TOP AND CABINET PARTS
For Model: 2DLXR7244MQ1
(Designer White)
Illus.
Part
No.
No.
DESCRIPTION
1
Literature Parts
LIT8318342 Installation
Instructions
LIT8539781 Use & Care Guide
LIT8542738 Wiring Diagram
LIT8539784 Repair Parts List
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
LIT4313896 Manual, Washer
2
8318068 Top
3
62750 Spacer, Cabinet To
Top (4)
4
357213 Nut, Push−In (2)
5
63424 Cabinet
6
62780 Clip, Top & Cabinet
& Rear Panel (2)
7
3357011 Screw, 10−16 x 1/2
8
3351614 Screw, Ground
11
8318084 Switch, Lid
13
3351355 Screw, Lid Hinge
Mounting (4)
15
8318088 Hinge, Lid (L.H.)
16
54583 Hinge, Lid (R.H.)
17
19119 Bumper, Lid Hinge
18
21258 Bearing, Lid
Hinge (2)
19
8542383 Lid
22
9724509 Bumper, Lid (2)
28
3390631 Screw,
10−16 x 3/8 (4)
3
8539784
