1
PANEL DESCRIPTION
RX SPEAKER KEY
Push to turn the RX speaker functon ON or OFF.
When the RX speaker functon s turned ON, the receved
audo can be heard va the external speaker.
• Ths functon s avalable when the external speaker s addtonally
connected.
• Ths functon s useful when you are out of the vehcle.
• The audo output level s lnked to the transcever's volume control.
LIGHT KEY
Push to turn the transcever's backlght ON for about 5 sec.
when the backlght functon s turned OFF n user set mode.
LOCK KEY
Push and hold to electroncally lock all programmable keys
except the followng:
[Mon(Aud)], [Lght], [Lock], [Call] (ncl. Call A and Call B),
[Emergency Sngle], [Survellance], [Lone Worker] and [OPT 1/2/3].
LONE WORKER KEY
Push to turn the Lone Worker functon ON or OFF.
• If the Lone Worker functon s actvated, the Emergency functon s
automatcally turned ON after the specfied tme perod has passed
wth no operaton s performed.
HIGH/LOW KEY
Push to select the transmt output power temporarly or per-
manently, dependng on the pre-settng.
• Ask your dealer for the output power level for each selecton.
5
TONE/RAN CH SELECT KEY
➥ Whle n analog mode operaton, push to enter the con-
tnuous tone channel selecton mode. Then select the
desred tone frequency/code settng wth [CH Up] or
[CH Down]. After the selecton, push ths key agan to set.
➥ Whle n dgtal mode operaton*, push to enter the RAN
channel selecton mode. Then select the desred RAN set-
tng wth [CH Up] or [CH Down]. After the selecton, push
ths key agan to set.
➥ Whle n mxed (dgtal and analog) mode operaton*, push
to enter the contnuous tone channel selecton mode.
Then select the desred tone frequency/code settng wth
[CH Up] or [CH Down]. After the selecton, push ths key
to set. After that, the RAN channel selecton screen ap-
pears. Select the desred RAN settng wth [CH Up] or
[CH Down]. After the selecton, push ths key agan to set.
* Dgtal and mxed (dgtal and analog) mode operatons are aval-
able only when the optonal UT-126H
s nstalled. Ask your dealer for detals.
lator unit
C.TONE CH ENT KEY
Push to enter the contnuous tone channel selecton mode.
Then select the desred tone frequency/code settng wth
[CH Up] or [CH Down]. The selected channel remans set as
the contnuous tone channel untl another channel s desg-
nated as such.
-
digital modulator / demodu
