HTML Configuration
and Control
This section provides procedures for accessing and using the MGP Pro embedded web
pages. Topics include:
•
•
•
•
•
The MGP Pro series can be controlled and configured using HTML web pages that are
accessed over a network or from a local PC connected to the MGP Pro LAN port. The
MGP Pro has factory-installed HTML web pages that allow you to view and adjust IP
settings, upload firmware and other files to the MGP Pro, and select a background image
for the display. Access these HTML pages using a web browser such as Microsoft Internet
Explorer.
NOTES:

Accessing the Web Pages

To access the MGP Pro HTML web pages:
1.
2.
Accessing the Web Pages
Viewing System Status
Using the Configuration Pages
Using the File Management Page
Using the Background Page
• Administrators have access to all of the web pages and are able to make changes
to settings. Users can access the pages on the
tabs only.
• The screen examples in this section all show MGP 462 Pro web pages. The
MGP 464 Pro web pages are identical in content and appearance except for the
product names and number of windows discussed.
Start the web browser program.
Enter the MGP Pro IP address in the browser
NOTE: If your local system administrators have not changed the address, use the
factory-specified default, 192.168.254.254, for this field.
System Status
field.
Address
MGP Pro Series • HTML Configuration and Control
and
Background
84
