SECTION 6

[FRONT UNIT]

REF ORDER
NO. NO.
IC1 1130010800 S.IC
IC2 1130008560 S.IC
Q1 1590000720 S.TRANSISTOR
Q2 1590000430 S.TRANSISTOR
Q3 1590000430 S.TRANSISTOR
Q4 1590000720 S.TRANSISTOR
D1 1790001670 S.DIODE
D2 1790001670 S.DIODE
D3 1790001670 S.DIODE
D4 1790001250 S.DIODE
D5 1790001250 S.DIODE
D6 1790001250 S.DIODE
L1 6200003960 S.COIL
R1 7030003440 S.RESISTOR
R2 7030003440 S.RESISTOR
R3 7030003390 S.RESISTOR
R4 7030003390 S.RESISTOR
R5 7030003520 S.RESISTOR
R6 7030003440 S.RESISTOR
R7 7030000330 S.RESISTOR
R8 7410000950 S.ARRAY
R9 7410000770 S.ARRAY
R10 7030003680 S.RESISTOR
R11 7030003680 S.RESISTOR
R12 7210003020 VARIABLE
R13 7030003730 S.RESISTOR
R14 7030003680 S.RESISTOR
R16 7030003440 S.RESISTOR
R17 7030003560 S.RESISTOR
R18 7030003560 S.RESISTOR
R19 7030003560 S.RESISTOR
R20 7030003510 S.RESISTOR
R21 7030003800 S.RESISTOR
R22 7030003560 S.RESISTOR
R23 7030003560 S.RESISTOR
R24 7030003480 S.RESISTOR
R25 7030003640 S.RESISTOR
C1 4030007090 S.CERAMIC
C2 4030007090 S.CERAMIC
C3 4030007090 S.CERAMIC
C4 4030007090 S.CERAMIC
C5 4030007090 S.CERAMIC
C6 4030007090 S.CERAMIC
C7 4030007090 S.CERAMIC
C8 4030007090 S.CERAMIC
C9 4030007090 S.CERAMIC
C10 4030007090 S.CERAMIC
C11 4030007090 S.CERAMIC
C12 4030007090 S.CERAMIC
C13 4030007090 S.CERAMIC
C14 4030007090 S.CERAMIC
C15 4030007090 S.CERAMIC
C16 4030007090 S.CERAMIC
C17 4030007090 S.CERAMIC
C18 4030007090 S.CERAMIC
C19 4030006860 S.CERAMIC
C20 4030006860 S.CERAMIC
C21 4030007090 S.CERAMIC
C22 4030007090 S.CERAMIC
C23 4030007090 S.CERAMIC
C24 4030007090 S.CERAMIC
C25 4030007090 S.CERAMIC
C26 4030007090 S.CERAMIC
C27 4030007090 S.CERAMIC
C28 4030007090 S.CERAMIC
C29 4030007090 S.CERAMIC

PARTS LIST

DESCRIPTION
LC75824W
TC75S51F (TE85L)
DTA144EUA T106
DTC144EUA T106
DTC144EUA T106
DTA144EUA T106
RB706F-40T106
RB706F-40T106
RB706F-40T106
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
MLF1608A 1R0K-T
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 391 V (390 Ω)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
MCR10EZHJ 390 Ω (391)
EXB-V8V 102JV
EXB-V4V 102JV (1 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
EVU-F2KFK1 B14 (10KB)
ERJ3GEYJ 274 V (270 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 392 V (3.9 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 JB 1H 102K-T
C1608 JB 1H 102K-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
[FRONT UNIT]
REF ORDER
NO. NO.
C30 4030011600 S.CERAMIC
C31 4030011600 S.CERAMIC
C32 4030011600 S.CERAMIC
C33 4030007130 S.CERAMIC
C34 4030007090 S.CERAMIC
C35 4030007090 S.CERAMIC
C37 4550000550 S.TANTALUM
C39 4030006900 S.CERAMIC
C40 4550005980 S.TANTALUM
C41 4030006860 S.CERAMIC
J1 6450002210 CONNECTOR
J2 6510023090 S.CONNECTOR
DS1 5040002310 S.LED
DS2 5040002310 S.LED
DS3 5040002310 S.LED
DS4 5040002310 S.LED
DS5 5040002310 S.LED
DS6 5040002310 S.LED
DS7 5040002310 S.LED
DS8 5040002310 S.LED
DS9 5040002310 S.LED
DS10 5040002310 S.LED
DS11 5040002310 S.LED
DS12 5030002230 LCD
W1 8900010950 CABLE
EP1 0910054932 PCB
EP2 8930057820 LCD CONTACT
6 - 1
DESCRIPTION
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 JB 1E 104K-T
C1608 CH 1H 101J-T
C1608 CH 1H 470J-T
C1608 CH 1H 470J-T
TESVA 1V 224M1-8L
C1608 JB 1H 103K-T
TEMSVA 1A 475M-8L
C1608 JB 1H 102K-T
3017-8821
20FLT-SM1-TB
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
SML-311YTT86
L1-0483TAT
OPC-1126 (P=0.5 N=20 L=90)
B 5809B
SRCN-2526-SP-N-W
S.=Surface mount
