EF CK-SPECCHIO User Manual

Designer hood
Hide thumbs

Advertisement

Quick Links

Download this manual
DESIGNER HOOD
MODEL: CK-SPECCHIO
THE BEAUTY OF SIMPLICITY
USER MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the CK-SPECCHIO and is the answer not in the manual?

Questions and answers

Related Manuals for EF CK-SPECCHIO

Summary of Contents for EF CK-SPECCHIO

  • Page 1 DESIGNER HOOD MODEL: CK-SPECCHIO THE BEAUTY OF SIMPLICITY USER MANUAL...
  • Page 2 Fig.1 Fig.2 Fig.3 Fig.4 Fig.5...
  • Page 3 Fig.6 Fig.7 Fig.8 Fig.9 Fig.10 Fig.11 Fig.12 Fig.13 Fig.14...

  • Page 4: Safety Precaution

    Fig.15 Fig.16 Fig.17 Fig.17 Fig.18 Fig.18 Fig.17 Fig.17 Fig.18 Fig.18 GENERAL Carefully read the following important information regarding installation safety and maintenance. Keep this information booklet accessible for further consultations. The appliance has been designed for use in the ducting version (air exhaust to the outside –...

  • Page 5: Installation Instructions

    Before connecting the model to the electricity network: - control the data plate (positioned inside the appliance) to ascertain that the voltage and power correspond to the network and the socket is suitable. If in doubt please ask qualified electrician for help. 2.
  • Page 6 personnel. • Electric Connection The appliance has been manufactured as class I, therefore earth cable is necessary. The connection to the mains is carried out as follows: IEC227 North America L=live Brown Black N=neutral Blue White E=earth Green/Yellow Green If the plug is not provided, connect the electrical load as indicated on the description label.

  • Page 7: Use And Maintenance

    of wall (e.g. reinforced concrete, plasterboard, etc.). If the screws and screw anchors are provided with the product, kindly check the screws are suitable for the type of wall in which the hood is to be fixed. • FIXING THE DECORATIVE TELESCOPIC FLUE Arrange the electrical power supply within the dimensions of the decorative flue.
  • Page 8 water and neutral liquid detergent, leaving to soak. - Rinse thoroughly with warm water and leave to dry. - The filters may also be washed in the dishwasher. Please take note that the aluminum panels may alter in color after several washes.
  • Page 9 Fig.C Fig.D • How to replace the charcoal filters for 35 series 1. Push the middle bottom edge of the glass door (Fig.E) 2. The inside gas spring will help you to open the glass door , and fixed at an angle (Fig.F) 3.
  • Page 10 •FUNCTION KEYS: (Fig.9) • FUNCTION KEYS: (Fig.8) A= TIMER – 15 MINUTES A = OFF B= SPEED I B = SPEED I / OFF C= SPEED II C = SPEED II / OFF D= SPEED III D = SPEED III / OFF E =LIGHT E = LIGHT •...
  • Page 11 If Speed 3 is required，press key C adjust“＋”. At Speed 3 program both key B and key C indication light will flash on each function key button. To on the light press key E. To off the light press key E again. When the appliance and light are ON together or separately, press key A the Automatic Stop Timer will start the 15 minutes count down.
  • Page 12 Timer Function before 15 minutes time frame, press key A again. • FUNCTION KEYS :( Fig.14) A= Filtering system / Set clock B= Delay Timer C= Speed S1/ “-” adjust / off D= Digital display E= Speed S1/ “+” adjust / off F= Alarm G= Light When the Key A is flashing, at the same time “...
  • Page 13 B= Speed 1 / adjust / switch off C= digital display screen (showing timer and speed) D= Speed 3 / adjust / switch off E= Light When key A is being pressed, digital display screen will show "15 minutes" for timer whereas the minutes can be adjusted by pressing "+" or "-" on key B and D.

  • Page 14: Troubleshooting

    be used to extend the time of Automatic Stop Timer. To stop the Automatic Stop Timer Function before 15 minutes time frame, press key B again. Troubleshooting Problem Possible reason Solution Hood doesn’t work Electric supply Check whether the plug is connected Check whether the main switch is turned on Poor airflow...
  • Page 15 resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased. They can take this product for environmental safe recycling. Warranty Information The manufacturer provides warranty in accordance with the legislation of the customer's own country of residence, with a minimum of 1 year (Germany: 2 years), starting from the date on which the appliance is sold to the end user.
