NETWORK SERVICES
DECEMBER 2008
ACU5501A
Wizard DVI SRX
USER GUIDE
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500)
CUSTOMER
FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746
SUPPORT
Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018
INFORMATION
Web site: www.blackbox.com • E-mail: info@blackbox.com
Advertisement
Table of Contents
Related Manuals for Black Box Wizard DVI SRX
Summary of Contents for Black Box Wizard DVI SRX
-
Page 1: User Guide
Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) CUSTOMER FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 SUPPORT Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 INFORMATION Web site: www.blackbox.com • E-mail: info@blackbox.com... -
Page 2: Table Of Contents
Contents ® Welcome Operation What’s in the box.................3 Operation ...................10 What you may additionally need ..........3 General use ................10 Video display (EDID) information ........10 Installation Power and activity indicators ..........10 Connections .................4 Further information Switch settings ................4 Mounting the modules – desk or rack ........4 Troubleshooting ................11 Connections at the local module ...........5 Getting assistance ..............11... -
Page 3: Welcome
Category 5, 5e or 6 twisted pair cabling. Thanks to our long involvement and investment in extender technology we have The Wizard DVI SRX extenders have been designed to be quick to install and succeeded in overcoming the numerous problems associated with extending totally transparent in operation. -
Page 4: What's In The Box
USB cable 2m (type A to B) Rack mount plate plus three screws Video cable DVI/D to DVI/D Eight self-adhesive Wizard DVI SRX local and remote modules rubber feet Two ferrite cores What you may additionally need Power adapter and country-... -
Page 5: Installation
Installation ® Connections Installation of the DVI SRX modules is straightforward and requires minimal Rack mount configuration in most cases. Note: The module switches are not accessible once it is inserted into the rack, therefore, check all settings before insertion. Connections at the local module •... -
Page 6: Connections At The Local Module
Connections at the local module ® Video connection Link connection 1 Use the supplied DVI/D link cable to connect the DVI input socket of the 1 Attach one of the supplied ferrite cores to the link cable, next to the local module to the digital video output socket of the computer. -
Page 7: Connections At The Remote Module
Connections at the remote module ® Video connection Link connection 1 Attach one of the supplied ferrite cores to the link cable, next to the 1 Connect the DVI/D lead from the video monitor to the DVI output socket of the remote module. -
Page 8: Video Image Compensation
Video image compensation ® The DVI SRX modules use a special two-part compensation technique to overcome the effects of long cable lengths upon the digital video signal. Under your control, the local and remote modules apply their own adjustments to the video signal. -
Page 9: Performing Upgrades
USB socket from an active computer, available from Black Box and allows you to check the current revision of the DVI or by using another standard power supply, similar to the one used by the remote module. - Page 10 IMPORTANT: Check that the ‘Intended Target Units’ field matches the ‘Unit Connected’ field. If these fields do not match then you may have an incorrect upgrade file, check with Black Box technical support before proceeding. Check also that the ‘New firmware version’ is greater than the ‘Current firmware version’.
-
Page 11: Operation
Operation ® Operation General use Power and activity indicators Each module provides two indicators to confirm power status and also feedback In use, the DVI SRX modules should be transparent - the system and its peripherals should operate exactly as normal, the only difference being that they about the various input signals: are now up to 50 metres apart. -
Page 12: Further Information
Further information ® Troubleshooting Getting assistance If you experience problems when installing or using the DVI SRX modules, If you are still experiencing problems after checking the list of solutions in the please check through this section for a possible solution. If your problem is not Troubleshooting section then we provide a number of other solutions: listed here and you cannot resolve the issue, then please refer to the ‘Getting •... -
Page 13: Safety Information
Safety information ® • For use in dry, oil free indoor environments only. • Do not use to link between buildings. • Ensure that the twisted pair interconnect cable is installed in compliance with all applicable wiring regulations. • Do not connect the CATx link interface (RJ45 style connector) to any other equipment, particularly network or telecommunications equipment. -
Page 14: Radio Frequency Energy
Radio Frequency Energy ® A Category 5 (or better) shielded twisted pair cable must be used to connect the local and remote units in order to maintain compliance with radio frequency energy emission regulations and ensure a suitably high level of immunity to electromagnetic disturbances. -
Page 15: Normas Oficiales Mexicanas (Nom) Safety Statement
Normas Oficiales Mexicanas (NOM) electrical ® safety statement Instrucciones de seguridad 15 En caso de existir, una antena externa deberá ser localizada lejos de las 1 Todas las instrucciones de seguridad y operación deberán ser leídas antes de lineas de energia. que el aparato eléctrico sea operado. - Page 16 ® © 2008 Black Box Corporation All trademarks are acknowledged. Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018, United States of America Tel: +1-724-746-5500 Fax: +1-724-746-0746 Documentation by: www.ctxd.com...
-
Page 17: Blackbox Subsidiary Contact Details
BlackBox subsidiary contact details ® Country Web Site/Email Phone United States www.blackbox.com 724-746-5500 724-746-0746 Austria www.black-box.at +43 1 256 98 56 +43 1 256 98 56 support@black-box.at Belgium www.blackbox.be +32 2 725 85 50 +32 2 725 92 12 support.nederlands@blackbox.be support.french@blackbox.be support.english@blackbox.be Denmark...
