MULTIBAND P25
AIRBORNE TRANSCEIVER
MODEL TDFM-600/6000
Installation and
Operating Instructions
Til Document No.
01RE293
Rev. F
Issue 3
December 2004
Technisonic Industries Limited
240 Traders Blvd, Mississauga, Ontario L4Z 1W7
Tel:(905)890-2113 Fax:(905)890-5338
www.til.ca

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDFM-600 and is the answer not in the manual?

Questions and answers

Related Manuals for Technisonic Industries Limited TDFM-600

Summary of Contents for Technisonic Industries Limited TDFM-600

  • Page 1 MULTIBAND P25 AIRBORNE TRANSCEIVER MODEL TDFM-600/6000 Installation and Operating Instructions Til Document No. 01RE293 Rev. F Issue 3 December 2004 Technisonic Industries Limited 240 Traders Blvd, Mississauga, Ontario L4Z 1W7 Tel:(905)890-2113 Fax:(905)890-5338 www.til.ca...
  • Page 2 Changes or modifications not expressly approved by Technisonic Industries could void the users authority to operate the equipment. WARRANTY INFORMATION The Model TDFM-600/6000 Transceiver is under warranty for one year from date of purchase. Failed units caused by defective parts, or workmanship should be returned to: Technisonic Industries Limited...
  • Page 3 Summary of DO-160C Environmental Testing for Technisonic Model TDFM-600 and 6000 Transceiver. Conditions Section Description of Conducted Tests Temperature and Altitude Equipment tested to categories C4 and D1. Vibration Equipment is tested without shock mounts to categories B, M and N.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Paragraph Title Page SECTION 1 GENERAL DESCRIPTION Introduction ....................1-1 Description ....................1-1 Model Variation ..................1-1 Technical Summary..................1-3 SECTION 2 OPERATING INSTRUCTIONS General ..................... 2-1 Front Panel ....................2-1 Power Switch .................... 2-2 Knob......................2-2 Soft Keys and HOME ..................
  • Page 5 LIST OF TABLES Table No. Title Page 25-pin D Connections.................. 3-2 LIST OF ILLUSTRATIONS Figure No. Title Page Operator’s Controls – TDFM-600/6000 ............2-1 Operator’s Controls – TDFM-636 ..............2-2 Outline Drawing ..................3-1 Wiring Connections and notes ..............3-5...

  • Page 6: General Description

    RF modules are installed. DESCRIPTION The TDFM-600/6000 series of transceivers are airborne multi-band radios capable of operation in conventional analog and P25 digital FM systems, SmartNet/SMART ZONE and P25 9600 trunking systems. Type I RF modules are available in VHF, UHFLO, UHFHI and 800 MHz bands. Type II RF modules support additional optional features not available in type I modules and are also available in VHF, UHFLO, UHFHI and 700/800 MHz.
  • Page 7 P200 series project numbers are used specified in ascending order. in transceivers with type I modules *Note: 0 used when only one module installed. TDFM-600 Model Variations with type II Modules *TDFM-6X0, P/N 011210-3-6X0/PYYY/28 GREEN display and 28 Volt back lighting. *TDFM-6X0, P/N 011210-3-6X0/PYYY/5 GREEN display and 5 Volt back lighting.
  • Page 8 All model variations are provided with 28 Volt back lighting unless a specific request is made for 5 Volt AC operation. NV (Night Vision) compatible option is only available with green display. TECHNICAL CHARACTERISTICS Specification Characteristic Model Designation: TDFM-600/6000 Physical Dimensions: Approx. 8" X 3" X 5.75" Weight: 4.2 lbs. (1.9 kg) Operating Temperature Range: -30°C to +60°C...
  • Page 9 TECHNICAL CHARACTERISTICS (continued) Receiver section Sensitivity in uV: *Digital 1% BER (12.5kHz) 0.35 0.35 0.45 *Digital 5% BER (12.5kHz) 0.25 0.25 0.25 **Analog with 12dB SINAD 0.25 0.25 0.25 Selectivity in dB: 25 kHz Channel 12.5 kHz Channel Intermodulation (dB) * ** Type II Modules RF Output Power: 1 or 7 Watts (VHF)

  • Page 10: Operating Instructions

    This allows for separate and simultaneous operation on each of the bands just like having 2 or 3 separate radios. If combined operation is desired, a Technisonic AMS-6000 audio mode selector may be used ahead of the audio controller. FRONT PANEL Refer to the diagrams below: Figure 2-1 Front panel Controls – TDFM-600/6000 Series Transceivers (not including TDFM-636)

  • Page 11: Power Switch

    Figure 2-2 Front panel Controls – TDFM-636 Transceiver Only POWER SWITCH To switch the transceiver on, press and hold the left most knob until the radio powers up. The display will show TECHNISONIC and the software version installed followed by the model number as determined by which RF modules are installed.

  • Page 12: Soft Keys And Home

    SOFT KEYS AND HOME The transceiver has three soft keys which assume the function shown above them on the display. The functions displayed depend on how the module was programmed with the radio service software (CPS)™. Functions can be different on a channel by channel basis as well. These may include: ZONE - Pressing this function will prompt you for a new zone number which can be entered directly or scrolled using the UP and DN keys.
  • Page 13 It is possible to use Motorola’s Customer Programming Software (CPS™) to alter the default keypad settings of the TDFM-600/6000 series radios. However if custom key settings are chosen it will not be possible for Technisonic to help the Pilot or other Radio User through operational difficulties. These questions will have to be referred to the Radio System Administrator responsible for customising the settings.

  • Page 14: Mup And Mdn Keys

    The following settings must be programmed for each mode in a Trunked (P25 9600, SmartNet or SMARTZONE) Radio: System Type TG Strapping System ID Zone Individual ID Scan List Coverage Type Scan Type Affiliation Type Interconnect Control Channel 1 Phone Display Format Control Channel 2 Private Call Talkgroup 1...

  • Page 15: Display

    CPS™. Follow the instructions supplied with the CPS™ and RIB. The radio cable supplied with the RIB will not connect to the TDFM-600/6000, therefore you will need to fabricate or purchase the type I programming cable, P/N 013524-1.
  • Page 16 Programming cables for units with Type II modules The TDFM-600/6000 series transceivers that employ type II modules do not require a Smart RIB box, AC power pack or computer RIB cable. A Technisonic PC-6000 II programming cable, P/N 047366-1 and Motorola CPS Programming software, P/N RVN4186 (Latest revision) is all that is required to program transceivers with type II modules.

  • Page 17: 2.15 Configuration Menu

    2.15 CONFIGURATION MENU Some features of the TDFM-600/6000 transceiver can be configured to the user’s preference. To enter the configuration menu, turn the unit on while simultaneously pressing the F4, ESW and TSW keys. Hold the keys until the display reads ‘Configuration Menu’. The configurable items are: Knob default Rotating the left most knob will toggle the condition between volume and channel.

  • Page 18: 2.16 Flash Upgrade Mode

    2.16 FLASH UPGRADE MODE On occasion it may be required to flash upgrade one or more of the modules in the radio to change or add new features. This can be done using the Motorola RIB box and software supplied in a Motorola flash upgrade kit.
  • Page 19 The following is a list of the standard PL tones: Number Tone Number Tone Number Tone 67.0 103.5 156.7 71.9 107.2 162.2 74.4 110.9 167.9 77.0 114.8 173.8 79.7 118.8 179.9 82.5 123.0 186.2 85.4 127.3 192.8 88.5 131.8 203.5 91.5 136.5 94.8...

  • Page 20: Installation Instructions

    INSTALLATION The TDFM-600/6000 Transceiver is designed to be dzus mounted and should be installed in conjunction with an IN-600 installation kit. See figure 3-1 for an outline drawing of the unit with dimensions to facilitate the installation.
  • Page 21 FIGURE 3-1 Outline Drawing for Model TDFM-600/6000...

  • Page 22: Pin D Connections

    Panel Backlighting Note: The TDFM-600/6000 has one set of Mic, Audio and PTT lines for each RF band installed. Single band units will only use Mic 1, Audio 1 and PTT 1. Dual band units will use Mic 1 & 2, Audio 1 & 2, and PTT 1 &...
  • Page 23 3.10 MIC 1, 2 AND 3 - PINS 3, 6 AND 9 The microphone input signals shall be connected using shielded wire with the shield connected to ground (pin 1 or 14). It is recommended for best results to leave the other end of the shield floating to prevent ground currents unless you are connecting to an audio panel with floating hi and lo inputs (like the Technisonic A710 or A711 series).

  • Page 24: Wiring Connections And Notes

    FIGURE 3-2 Wiring connections and notes for the TDFM-600/6000 Transceiver...
  • Page 25 3.18 POST INSTALLATION EMI TEST PURPOSE The purpose of this test is to identify any interference that the TDFM-600/6000 transceiver may cause with existing aircraft systems. TEST CONDITIONS The TDFM-600/6000 transceiver should be installed and function tested. The antenna VSWR should be checked.
  • Page 26 Determine if the image frequency for the VHF Comm falls within the range of the TDFM- 600/6000. If so, select a set of frequencies that will cause the TDFM-600/6000 to be set as close as possible to the image frequency. Any one of the many possible sets will suffice.
  • Page 27 Determine if the image frequency for the VOR/ILS Nav falls within the range of the TDFM- 600/6000. If so, select two sets of frequencies that will cause the TDFM-600/6000 to be set as close as possible to the image frequency. Choose one set in the localizer frequency range and one in the VOR frequency range.
  • Page 28 140.0000 / 172.0000 108.100 140.0000 / 171.9000 Image: NOTES: Modulate the TDFM-600/6000 transmitter on the following frequencies for at least 20 seconds. Observe the Glideslope displays. Look for any movement of flags or needles on the navigation display. FREQUENCIES RESULTS...
  • Page 29 Operate the TDFM-600/6000 transmitter on the following frequency for at least 20 seconds. Observe the Transponder for any spurious replies or loss of reply to test set. FREQUENCIES TRANSPONDER #1 TRANSPONDER #2 TDFM-600/6000 PASS FAIL PASS FAIL 512 MHz (type I)
  • Page 30 Modulate the TDFM-636 on the following two frequencies simultaneously. Monitor the HF on the given frequency. Listen for any noise or detected audio signals on the HF comm. FREQUENCIES RESULTS HF 1 TDFM-636 PASS FAIL 12.0000 MHz 160.0000 / 172.0000 FREQUENCIES RESULTS HF 2...
  • Page 31 Observations: Perform a coupled ILS approach to the aircraft's certified limits. Modulate the TDFM-600/6000 transmitter on the above frequencies for at least 20 seconds. Observe any effect on the autopilot. Repeat for second flight director/autopilot if equipped.
  • Page 32 List the power plant, fuel and other electric instruments in the chart provided and note any anomalies that occur while transmitting. Assess the results. STEP SYSTEM PASS FAIL NOTES Com 1&2 (UHF Lo, UHF Hi, and 800 MHz) Transponder & Encoder (VHF, UHF Lo, and 800 MHz) ADF 1 &...
  • Page 33 STEP SYSTEM PASS FAIL NOTES Amps Bus Voltage Fuel % Torque % Annunciators Digital Clock Oil Pressure DME 1&2 (VHF, UHF Lo, and 800 MHz) GPS 1&2 (UHF Lo and 800 MHz) 3-14...
  • Page 34 STEP SYSTEM PASS FAIL NOTES NOTES: 3-15...
