Technisonic Industries Limited TFM-566 Installation And Operating Instructions Manual

Vhf/vhf lo fm airborne transceiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VHF/VHF LO FM
AIRBORNE TRANSCEIVER
MODEL TFM-566
(P/N's 031217-1,3)
Installation and
Operating Instructions
Til Document No.
03RE318
Rev. B
September 2003
Technisonic Industries Limited
240 Traders Boulevard, Mississauga, Ontario L4Z 1W7
Tel:(905)890-2113 Fax:(905)890-5338
www.til.ca

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TFM-566 and is the answer not in the manual?

Questions and answers

Related Manuals for Technisonic Industries Limited TFM-566

Summary of Contents for Technisonic Industries Limited TFM-566

  • Page 1 VHF/VHF LO FM AIRBORNE TRANSCEIVER MODEL TFM-566 (P/N’s 031217-1,3) Installation and Operating Instructions Til Document No. 03RE318 Rev. B September 2003 Technisonic Industries Limited 240 Traders Boulevard, Mississauga, Ontario L4Z 1W7 Tel:(905)890-2113 Fax:(905)890-5338 www.til.ca...
  • Page 2 Changes or modifications not expressly approved by Technisonic Industries could void the user’s authority to operate the equipment. WARRANTY INFORMATION The Model TFM-566, Transceiver is under warranty for one year from date of purchase. Failed units caused by defective parts, or workmanship should be returned to: Technisonic Industries Limited...
  • Page 3 Summary of DO-160C Environmental Testing for Technisonic Model TFM-566, VHF and VHF Low Transceiver: Conditions Section Description of Conducted Tests Temperature and Altitude Equipment tested to categories B2 and Vibration Equipment is tested without shock mounts to categories B, M and N.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS Paragraph Title Page SECTION 1 GENERAL DESCRIPTION Introduction ..........1-1 Description .
  • Page 5 LIST OF TABLES Table No. Title Page 9-pin D and 15-Pin D Connections ....... . 3-3 LIST OF ILLUSTRATIONS Figure No.

  • Page 6: General Description

    138-150 MHz portion of the band. If the TFM-566 transceiver is used in CANADA, VHF operation is restricted to the following sub bands: 138-144, 148-148.99, 149.005-150.005 and 150.05-174 MHz.
  • Page 7 TECHNICAL CHARACTERISTICS Specification Characteristic GENERAL Model Designation: TFM-566 Frequency Range: 138 to 174 and 66 to 88 MHz Tuning Increments: 2.5 kHz Operating Mode: F3E simplex or semi-duplex Channel Spacing: 25 or 12.5 kHz Physical Dimensions (including heatsink): Approx. 8.0" X 3.0" X 5.75"...
  • Page 8 TECHNICAL CHARACTERISTICS (continued) VHF RECEIVER Sensitivity at 12 dB SINAD Better than 0.35 µV Adjacent Channel Selectivity -75 dB (25 kHz) -70 dB (12.5 kHz) Spurious Attenuation -90 dB Third Order Intermodulation -70 dB Image Attenuation -80 dB FM Acceptance ±...
  • Page 9 VHF and VLO TRANSMITTER RF Power Output 1 watt or 10 watts Output Impedance 50 ohms Maximum Deviation ±5 kHz (25 kHz mode) (In narrowband mode) ±2.5 kHz(12.5kHz mode) Spurious Attenuation -70 dB below carrier level Frequency Stability ± 2.5 ppm Microphone Circuit Carbon or equivalent Sidetone Output...

  • Page 10: Operating Instructions

    SECTION 2 OPERATING INSTRUCTIONS FEATURES The equipment has several important operating features which provide maximum flexibility, performance and versatility. These features include: 1. VHF and VLO bands that can be configured to be operated independently or as a single unit. 2.
  • Page 11 g) SIDETONE - The TX audio circuit becomes active allowing you to adjust the sidetone level with the VHF volume knob. When thedesired level is reached, press ENTER and this level will be set for both VHF and VLO bands. The factory setting is 23.

  • Page 12: Operating Instructions

    OPERATING INSTRUCTIONS (See Figure 2-1) 1. Switch power on by turning the main volume clockwise. Depending how the radio is configured, either the last programmed or last displayed frequencies will appear on the screen. The transceiver is now in normal operating mode. 2.

  • Page 13: Programming Instructions

    Use the 1,2,3,4,5 and M.DN keys to toggle between these functions (for details see paragraph 2.5). Once the desired condition has been selected, press ENTER. The TFM-566’s display will show a "+" beside the memory channel number if scan is enabled.

  • Page 14: Scanning Function

    PRIORITY SCANNING, SELECTIVE MEMORY CHANNEL SCANNING AND SCAN LISTS Instead of breaking up the 200 channels into blocks for scanning, the TFM-566 has 5 scan lists per band. Any of the 200 channels can be assigned to any one or more of these 5 scan lists.

  • Page 15: Direct Frequency Entry Mode

    DIRECT FREQUENCY ENTRY MODE This mode is designed to facilitate quick frequency selection during emergency and other operational conditions requiring direct operating frequency selection. This operating mode is disabled along with the programming mode when the internal disable jumper is set. 1.

  • Page 16: 90 Second Transmitter Time Out Feature

    2.11 90 SECOND TRANSMITTER TIME OUT FEATURE A selectable 90 second transmitter time out feature is provided to prevent accidental continuous transmission in the event of a faulty PTT switch. With this feature enabled the transceiver will stop transmitting after the PTT is engaged continuously for 90 seconds. The timer is reset by releasing then re-engaging the PTT switch.
  • Page 17 107.2 47.5* No Tone 110.9 49.2* (carrier squelch only) 114.8 51.2* (The tones marked with * are 118.8 53.0* nonstandard tones). 123.0 54.9* 127.3 56.8* 131.8 58.8* 136.5 63.0* 141.3 69.4* 146.2 159.8* 151.4 165.5* 156.7 171.3* 4. Press ENTER. "TX TONE" appears on the display. Repeat step 3. 5.

  • Page 18: Pc Memory/Programming Download Capability

    Documentation in PDF format under the Help menu. Otherwise, to get started, pull down the File menu and select TFM-566. The program defaults to serial port com1 but can be set to com2, 3 or 4 under the Com Port menu. The program is now ready to use. You may want to upload data from the radio and edit channels or start a new data file.
  • Page 19 TFM-530 Upload/Download Programming Cable P/N 993390-1 Wiring Diagram FIGURE 2-2 TFM-566 Transceiver PC Up/Download Cable - wiring diagram Note: If your serial port is a 9 pin connector, instead of the 25 pin use a female 9 pin D connector, connecting:...

  • Page 20: Installation Instructions

    Consult with instructions provided with the antennas. Connect RF cables from antennas to the back of the TFM-566 unit by utilizing the BNC connectors provided in the installation kit. The VLO connector is located on the rear, above the 15-pin D connector and the VHF connector is below the 9-pin D.
  • Page 21 FIGURE 3-1 Outline Drawing for Model TFM-566 Transceiver...
  • Page 22 INSTALLATION - PIN LOCATIONS AND CONNECTIONS (continued) 15 Pin D Connections - Use FEMALE Connector Pin # Description 600 Ohm Output 1 Data Output Panel Lighting (28VDC or 5VAC) Memory Up Memory Down Mic Signal Input 1 Main Power +28VDC Main Ground 4 ohm Speaker Output 4 ohm/600 ohm Output Ground...
  • Page 23 FIGURE 3-2 Wiring connections for the TFM-566 Transceiver...

  • Page 24: Wiring Instructions

    WIRING INSTRUCTIONS Figure 3-2 shows all required connections and recommended wire sizes for the TFM-566 Transceiver. 3.7.1 Main Power +28VDC The main power +28VDC (±15%) is connected to pins 7 and 14 of the transceiver. Both pins should be connected.

  • Page 25: Internal Programming And Guard Enable/Disable Jumper

    INTERNAL PROGRAMMING AND GUARD ENABLE/DISABLE JUMPER The programming and direct frequency entry modes can be disabled by removing the internal enable/disable jumper strap from pins 1 and 2 of J10. Removal of this jumper will prevent operation on any frequencies other than those programmed in the 400 memory positions and two guard receiver memory positions.

  • Page 26: Transmitter Power Adjustments

    TRANSMITTER POWER ADJUSTMENTS The transmitter power is adjusted to a maximum of 10 watts in high power mode and 1 watt in low power mode over the transceiver operating bandwith at the factory. If transmitter RF power re-adjustment is required, perform as follows: 1.
  • Page 27 FIGURE 3-4 External Adjustment Access Holes...

  • Page 28: Transmitter Deviation Adjustment

    3.11 SQUELCH ADJUSTMENT The squelch circuit is designed to open or close depending upon the noise content and not the strength of the received signal. Therefore high squelch settings are not necessary nor possible. The squelch on both the VHF and VLO receivers is factory set to open at approximately 22 dB SINAD, while the guard receiver is set to open at 25 dB SINAD.
  • Page 29 6. Key the transmitter and input a +10 dBm (2.5 VRMS), 2.5 kHz audio signal into microphone input 1 if in single mode or microphone input 2 if in dual mode. 7. Adjust the wideband deviation limit potentimeter, R21 on the VLO Rx/Tx module (see Figure 3-6) to produce a ±4.25 kHz deviation.
  • Page 30 VLO Receiver/Transmitter PCB Module Notes: R21 is for 25 kHz (wideband) Deviation Adjustment R16 is for 12.5 kHz (narrowband) Deviaton Adjustment FIGURE 3-6 Deviation Adjustment Potentiometer Location 3-11...
  • Page 31 POST INSTALLATION EMI TEST PURPOSE The purpose of this test is to identify any interference that the TFM-566 may cause with existing aircraft systems. As the TFM-566 installation may include the ATC-550 antenna tuner controller, this test, as required, will also identify any interference caused by the ATC-550.
  • Page 32 Determine if the image frequency for the VHF Comm falls within the range of the TFM-566. If so, select a set of frequencies that will cause the TFM-566 to be set as close as possible to the image frequency. Any one of the many possible sets will suffice. Record those values in the spaces provided in the following chart.
  • Page 33 FREQUENCIES RESULTS VHF #1 TFM-566 PASS FAIL 132.000 66.0000 135.975 67.9875 135.975 138.0000 121.150 157.5000 131.250 157.5000 128.000 Image: RESULTS FREQUENCIES VHF #2 TFM-566 PASS FAIL 132.000 66.0000 135.975 67.9875 135.975 138.0000 121.150 157.5000 131.250 157.5000 128.000 Image: NOTES:...
  • Page 34 Determine if the image frequency for the VOR/ILS Nav falls within the range of the TFM- 566. If so, select two sets of frequencies that will cause the TFM-566 to be set as close as possible to the image frequency. Chose one set in the localizer frequency range, and one in the VOR frequency range.
  • Page 35 Modulate the TFM-566 transmitter on the following frequencies for at least 20 seconds. Observe the Glideslope displays. Look for any movement of flags or needles on the navigation display. FREQUENCIES RESULTS G/S #1 PASS FAIL TFM-566 334.7 (108.1) 66.9400 334.7 (108.1) 83.6750...
  • Page 36 Operate the TFM-566 transmitter on the following frequency for at least 20 seconds. Observe the Transponder for any spurious replys or loss of reply to test set. FREQUENCIES TRANSPONDER #1 TRANSPONDER #2 TFM-566 PASS FAIL PASS FAIL 85.0000 MHz 85.8350 MHz 171.6650 MHz...
  • Page 37 Modulate the TFM-566 transmitter on the following frequencies for at least 20 seconds. Observe the DME displays. Look for loss of distance information on the display. FREQUENCIES RESULTS DME 1 TFM-566 PASS FAIL 978 (108.0) 81.5000 978 (108.0) 1020 (112.1) 85.0000...
  • Page 38 While turning the ATC-550 on and off as often as required, listen for any noise or detected audio signals on the HF receiver audio. FREQUENCIES RESULTS HF #1 PASS FAIL 16 MHz FREQUENCIES RESULTS HF #2 PASS FAIL 16 MHz NOTES:...
  • Page 39 Frequency #2 Frequency #3 At a safe altitude engage the autopilot or stability augmentation system. Modulate the TFM-566 transmitter on the above frequencies for at least 20 seconds. Observe any effect on the autopilot or stability augmentation system. Observations: Perform a coupled ILS approach to the aircraft's certified limits. Modulate the TFM-566 transmitter on the above frequencies for at least 20 seconds.
  • Page 40 List the power plant, fuel and other electric instruments in the chart provided and note any anomalies that occur while transmitting or switching the ATC-550 on and off. Assess the results. STEP SYSTEM PASS FAIL NOTES Com 1&2 (VLO 66-88 MHz Band) Transponder &...
  • Page 41 STEP SYSTEM PASS FAIL NOTES Compass Fuel Pressure Oil Temp Amps Bus Voltage Fuel % A-11...
  • Page 42 STEP SYSTEM PASS FAIL NOTES Torque % Annunciators Digital Clock Oil Pressure A-12...
  • Page 43 STEP SYSTEM PASS FAIL NOTES NOTES: A-13...
