2. In the Options window, select Appearance.
3. Choose the appearance settings. Click Apply to set changes. Click OK to set changes and close the Options window.
To reset the interface to the default appearance
1. From the Tools menu, select Options.
2. In the Options window, select General.
3. Click Restore Default.
4. Close and then restart BACS 3.
V V S
IEWING ITAL IGNS
The Vital Signs section of the Information tab has useful information about the network adapters that are installed in your
system, such as the link status of the adapter and general network connectivity.
To view Vital Signs information for any installed network adapter, click the name of the adapter listed in the Device
Management pane, then click the Information tab.
• If the Information tab is not visible, then from the View menu, select Navigate, then Device Management, and then
Information.
• If the Vital Signs section within the Information tab is not visible, then from the Context View tab on the right side of
the window, select Information and then select Vital Signs.
NOTES:
• Information about Broadcom network adapters may be more comprehensive than information about network
adapters made by others.
• Some information may not be available for all Broadcom network adapters.
