Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) • Customer FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax Support 724-746-0746 • Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, Information PA 15055-1018 • Web site: www.blackbox.com • E-mail: info@blackbox.com...
Page 2
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS This equipment generates, uses, and can radiate radio-frequency energy, and if not installed and used properly, that is, in strict accordance with the manufacturer’s instructions, may cause inter ference to radio communication. It has been tested and found to comply with the limits for a Class A computing device in accordance with the specifications in Subpart J of Part 15 of FCC rules, which are designed to provide reasonable protection against such interference...
Page 3
NOM Statement Normas Oficiales Mexicanas (NOM) Electrical Safety Statement INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
Page 4
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender 13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
Trademarks Used in this Manual TRADEMARKS USED IN THIS MANUAL Black Box and the Double Diamond logo are registered trademarks, and ServSwitch is a trademark, of BB Technologies, Inc. Any other trademarks mentioned in this manual are acknowledged to be the property of the trademark owners.
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender Contents Chapter Page 1. Specifications..................7 2. Overview ..................8 2.1 Introduction ................8 2.2 Features ..................8 2.3 What’s Included ................9 2.4 What You Need to Supply ............10 2.5 Hardware Description ............... 10 2.5.1 Console Unit ..............
Chapter 1: Specifications 1. Specifications Distance: 1080p: 3200 ft. (1000 m); 1080i: 6400 ft. (2000 m) HDCP Support: Yes Hotkey: Yes Video Resolution (Maximum): Full HD: 1920 x 1080; WUXGA: 1920 x 1200 User Controls: Each unit: (1) Push Button: Control Status Switch Connectors: Console Unit: Console Interface: Serial port: (1) DB9 M DTE;...
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender 2. Overview 2.1 Introduction The DVI-D USB KVM over Fiber Optic Extender consists of a console unit and a computer unit. It enables you to remotely access and control a computer or KVM switch up to 6400 feet (2000 m) away from using only fiber optic cable. The extender optimizes the digital display up to a maximum resolution of Full HD (1920 x 1080)/WUXGA (1920 x 1200)/UXGA (1600 x 1200).
WSXGA all the way to Full HD, WUXGA system 2.3 What’s Included Your package should contain the following items. If anything is missing or damaged, contact Black Box Technical Support at 724-746-5500. • (1) KVM Extender console unit • (1) KVM Extender computer unit •...
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender 2.4 What You Need to Supply • (1) computer with USB port(s) and DVI video output port • (1) USB keyboard/mouse to control the console • Microphone, speakers, HDCP-compliant monitors with DVI interface for the HDCP video source (optional) •...
Page 11
Chapter 2: Overview Back Panel Figure 2-2 shows the extender console unit’s back panel. Table 2-2 describes its components. REMOTE DC 9-12V Console Local Computer Remote Computer 15 11 Figure 2-2. Console unit’s back panel. Table 2-2. Console unit’s back panel components. Number Component Description...
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender 2.5.2 Computer Unit Front Panel Figure 2-3 shows the DVI-D USB KVM over Fiber Optic Extender Computer Unit’s front panel. Table 2-3 describes its components. Figure 2-3. Computer unit’s front panel. Table 2-3. Computer unit’s front panel components. Number Component Description...
Page 13
Chapter 2: Overview Back Panel Figure 2-4 shows the extender computer unit’s back panel. Table 2-4 describes its components. LOCAL DC 9-12V Local Console Computer Remote Console 15 11 Figure 2-4. Computer unit’s back panel. Table 2-4. Computer unit’s back panel components. Number Component Description...
Chapter 3: Installation 3. Installation 3.1 Using Fiber Optic Cable 1. Use multimode fiber optic cable (50/125 and 62.5/125) terminated with SC connectors to link the computer unit and the console unit. Table 3-1 lists applicable specifications. Table 3-1. Fiber optic cable specifications. Cable Diameter 50/125 µm 62.5/125 µm...
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender 9. Conductive cables require proper grounding and bonding for applicable conductors. 10. Carefully inspect all fiber optic components for damage and test it for continu- ity or loss if you suspect damage. 11. Move small, lightweight spools of fiber optic cable by hand. Move larger reels with appropriate lifting equipment or use two or more installers skilled in the moving operation.
Chapter 4: Operation 4. Operation 4.1 LED Indicators The LEDs on the KVM extender indicate the latest link, communication, and control status between the Computer Unit and Console Unit. 1. Press the push button on Console Unit to select “Local ON” or “Remote ON.” 2.
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender 4.2 Selecting Computers Using Push Buttons The Computer Unit and the Console Unit’s front panels each have a push button. Push these buttons in sequence to switch between operation modes. 4.2.1 Push Button on the Console Unit The button on the front panel of the Console Unit can be used to switch modes by following the sequence below: Local On—>Remote On—>Local On—>Remote On...
Chapter 4: Operation 4.3 Selecting Computers Using Keyboard Hotkey Commands A hotkey command is a short key sequence that selects a computer, activates a computer scan, etc. The KVM extender interprets keystrokes for hotkeys all the time no matter what the connection pattern is. Standard Mode is defined as the state of the KVM extender without any connection to any KVM switch.
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender Figure 4-1. Alternate hotkeys activated on keyboard. 4.3.1 Mask Hotkey Switch Slide the Mask Hotkey Switch (shortcut for Cascade Hotkey Configuration) located at the rear panel of both Console Unit and Computer Unit ON/OFF to switch hot- key control between the KVM switch cascaded/computer connected accordingly.
Page 21
Chapter 4: Operation Example of Mask Hotkey set to “ON” in cascade architecture An IT administrator sitting in front of the Console Unit can preset the Console Unit to remote mode for accessing the KVM Switch that is attached to the Computer Unit, then slide “ON”...
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender 4.3.2 Hotkey Commands • Before inputting any hotkey commands, enable either of two modes: Standard Mode: Input the hotkey command [left Ctrl + left Ctrl + Alt + E]. The unit will beep once to confirm. Compatibility Mode: Input the hotkey command [left Ctrl + left Ctrl + Alt + E].
Page 23
Chapter 4: Operation Table 4-4 (Continued). Console unit hotkey commands and their functions. Mask Hotkey: OFF Mask Hotkey: ON Function Description Hotkey Alternate Hotkey Alternate Hotkey Hotkey [Leading Code]+F2 Mode selection in sequence. Switch the console control between local computer and remote computer.
Page 24
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender Table 4-5. Computer unit hotkey commands and their functions. Mask Hotkey: OFF Mask Hotkey: ON Function Description Hotkey Alternate Hotkey Alternate Hotkey Hotkey [Ctrl]+[Ctrl]+Alt+E Select cascading status. Two beeps: Enable com- patibilty mode so users can access the KVM switch that connects to the com- puter unit.
Page 25
Chapter 4: Operation Table 4-5 (Continued). Computer unit hotkey commands and their functions. Mask Hotkey: OFF Mask Hotkey: ON Function Description Hotkey Alternate Hotkey Alternate Hotkey Hotkey [Leading Code]+3 Select Auto mode. [Leading Code]+F3 [BTN] [BTN] Select Latch time. The extender beeps 1 to 4 times to indicate the latch time: 5, 15, 30, or 60...
Page 26
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender NOTE: [BTN] denotes Press and Hold the front-panel push button for two seconds. NOTE: After you Press and Hold the push button, the hotkey state will automatically time out if: 1. The keyboard detects no activity within six seconds afer you press and hold the push button for two seconds.
Chapter 4: Operation • DVI mode for monitor display: Set the display(s) on both the Console and Computer Units to DVI mode that is incapable of carrying any audio signals. Press and hold the push button for two seconds + V + D DVI Monitor DVI Monitor Computer Unit...
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender 5. Cascade Configuration You can connect one KVM extender per console port of the KVM switch in a cas- cade configuration. To prevent any conflict between hotkey commands among the connected units, press the E key after you press Ctrl + Ctrl to access the extender directly.
Page 29
1. An external power source is required to supply enough power to the KVM extender’s Computer Unit when connecting to the KVM switch. To purchase an optional power adapter, call Black Box Technical Support at 724-746-5500. 2. To prevent sending wrong keystrokes for Hotkey control to the KVM extender’s Console Unit, set up the latch time and push button control...
ServSwitch Brand DVI-D USB KVM-over-Fiber Extender 6. Serial Configuration The KVM Extender has serial ports on both the Console and Computer units. You can connect these serial ports to serial terminal and serial devices for device configurations such as POS, bar-code scanners, card readers, and touch screens. The extender units transmit data without baud rate limits or configuration.
Appendix : Cable Requirements /Fiber Optic/Blu-ray Appendix. Cable Requirements/Fiber Optic Cable/Blu-ray A.1 Cable Requirements A fiber optic cable terminated with multimode SC connectors is normally used to connect the Computer Unit to the Console Unit. Your package includes a fiber optic cable.
Page 32
724-746-5500 or blackbox.com. About Black Box Black Box Network Services is your source for more than 118,000 networking and infrastructure products. You’ll find everything from cabinets and racks and power and surge protection products to media converters and Ethernet switches all supported by free, live 24/7 Tech support available in 20 seconds or less.
