- Page 1 4K HDMI 4 Way Splitter - ID# 15482 Operation Manual...
- Page 2 Introduction This 1 by 4 4K UHD HDMI Splitter is an advanced solution for splitting and distributing a single HDMI input to 4 HDMI outputs. It provides a high level of audio and video performance with support for resolutions up to 4K@60Hz (YUV4:2:0) resolution and high definition digital audio formats such as LPCM 7.1CH with audio sampling rates up to 192kHz, Dolby TrueHD, Dolby Digital Plus, Dolby Atmos and DTS-HD Master...
- Page 3 Operating Functions and Controls Front Panel POWER: This LED will illuminate to indicate the unit is on and receiving power. IN: This LED will illuminate to indicate that a live source has been detected on the input port. When no source is detected theLED will remain off.
- Page 4 OUT 1~4: Connect to HDMI TVs, monitors or amplifiers for digital video and audio output. Connection Diagram...
- Page 5 Specifications Video Bandwidth 300MHz/9Gbps Input Ports 1× HDMI, 1× USB(Service) Output Ports 4 × HDMI Supported Resolutions VGA~WUXGA 480i~1080p@60Hz 4K@24/25/30Hz (YUV4:4:4) 4K@50/60Hz (YUV4:2:0) HDMI Cable I/O Distance* 5M (4K@60Hz, YUV4:2:0, 8-bit) 10M (1080p@60Hz, 8-bit) Power Supply 5V/1.2A DC (US/EU standards, CE/FCC/ UL certified) ESD Protection Human Body model:...
- Page 6 DVI and HDMI Supported Resolutions Input Output 640x480@60/72/75/85Hz 800x600@56/60/72/75/85Hz 1024x768@60/70/75/85Hz 1280x1024@60Hz 1366x768@60Hz 1600x1200@60Hz 1920x1080@60Hz 1920x1200@60Hz 1440x576i@50Hz 1440x480i@59.94/60Hz 720x480p@59.94/60Hz ...
