Whirlpool 2DLXR7244MQ1 Parts List page 11

Automatic washer
Hide thumbs

Advertisement

Illus.
Part
No.
No.
DESCRIPTION
1
3349557 Clip, Harness
2
388498 Clip, Harness
3
3347812 Clip, Harness
4
3352501 Clip, Harness
5
90016 Clip, Harness
6
3390496 Clip, Harness
7
389379 Retainer,
(Suds Models)
8
352090 Timer, Block
Disconnect
(White)
9
352089 Timer, Block
Disconnect
(Black)
10
62889 Receptacle,
Terminal
(3−Way)
(Lid Switch)
(Use Term.94613)
Or 94614.)
11
353424 Plug, Terminal
(3−Way)
(Power Cord)
(Use Term.94613)
12
62505 Block, Disconnect
(Motor 2 Speed)
(Use Term.352088)
WIRING HARNESS PARTS
For Model: 2DLXR7244MQ1
(Designer White)
Illus.
Part
No.
No.
DESCRIPTION
13
3348075 Block, Disconnect
(Motor 3 Speed)
(Use Term. 94613
Or 94614.)
14
3347243 Block, Disconnect
(Use Term. 352088)
15
63523 Protector
16
717252 Connector
(2−Way)
(Use Term.94614)
17
387566 Plug, Terminal
(4−Way)
(Power Cord)
(Use M3 Screws)
18
3352944 Clip, Harness
19
3390423 Block, Disconnect
(12−Way)
(Timer)
(Use Term. 94613)
20
3347730 Receptacle
(6−Way)
(Use Term. 94613)
21
388818 Plug, Terminal
(12−Way)
(Use Term. 94613
Or 94614.)
22
3369366 Timer, Block
Disconnect
(Black) (Amp)
(Use Term.3369365)
Illus.
No.
23
24
25
26
27
28
29
30
11
Part
No.
DESCRIPTION
3349494 Connector, Etc
60687 Connector, Relay
(Use Term.308569)
3407125 E.T.C. Control
3948617 Connector (T.P.A.)
(3−Circuit)
(Lid Switch)
(Use Term. 3948619
OR 3948620.)
3360056 Connector (T.P.A)
(3−Circuit)
(Pressure Switch)
(Use Term.3948619
OR 3948620.)
3354925 Block, Connector
(Cold Valve)
(Use Term.693217)
3354926 Block, Connector
(Hot Valve)
(Use Term.693217)
3948615 Connector (T.P.A.)
(6−Circuit)
(Temp. Switch)
(Use Term.3948619
OR 3948620.)
8539784
