7 Service Fixture & Tools
7.1.
When Replacing the Main P.C.B.
After replacing the MAIN P.C.B., be sure to achieve adjustment.
The adjustment instruction is available at "software download" on the "Support Information from NWBG/VDBG-AVC" web-site in
"TSN system", together with Maintenance software.
7.2.
Service Position
This Service Position is used for checking and replacing parts. Use the following Extension cables for servicing.
No.
Parts No.
1
RFKZ0487
2
RFKZ0444
3
VFK1480
4
VFK1388
5
VFK1441
6
VFK1440
Table S1 Extension Cable List
Connection
FP6001(MAIN) - MONITOR FPC
PP6001(MAIN) - PS6401(SD HOLDER)
FP6010(MAIN) - ECM HOLL FPC(FRONT CASE UNIT)
FP6004(MAIN) - FP7001(FLASH)
FP6005(MAIN) - LENS BARRIER UNIT
FP4803(SD HOLDER) - OPERATION SW UNIT(TOP CASE UNIT) 10PIN 0.5 FFC
21
Form
35PIN 0.3 FFC
50PIN 0.5 B to B
6PIN 0.5 FFC
12PIN 0.5 FFC
8PIN 0.5 FFC
