Converters.TV 15130 Operation Manual

Hdmi 1 x 8 splitter
Hide thumbs
1
2
3
4
5

Advertisement

Quick Links

Download this manual
HDMI 1 x 8 Splitter
- ID# 15130
Operation Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the 15130 and is the answer not in the manual?

Questions and answers

Related Manuals for Converters.TV 15130

Summary of Contents for Converters.TV 15130

  • Page 1 HDMI 1 x 8 Splitter - ID# 15130 Operation Manual...
  • Page 2 Introduction into up to 8 This 1 by 8 HDMI Splitter can split and distribute a single HDMI input identical HDMI outputs without any loss of quality. It supports a wide range of HDMI features including high definition video and lossless audio, 3D, and 12- bit Deep Color Features •...

  • Page 3: Hdmi Input

    Operation Controls and Functions Front Panel Back Panel EDID:The default setting is TV. When in this mode, the unit will detect the EDID settings of the display connected to OUTPUT 1 and record them in the unit's memory. If there are any audio or video issues then switch the unit to STD mode and power cycle it.
  • Page 4 Connection Diagram...
  • Page 5 Specifications Video Bandwidth 225 MHz/6.75 Gbps Input Ports 1×HDMI (Female), 1×USB (Service only) Output Ports 8×HDMI (Female) Output Resolution 480i ~ 1080p@24/50/60 up to 12-Bit Color Depth, and VGA ~ WUXGA(RB) HDMI Input Cable 15m (1080p 8-bit)/10m (1080p 12-bit) HDMI Output Cable 15m (1080p 8-bit)/10m (1080p 12-bit) Power Supply 5 V/6 A DC (US/EU standards, CE/FCC/UL...
