- Page 1 HDMI 1 In x 16 Out 4Kx2K Splitter # 15215 Operation Manual...
- Page 2 Introduction This high performance 1 by 16 HDMI splitter distributes one HDMI input to up to sixteen simultaneous HDMI outputs and supports 4K×2K, 3D, 12-bit Deep Color as well as High Definition Lossless Audio. With its 3Gbps bandwidth it supports the latest HDMI standards so you can be sure of superior HDMI distribution Applications •...
- Page 3 Operation Front Panel Controls and Functions 1. POWER LED: The power LED will illuminate when the unit is powered. SYNC LED: The LED will illuminate when the HDMI source signal is connected to the input port. Rear Panel 1. EDID STD/TV: The default factory setting is TV, when in this mode, the unit will detect the first HDMI output device's EDID settings and record them in the unit's memory.
- Page 4 Specifications Video Bandwidth 340MHz/10.2Gbps Input Port 1×HDMI (Female connector), 1×USB (Manufacturer use only) Output Ports 16×HDMI (Female connector) Output Resolutions 480i~1080p@50/60, 1080p@24/50/60, VGA~UXGA, Ultra HD (4K×2K@30) ESD Protection Human body model: ±8kV (air-gap discharge) ±4kV (contact discharge) Dimensions 436 mm (W)×26 mm (D)×48 mm (H) Weight 1664 g Chassis Material...
- Page 5 Connection Diagram...
