Pfaff expression line Owner's Manual page 24

Buttons for
4
3
3
2
1
8
5
6
7
Needle stop up/down with indicator (1)
Press this button to move the needle up or down.
The setting of the needle stop position is changed
at the same time. When needle down is activated,
the indicator is lit, the needle will stop in the down
position.
You can also tap the foot control to raise or lower
the needle.
Immediate tie-off (2)
Press the tie-off button while sewing and your
machine sews a few tie-off stitches and stops
automatically.
Stitch restart (3)
When having stopped sewing in the middle of a
stitch, press restart to start sewing at the beginning
of the stitch again without having to reset any
special settings you have made.
If pressing the stitch restart button while sewing,
then stop.
Speed control (4)
Press the speed button to sew at a slower speed.
An icon on the graphic display will indicate how
slow your machine will sew. Long press the speed
button and use the wheel (13) to change the sewing
speed.
Note: You cannot select a higher speed than the default
speed.
2:12
3.5 machine
1 2 4 9 11 10 12 13
15 16 17 18 19 20
Reverse (7) with indicator (5)
For permanent reverse, press the button
before starting to sew. The reverse indicator (5)
will be lit and the machine sews in reverse until
you press the button again to cancel.
If you press the reverse button while sewing, the
machine sews in reverse for as long as you keep the
button pressed. The reverse indicator is lit when
the reverse button is pressed.
Reverse is also used when sewing buttonholes,
programmed tie-off end, darning stitches and
tapering stitches to step between the parts of the
stitch.
Programmed tie-off indicator (6)
The programmed tie-off indicator is lit to indicate
that one or several tie-off options are activated. The
indicator stays lit until the tie-off options are no
longer in use.
Thread snips with indicator (8)
Press the button when you are not sewing and
your sewing machine cuts the top and bobbin
threads and raises the presser foot and the needle.
To cut before the needle moves to the start position
of the next stitch, press the thread snips button
while sewing. The thread snips indicator will be lit.
The graphic display lets you view all your
selections and options. Stitches are shown in real
size.
14
OK
21 22 23
