Owners &
Installation
LISTINGS AND CODE APPROVALS
These gas appliances have been
tested in accordance with AG 103,
NZS 5262 and have been certified
by the Australian Gas Association
for installation and operation as
described in these Installation and
Operating Instructions.
Your unit should be serviced
annually by an authorised
service person.
G51 Surefire
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper
installation,
alteration, service or maintenance can
cause injury or property damage. Refer to
this manual. For assistance or additional
information consult an authorised installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapours and liquids in the vicinity
of this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
Australia
P.O. Box 533
Braeside, Victoria
3195
918-257
FOR YOUR SAFETY
adjustment,
What to do if you smell gas:
New Zealand
1-37 Mt
Wellington Hwy.Panmure,
P.O. Box 14349
Auckland 6.
Models: G51-NG
G51-LPG
Do not try to light any appli-
ance
Do not touch any electrical
switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fire
department.
02/02/04
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Masport Masport G51-NG
Summary of Contents for Masport Masport G51-NG
- Page 1 Owners & Installation G51 Surefire Models: G51-NG G51-LPG PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, What to do if you smell gas: alteration, service or maintenance can Do not try to light any appli- cause injury or property damage.
- Page 2 TO THE NEW OWNER: Congratulations! You are the owner of a state-of-the-art Gas Stove by FPI FIREPLACE PRODUCTS INTERNATIONAL LTD. The G51 has been designed to provide you with all the warmth and charm of a wood fireplace at the flick of a switch.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Operating Instructions Safety Label Safety Label ............... 4 Operating Instructions ..........17 Lighting Procedure ............ 17 Shutdown Procedure ..........17 First Fire ..............17 Installation Normal Operating Sounds of Unit Dimensions ............5 Gas Appliances ..........17 Important Message ............ -
Page 4: Safety Label
SAFETY LABEL NOTE: Masport units are constantly being im- This is a copy of the label that accompanies proved. Check the label on the unit and if there each G51 Gas Fireplace. is a difference, the label on the unit is the correct one. -
Page 5: Unit Dimensions
UNIT DIMENSIONS Masport G51 Surefire... -
Page 6: Important Message
INSTALLATION IMPORTANT: INSTALLATION BEFORE YOU START SAVE THESE CHECKLIST Installation is to be carried out ONLY by an INSTRUCTIONS authorised person. The Masport Gas Insert is installed as listed below. 1) The appliance shall be installed in accord- The Masport Gas Fireplace must be installed in ance with the manufacturer's installation accordance with these instructions. -
Page 7: Minimum Fireplace Dimensions
INSTALLATION MINIMUM FIREPLACE GAS CONNECTION MINIMUM DIMENSIONS CLEARANCES TO GAS CONNECTION WARNING: COMBUSTIBLES Only persons licensed to work with The minimum fireplace dimensions for the Masport gas space heater are shown in the gas piping may make the necessary The minimum fireplace clearances for the following diagrams: gas connections to this appliance. -
Page 8: Flueing
INSTALLATION FLUEING GAS AERATION TEST FOR FLUE SYSTEM SPILLAGE THE APPLIANCE MUST NOT BE CONNECTED TO A CHIMNEY FLUE SERVING A SEPARATE The aeration adjustment rod is attached to the A "spillage" test must be made before SOLID FUEL BURNING APPLIANCE. air shutter which is located just above the the installed unit is left with the custom- orifice bracket. -
Page 9: Valve Tray Installation
INSTALLATION VALVE TRAY INSTALLATION 1) Line up valve tray with 4 holes in firebox and secure with screws. 3) Place the valve shield over the valve and secure with screw. Screw Valve Shield 4) Install the valve cover by aligning it with the 3 holes in the firebox and secure with screws. -
Page 10: Burner Installation
INSTALLATION BURNER INSTALLATION 1) Fit burner tube into orifice. Burner Tube Orifice Secure burner to valve tray. 2) Secure burner to the valve tray using one screw. 3) Close valve cover. Screw location in valve tray. Valve Cover Masport G51 Surefire... -
Page 11: Log Set Installation
INSTALLATION LOG SET INSTALLATION Carefully read the instructions below and refer to the diagrams. If logs are broken do not use the unit until they are replaced. Broken logs can interfere with the pilot operation. The gas log kit (Part #390-930) contains the following pieces: 02-95 a) 02-55 Middle Left Log... - Page 12 INSTALLATION 02-95 02-96 02-51 02-50 Fit notch into 2nd grate tab. Fit notch onto left side of grate. 5) Place the bottom left front edge of Log 02-55 against the rear bracket on the burner tray and rest the log on the cutout in Log 02-96. 7) Position Log 02-97 across the cutouts in Logs 02-51 and 02-96.
- Page 13 INSTALLATION 9) Place the embers lava on the front of the burner tray as shown in the circled areas in the picture below. 02-52 02-97 Embers Lava Ensure not to block the burner ports. Cutout Bracket 10) Test fire to ensure proper light off (make sure flame flows smoothly from one end of burner to the other).
-
Page 14: Finishing Trim Installation
INSTALLATION FINISHING TRIM BRICK PANEL INSTALLATION INSTALLATION 5) Install the brick retaining clips, one on each 1) Remove screen door, if used. 1) Fit the left side finishing trim onto the firebox side to secure the side brick panels in by sliding the cut-outs on the finishing trim place. -
Page 15: Screen Installation (Optional)
INSTALLATION OPTIONAL SCREEN INSTALLATION 3) Pull up the spring loaded pin at the bottom of 1) Install the 3 brackets as shown. 2) Fit the pin on top of the screen into the pin the screen and rest it in the pin hole of the hole located in the top right bracket. -
Page 16: Wiring
INSTALLATION WIRING This heater does not require a 240V A.C. supply Caution: Ensure that the wires do CAUTION: Label all wires prior to for the gas control to operate. A 240V A.C. not touch any hot surfaces and are disconnection when servicing con- power supply is needed for the fan/blower away from sharp edges. -
Page 17: Operating Instructions
OPERATING INSTRUCTIONS 4) Fully press the ignition button and ignite the OPERATING NORMAL OPERATING pilot burner by continously depressing the INSTRUCTIONS SOUNDS OF piezo ignitor. Once the pilot has lit, continue holding in the ignition button for approxi- GAS APPLIANCES mately 10 seconds to ensure the pilot stays Before operating this appliance, proceed on. -
Page 18: Lighting Plate Instructions
OPERATING INSTRUCTIONS COPY OF LIGHTING PLATE INSTRUCTIONS FOR YOUR SAFETY READ BEFORE LIGHTING This appliance must be installed in accordance with local codes, if any; if not, follow current CAN1-B149/ANSI Z223.1 Australia: AG 601/New Zealand: NZS 5261. WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. -
Page 19: Maintenance
MAINTENANCE MAINTENANCE LOG REPLACEMENT CLOTHING OR OTHER FLAMMA- INSTRUCTIONS BLE MATERIAL SHOULD NOT BE The unit should never be used with broken logs. PLACED ON OR NEAR THE APPLI- Turn off the gas valve and allow the unit to cool, ANCE. -
Page 20: Fan Replacement
MAINTENANCE FAN REPLACEMENT 9) Partially lift out fan. 1) Shut off power supply. 2) Remove screen door. 3) Remove logs. 4) Remove burner. 5) Remove brick panels. 6) Remove the 2 screws which secure the rear log tray. 10) Disconnect the ground wire. Rear Log Tray 7) Remove the fan cover plate by undoing the 11 screws and carefully lift out. -
Page 21: Replacement Parts List
REPLACEMENT PARTS Part # Description 390-033 Hood Pilot 390-510/P Valve Assembly - NG 390-511/P Valve Assembly - LPG 390-525 Burner Assembly - NG/LPG 511-031 Clip Brick 560-519/P Fan Assembly 390-000 Grate Assembly 390-930 Log Set 904-258 Magnet Ceramic 904-658 Inlet Flex Line Gas E61 904-777 Orifice #29 NG 904-652... - Page 22 NOTES _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ ____________________________________________________________ __________________________________________________________ ____________________________________________________________...
-
Page 23: Warranty
WARRANTY THE MASPORT EXPRESS WARRANTY All new Masport Gas appliances are warranted, subject to the This Express Warranty Does Not Cover: following conditions, to be free from defects in material or 1. Defects, malfunctions or failures caused by incorrect instal- workmanship under normal use. - Page 24 Printed in Canada © Copyright 2004, FPI Fireplace Products International Ltd. All rights reserved.
