- Page 1 HDMI UHD 4k2k 1 In 2 Out Splitter with HDCP 2.2 - # 15382 Operation Manual...
- Page 2 Introduction This high performance HDMI splitter with HDCP 2.2 is an advanced solution designed to distribute an single HDMI input to two simultaneous HDMI outputs and supports resolutions up to 4K2K@60Hz (YUV420), as well as High Definition Lossless Audio formats. Capable of receiving and transmitting up to 9Gbps of bandwidth with no data loss, it also supports the latest features so you can be assured of reliable and high quality HDMI distribution.
- Page 3 Operation Front Panel Controls and Functions 1. POWER: This LED will illuminate when the unit is connected to an active power supply and switched on. SYNC IN: This LED will illuminate when the unit is connected with active signal from the source device.
- Page 4 the best resolution that all displays can support. Note: When Output 1 is connected to a 4K2K display and Output 2 is connected to non-4K2K display no picture may be displayed. To ensure proper display all screens must all be capable of displaying the same resolution.
- Page 5 Connection Diagram...
- Page 6 Supported Resolutions Resolution Input Output 640×480@60/72/75 √ √ 720×480@60 √ √ 720×576p@50 √ √ 800×600@60/72/75 √ √ 1024×768@60/70/75 √ √ 1280×720@50/60 √ √ 1280×720p@60 √ √ 1280×768@60 √ √ 1280×800@60 √ √ 1280×1024@60 √ √ 1360×768@60 √ √ 1600×1200@60 √ √...
