NetXtreme II
set of library functions to enable the communications between either miniport drivers or intermediate drivers and the protocol
stack. The protocol stack implements IP, IPX and ARP. A protocol address such as an IP address is assigned to each
miniport device instance, but when an Intermediate driver is installed, the protocol address is assigned to the virtual team
adapter and not to the individual miniport devices that make up the team.
The Broadcom supplied teaming support is provided by three individual software components that work together and are
supported as a package. When one component is upgraded, all the other components must be upgraded to the supported
versions. Table 3 describes the four software components and their associated files for supported operating systems.
Software
Broadcom Name
Component
Virtual Bus Driver
(VBD)
Miniport Driver Broadcom Base Driver
Intermediate Broadcom Advanced
Driver Server Program
(BASP)
Configuration Broadcom Advanced
User Interface Control Suite 3
(BACS)
Page 22 Executive Summary
Table 3: Broadcom Teaming Software Component
Network Adapter/Operating System
BCM5706, BCM5708, BCM5709
BCM5706, BCM5708, BCM5709
BCM57710, BCM57711
BCM57710, BCM57711
Windows 2000 Server (NDIS 5.0)
Windows Server 2003 (NDIS 5.1)
Windows Server 2003 (NDIS 5.1)
Windows Server 2003 (NDIS 5.2)
Driver supports Layer 4
Windows Server 2003 (NDIS 5.2)
Driver supports Layer 4
Windows Server 2008 (NDIS 6.0)
Windows Server 2008 (NDIS 6.0)
Windows Server 2008 R2 (NDIS 6.0)
Windows 2000 Server
Windows Server 2003
Windows Server 2003
Windows Server 2008
Windows Server 2008 R2
–
Bro adco m C orp or atio n
User Guide
January 2010
System Windows File
Architecture Name
32-bit bxvbdx.sys
64-bit bxvbda.sys
32-bit evbdx.sys
64-bit evbda.sys
bxnd50x.sys
32-bit bxnd51x.sys
64-bit bxnd51a.sys
32-bit bxnd52x.sys
64-bit bxnd52a.sys
32-bit bxnd60x.sys
64-bit bxnd60a.sys
64-bit bxnd60a.sys
32-bit baspw2k.sys
32-bit baspxp32.sys
64-bit basamd64.sys
32-bit, 64-bit basp.sys
64-bit basp.sys
– bacs.exe
Document ENGSRVT52-CDUM100-R
