Bobbin Winding - Pfaff expression line Owner's Manual

Bobbin winding

Winding from horizontal position
1. Place an empty bobbin on the bobbin spindle,
with the logo facing up. Use only the original
PFAFF bobbins approved for this model.
®
2. Place the thread spool on the spool pin in
horizontal position. Slide a spool cap tightly
against the spool.
3. Place the thread into the thread guide (A) from
front to back. Pull the thread counter-clockwise
above the bobbin winder thread guide (B) and
then through the bobbin thread guides (C) at
the rear.
Note: Make sure the thread is pulled securely inside
the pre-tension device for correct thread tension.
4. Thread through the hole in the bobbin (D) from
the inside to the outside.
5. Push the bobbin lever to the right to wind. A
pop-up appears on the screen to inform you
that bobbin winding is active. Press the foot
control to start winding the bobbin.
When the bobbin is full, the bobbin winding
will slow down and stop automatically. The
pop-up closes. Remove the bobbin and cut the
thread using the bobbin thread cutter (E).
Winding through the needle
Make sure that the presser foot and the needle are
in the up position. Only wind through the needle if
using a metal presser foot.
Bring the thread up from the needle, under
the presser foot, upward through the left-hand
threading slot and through the bobbin thread
guides (C). Then follow step 4 and 5 above.
2:6
C C
E
B
A
B
A
C
D
C
