Technisonic Industries Limited TDFM-136B Quick Reference Manual

1. LED channel squelch indicators – Lights when signal received (Top: Main, Bottom: Guard).
2. Channel parameter display – (2 line by 24 character LED display) (Top: Main, Bottom: Guard).
3. MAIN Multi-function rotary encoder (default: Main volume,
4. GUARD
Data port – for use with KVL 3000+ keyloader or TDP-136 Programming software. Need USB Driver.
5.
6. MN/GD
7. G1/G2 (Toggle Switch) – Selects guard memory (GD1 or GD2), for transmit and edit.
8. HI/LO (Toggle Switch) – Selects transmit power, high (10W) or low (1W).
9.
KEYPAD (12 Keys) – Control radio functions, 3 command levels as shown below.
Basic functions on L1
Cmnd
Function
SELECT CHANNEL MEMORY
DISPLAY BRIGHTER
EDIT OPERATING MODE
*
SCROLL CHANNEL DOWN
SCAN ON/OFF
* SCROLL CHANNEL UP
*
EDIT FREQUENCY
DISPLAY DIMMER
*
EDIT TONE or CODE
Tone:
P25 Code:
x - Off
m - Monitor (i.e. x)
t - On
n - NAC only
c - Code
g - TGID + NAC
GO TO NEXT LEVEL
*
TOGGLE HOME/CURRENT
TOGGLE TALK AROUND
TiL 08RE394 - NIICD
NIICD Modified 6/6/2014
For Radio Firmware: 1.x.x
2
Multi-function rotary encoder (default: Guard volume,
(Toggle Switch) – Selects active channel (main or guard),
Command Level 1: press the desired "Cmnd'"key
TO
SCROLL DOWN THROUGH PROGRAMMED/ACTIVE MEMORY CHANNELS
OR
SCROLL UP THROUGH PROGRAMMED/ACTIVE MEMORY CHANNELS
TO
STEP UP/ DOWN THROUGH: TONES, CODES, TGID & NAC ($ = HEX)
TO
GO TO THE NEXT HIGHER COMMAND LEVEL
TOGGLE BETWEEN 'HOME' CHANNEL AND CURRENTLY DISPLAYED CHANNEL.
FOR DUPLEX CHANNELS: RADIO USES Rx INFORMATION FOR Tx. "UP" ARROW.
Edit Keys
ENTER THREE DIGIT CHANNEL NUMBER INTO MEMORY (001 to 230)
STEP UP/DOWN THROUGH OPERATING MODES
STOP SCAN
SELECT Rx FREQUENCY THEN
STEP UP/DOWN THROUGH SQUELCH MODES. Tx FOLLOWS Rx.
DECIMAL EDIT FOR NOISE SQL VALUE (00 TO 15)
TDFM-136B

Quick Reference Guide

press for ON, press & hold for
press for Squelch
for transmit and memory edit.
("n" or "D")
REPEAT FOR Tx FREQUENCY
OFF).
defeat).
