Converters.TV 1 by 8 HDMI to CAT6 Splitter Operation Manual

1 by 8 hdmi to cat6 splitter

Download this manual

1 by 8 HDMI to CAT6

Splitter

ID #743

Operation Manual

Need help?

Do you have a question about the 1 by 8 HDMI to CAT6 Splitter and is the answer not in the manual?

Page 1 1 by 8 HDMI to CAT6 Splitter ID #743 Operation Manual...
Page 2 Introduction The 1 by 8 HDMI to CAT6 1.3 splitter when used with CAT6 to HDMI receivers it will allows user to distribute a HDMI source through CAT6 cable over 45 meters. This solution provides a direct input of one HDMI to a looped output of HDMI and 7 CAT6 outputs –...
Page 3: Operation Controls And Functions
Operation Controls and Functions Front Panel HDMI/DVI indicators: When LED illuminate this means the input source is with HDMI content and when the input source is DVI the LED will not illuminate. HDCP indicators: When the input source is with the HDCP protection the HDCP LED will illuminate.
Page 4 Audio → PCM 2CH 3. The EDID selection will only activate when the unit is re-plug and power on. System Reset: Switch to “ON”, the system will send the internal CEC to the display within 8~10 minutes to force all the displays to switch to HDMI 1 input port.
Page 5 RJ-45 Pin Definitions Installation...
Page 6 Specifications Frequency Bandwidth 2.25Gbps (single link) Input Ports 1 x HDMI female port (Type A connector) Output Ports 7 x CAT6 output Video/7 x CAT6 output DDC 1 x HDMI female port (Type A connector) EDID STD / TV HDMI Audio Output PCM2, 5.1, 7.1, Dolby 5.1, DTS 5.1, DD+, D- TrueHD, DTS-HD HDMI Cable In...
