I I n n s s t t a a l l l l a a t t i i o o n n
1
1 - USB2.0 High-Speed Independent External ports (4)
2 - USB2.0 High-Speed Independent Internal port (1)
Installing the PCI Express serial card
1. Shut down all power connected to the computer, as well as all devices connected to
the computer peripherally (i.e. Printers, Monitors, Scanners etc.). As an added step to
ensure safe installation, unplug the power supply from the computer.
2. Remove the computer cover. For more detailed instruction on how to perform this
step, please refer to the documentation that was included with your computer at the
time of purchase.
3. Locate an empty PCI Express slot, removing the metal bracket covering the
accompanying empty port/socket.
4. Position the USB card above the open PCI Express slot, ensuring that the card is
properly aligned with the slot. Insert the card firmly into the slot, distributing force
evenly across the length of the board. Once inserted, secure the card into the
adjoining socket (previously covered by metal bracket), using the correct size screw (if
necessary, please consult documentation that accompanied purchase of computer).
5. Replace the computer cover and re-connect all power to the computer.
Driver installation
Once the computer is fully booted, following the physical installation of the card, Windows
