
Specifies the number of iterations to run on the selected tests.
Enables matching of VID, DID, SVID, and SSID from the image file with device IDs. Used
only with -fnvm <raw_image>.
Logs the test results to a specified log file.
Enables/disables Multiple Boot Agent (MBA) protocol.
1 = Enable
0 = Disable
Sets the MBA boot protocol.
0 = PXE
1 = RPL
2 = BOOTP
3 = iSCSI_Boot
Bro adco m C orp or atio n
User Guide
January 2010
Table 1 and the uediag
Document ENGSRVT52-CDUM100-R
