[MAIN UNIT]

REF ORDER
NO. NO.
IC1 1110003490 S.IC
IC2 1130008560 S.IC
IC3 1150002090 IC
1150002030 IC
1150002060 IC
IC4 1130010810 S.IC
IC5 1110005330 S.IC
IC6 1190001350 S.IC
IC7 1190001340 S.IC
IC8 1110003090 IC
IC9 1180001250 S.IC
IC10 1180000970 S.IC
IC11 1130008560 S.IC
IC14 1130009330 S.IC
IC15 1130006220 S.IC
IC18 1110002750 S.IC
IC19 1130009700 S.IC
IC20 1140010190 S.IC
IC21 1110005340 S.IC
IC22 1130004200 S.IC
IC23 1140009240 S.IC
IC24 1130009110 S.IC
IC25 1130004200 S.IC
Q1 1560000840 S.FET
Q2 1580000730 S.FET
Q3 1580000660 S.FET
Q4 1530002600 S.TRANSISTOR
Q5 1530002850 S.TRANSISTOR
Q6 1590000720 S.TRANSISTOR
Q8 1530000372 S.TRANSISTOR
Q9 1530003310 S.TRANSISTOR
Q10 1530003310 S.TRANSISTOR
Q11 1530003310 S.TRANSISTOR
Q12 1530003310 S.TRANSISTOR
Q13 1530002920 S.TRANSISTOR
Q14 1530002920 S.TRANSISTOR
Q15 1590001400 S.TRANSISTOR
Q16 1590000430 S.TRANSISTOR
Q17 1530002850 S.TRANSISTOR
Q18 1560000540 S.FET
Q19 1530002600 S.TRANSISTOR
Q20 1530003090 S.TRANSISTOR
Q21 1530002850 S.TRANSISTOR
Q22 1590000430 S.TRANSISTOR
Q23 1550000020 S.FET
Q24 1590000430 S.TRANSISTOR
Q25 1540000550 S.TRANSISTOR
Q26 1540000550 S.TRANSISTOR
Q27 1520000460 S.TRANSISTOR
Q28 1590001190 S.TRANSISTOR
Q29 1590000430 S.TRANSISTOR
Q30 1590000430 S.TRANSISTOR
Q31 1590001450 S.FET
Q32 1590000430 S.TRANSISTOR
Q33 1590000430 S.TRANSISTOR
Q34 1530002850 S.TRANSISTOR
Q35 1590001400 S.TRANSISTOR
Q36 1530002850 S.TRANSISTOR
Q37 1530002850 S.TRANSISTOR
Q38 1590000430 S.TRANSISTOR
Q39 1590000990 S.TRANSISTOR
Q40 1590000430 S.TRANSISTOR
Q41 1590000720 S.TRANSISTOR
Q42 1590000430 S.TRANSISTOR
Q43 1590000430 S.TRANSISTOR
Q44 1590000430 S.TRANSISTOR
Q48 1590000430 S.TRANSISTOR
Q49 1590000430 S.TRANSISTOR
Q50 1590000430 S.TRANSISTOR
Q51 1530002850 S.TRANSISTOR
D1 1790000660 S.DIODE
D2 1750000510 S.DIODE
D3 1710001060 DIODE
D4 1750000710 S.VARICAP
D5 1750000760 S.DIODE
D6 1790000620 S.DIODE
D8 1750000710 S.VARICAP
D9 1750000710 S.VARICAP
DESCRIPTION
TA31136FN (D, EL)
TC75S51F (TE85L)
RA30H4047M-01 [L]
RA30H4452M [M]-25W, [H]
RA45H4452M [M]-45W
SA7026DH-T
NJM12904V-TE1
M62364FP 600D
M62334FP 600C
LA4425A
TA7808F (TE16L)
AN78L05M-(E1)
TC75S51F (TE85L)
TC35453F (BR, DRY)
TC4W53FU (TE12L)
TA75S01F (TE85R)
LC73872M-TRM
HD64F2268TF (EMPTY)
NJM12902V-TE1
TC4S66F (TE85R)
HN58X24128FPI
S-80942ANMP-DD6-T2
TC4S66F (TE85R)
2SK1829 (TE85R)
3SK293 (TE85L)
3SK272-(TX)
2SC4215-O (TE85R)
2SC4116-BL (TE85R)
DTA144EUA T106
2SC3356 R24-T1B
2SC5107-O (TE85R)
2SC5107-O (TE85R)
2SC5107-O (TE85R)
2SC5107-O (TE85R)
2SC4226-T1 R25
2SC4226-T1 R25
XP1214 (TX)
DTC144EUA T106
2SC4116-BL (TE85R)
2SK880-Y (TE85R)
2SC4215-O (TE85R)
2SC4213-B (TE85R)
2SC4116-BL (TE85R)
DTC144EUA T106
2SJ377 (TE16R)
DTC144EUA T106
2SD1664 T100Q
2SD1664 T100Q
2SB1132 T100 R
XP6501-(TX) .AB
DTC144EUA T106
DTC144EUA T106
2SJ144-GR (TE85R)
DTC144EUA T106
DTC144EUA T106
2SC4116-BL (TE85R)
XP1214 (TX)
2SC4116-BL (TE85R)
2SC4116-BL (TE85R)
DTC144EUA T106
DTC363EK T146
DTC144EUA T106
DTA144EUA T106
DTC144EUA T106
DTC144EUA T106
DTC144EUA T106
DTC144EUA T106
DTC144EUA T106
DTC144EUA T106
2SC4116-BL (TE85R) [45W]
MA728 (TX)
UM9401F [25W]
XB15A407 [45W]
HVC350BTRF
MA4PH224
MA77 (TX)
HVC350BTRF
HVC350BTRF
[MAIN UNIT]
REF ORDER
NO. NO.
D10 1750000710 S.VARICAP
D11 1790000660 S.DIODE
D14 1790000620 S.DIODE
D15 1790000620 S.DIODE
D16 1750000710 S.VARICAP
D17 1750000710 S.VARICAP
D18 1720000570 S.VARICAP
D19 1790001250 S.DIODE
D20 1790001250 S.DIODE
D21 1750000830 S.VARICAP
D22 1790000700 DIODE
D23 1750000370 S.DIODE
D24 1750000370 S.DIODE
D25 1790001250 S.DIODE
D26 1790001250 S.DIODE
D27 1790000620 S.DIODE
D28 1750000520 S.DIODE
D30 1790001250 S.DIODE
D31 1750000520 S.DIODE
D32 1790001250 S.DIODE
D33 1790001250 S.DIODE
D34 1790001250 S.DIODE
D35 1750000520 S.DIODE
D36 1750000520 S.DIODE
D37 1750000520 S.DIODE
FI1 2010002450 S.XTAL
2030000150 S.MONOLITH
FI2 2020001840 CERAMIC
FI3 2040001440 S.LC
FI4 2040001440 S.LC
FI5 2040001440 S.LC
X1 6070000190 S.DISCRIMINATOR CDBCB450KCAY24-R0
X2 6050011120 S.XTAL
X3 6050009910 S.XTAL
X4 6050009520 S.XTAL
L1 6110001520 COIL
6110002110 COIL
L2 6110001520 COIL
L3 6110002110 COIL
L4 6200008330 S.COIL
L5 6170000230 COIL
L6 6200008330 S.COIL
L7 6200007230 S.COIL
6200007670 S.COIL
L8 6200007680 S.COIL
6200007670 S.COIL
L9 6200007680 S.COIL
6200007670 S.COIL
L11 6200007680 S.COIL
6200007670 S.COIL
L12 6200005720 S.COIL
L13 6200003350 S.COIL
L16 6110001520 COIL
6110002110 COIL
L18 6200005690 S.COIL
6200005680 S.COIL
L19 6200005690 S.COIL
6200005680 S.COIL
L20 6200005710 S.COIL
6200005700 S.COIL
L21 6200005710 S.COIL
6200005700 S.COIL
L22 6200005710 S.COIL
L23 6200004950 S.COIL
L24 6200004950 S.COIL
L25 6200009360 S.COIL
L26 6200009360 S.COIL
L27 6200004950 S.COIL
L28 6200004950 S.COIL
L29 6200004950 S.COIL
L31 6200007740 S.COIL
L32 6200005690 S.COIL
6200005680 S.COIL
L33 6200002850 S.COIL
L35 6200002840 S.COIL
L36 6200002860 S.COIL
6 - 2
DESCRIPTION
HVC350BTRF
MA728 (TX)
MA77 (TX)
MA77 (TX)
HVC350BTRF
HVC350BTRF
MA368 (TX)
MA2S111-(TX)
MA2S111-(TX)
HVC362TRF
DSA3A1
DA221 TL
DA221 TL
MA2S111-(TX)
MA2S111-(TX)
MA77 (TX)
DAN222TL
MA2S111-(TX)
DAN222TL
MA2S111-(TX)
MA2S111-(TX)
MA2S111-(TX)
DAN222TL
DAN222TL
DAN222TL
FL-313 (46.35 MHz) [USA], [GEN]
FL-335 (46.350 MHz) [EUR]
ALFYM450F=K
NFE31PT152Z1E9L
NFE31PT152Z1E9L
NFE31PT152Z1E9L [45W]
CR-671A (15.300 MHz)
CR-563 (3.579545 MHz)
CR-520 (19.6608 MHz+)
LA-232 [25W]
LA-382 [45W]
LA-232
LA-382
0.45-1.4-4TL 15N
LW-25
0.45-1.4-4TL 15N
LQW2BHN15NJ01L [L]
LQW2BHN10NJ01L [M], [H]
LQW2BHN12NJ01L [L]
LQW2BHN10NJ01L [M], [H]
LQW2BHN12NJ01L [L]
LQW2BHN10NJ01L [M], [H]
LQW2BHN12NJ01L [L]
LQW2BHN10NJ01L [M], [H]
ELJRE 33NG-F
ELJNC R27K-F
LA-232 [25W]
LA-382 [45W]
ELJRE 18NG-F [L]
ELJRE 15NG-F [M], [H]
ELJRE 18NG-F [L]
ELJRE 15NG-F [M], [H]
ELJRE 27NG-F [L]
ELJRE 22NG-F [M], [H]
ELJRE 27NG-F [L]
ELJRE 22NG-F [M], [H]
ELJRE 27NG-F
NL 252018T-1R8J
NL 252018T-1R8J
0.45-1.4-3TL 11N
0.45-1.4-3TL 11N
NL 252018T-1R8J
NL 252018T-1R8J
NL 252018T-1R8J
LQW2BHN47NJ01L
ELJRE 18NG-F [L]
ELJRE 15NG-F [M], [H]
NL 252018T-R82J
NL 252018T-R22J
NL 252018T-4R7J
S.=Surface mount
