Converters.TV 470 Operation Manual

Dvi splitter with hdcp compliance

DVI Splitter with HDCP

Compliance ID

#470

Operation Manual

Table of Contents

Need help?

Do you have a question about the 470 and is the answer not in the manual?

Page 1 DVI Splitter with HDCP Compliance ID #470 Operation Manual...
Page 2 Introduction The DVI Splitter with HDCP Compliance accepts DVI signal from a computer or video equipment and splits up to two, identical and buffered outputs. Each of the output can run up to 15 meters using standard DVI cable. It also supports a wide range of input resolution (25- •...
Page 3 Specifications Input connector: 1 input (DVI Female) Output connector: 2 inputs (DVI Female) Frequency bandwidth: 1.65Gbps (Single link) Power consumption: 6W Max Operating temperature range: 5 degree to 40 degree C Operating humidity range: 30 to 80% RH Power supply: 5VDC power supply with universal plugs Dimensions(mm):...
Page 4 DVI-D Pin Configuration DVI-Digital (DVI-D): Supports display-only connections between the host computer and display. This interface is designed for a 12 or 24-pin connection to enable single or dual-link mode activation. DVI-D Recepticle Connector...
