18 Shoe adaptor mount
[SHOE ADAPTOR]
19 Status indicator
20 Recording start/stop button
21 LCD monitor (Touch screen)
It can open up to 90 .
It can rotate up to 180
or 90
towards the opposite direction.
Due to limitations in LCD production
technology, there may be some tiny bright
or dark spots on the LCD monitor screen.
However, this is not a malfunction and
does not affect the recorded picture.
22 Battery holder
23 Tripod receptacle
If you attach a tripod with a 5.5 mm
(0.22 ) screw or larger, it may damage
this unit.
24 SD card cover
23
25 Access lamp [ACCESS]
26 Card slot
27 Photoshot button [
27
28 Zoom lever [W/T] (In Motion Picture
28
Recording Mode or Still Picture
Recording Mode)
Thumbnail display switch [
29
Volume lever [ VOL ] (In Playback
Mode)
29 Mode switch
30 Grip belt
Adjust the length of the grip belt so that it fits
your hand.
Flip the belt.
Adjust the length.
Replace the belt.
31 DC input terminal [DC IN]
Do not use any other AC adaptors except
the supplied one.
14
towards the lens
]
/
]/
