Owners &
Installation
LISTINGS AND CODE APPROVALS
These gas appliances have been
tested in accordance with AG 103,
NZS 5262 and have been certified by
the Australian Gas Association for
installation and operation as
described in these Installation and
Operating Instructions.
Your unit should be serviced
annually by an authorised service
person.
Freestanding Gas Stove
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper
installation,
alteration, service or maintenance can
cause injury or property damage. Refer to
this manual. For assistance or additional
information consult an authorised installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapours and liquids in the vicinity
of this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
Head Office - New Zealand
1-37 Mt Wellington Hwy.Panmure,
P.O. Box 14349
Auckland 6.
918-244b
Models: FG38-NG
FOR YOUR SAFETY
adjustment,
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electrical
switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fire
department.
Australia
P.O. Box 533
Braeside, Victoria, 3195
FG38-LPG
06/08/05
Advertisement
Table of Contents
Related Manuals for Masport FG38-NG
Summary of Contents for Masport FG38-NG
- Page 1 Owners & Installation Freestanding Gas Stove Models: FG38-NG FG38-LPG PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, What to do if you smell gas: alteration, service or maintenance can Do not try to light any appli- cause injury or property damage.
-
Page 2: Specifications
The models FG38-NG, and FG38-LPG of this series has been approved by AGA for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. -
Page 3: Table Of Contents
Remote Control (optional) ..........12 Electronic Components ..........19 Final Check ..............12 Main Assembly ............20 Wiring Diagram ............12 Burner & Log Assembly ..........21 Door Assemblies ............22 Warranty Warranty ..............23 Masport FG38 FireGenie Freestanding Gas Stove... -
Page 4: Safety Label
SAFETY LABEL This is a copy of the label that accompanies NOTE: Masport units are constantly being im- each Freestanding Gas Stove. We have print- proved. Check the label on the unit and if there ed a copy of the contents here for your review. -
Page 5: Installation
ESPECIALLY THE FIREPLACE 10) Installation and any repairs to this appliance The Masport Freestanding Gas Heater can be GLASS, AND SHOULD STAY AWAY should be done by an authorised service installed in a wide variety of ways and will fit person. -
Page 6: Installation Checklist
Fasten but do not penetrate the inner sleeve of the flue when tightening the screw. The minimum flue required is 3.3m from floor level. Follow all flueing manufacturer’s requirements and local building codes or AG 601. Masport FG38 FireGenie Freestanding Gas Stove... -
Page 7: Gas Connection
FG38 1) On-Off Solenoid Valve EV1 The gas line should be rigid pipe. Copper may FG38-NG: For 0 to 610 meters altitude 2) On-Off Solenoid Valve EV2 also be used if approved by AG 601. FG38-LPG: For 0 to 610 meters altitude 3) Inlet Pressure Test Point The gas connection at the valve is 1/2 male. -
Page 8: Conversion From Ng To Lpg
10) Carefully pull out the control box. These instructions must be left with the appliance. NOTE: The outlet pressure must be set to NOTE: The control box is held in place with maximum 2.65 kPa. velcro. Masport FG38 FireGenie Freestanding Gas Stove... -
Page 9: Aeration Adjustment
1) Carefully remove the logs from the box and unwrap them. The logs are fragile, handle C)02-44 with care - do not force into position. 2) Sprinkle the embers on the left and right sides of the firebox base. Embers Embers Masport FG38 FireGenie Freestanding Gas Stove... - Page 10 8) Place the lava rock in the area between the left and right logs, leaving a space in the middle for log (F) 02-47. Ensure that the lava rocks are not placed directly over the burner ports. A)02-65 B)02-56 E)02-45 C)02-44 Masport FG38 FireGenie Freestanding Gas Stove...
-
Page 11: Front Door Installation
If they are too hard or too easy to close, you may want to adjust them by loosening the latch catch. See diagram 3. 5) Remove the blue plastic protective coating from the glass. Masport FG38 FireGenie Freestanding Gas Stove... -
Page 12: Remote Control (Optional)
INSTALLATION REMOTE CONTROL FINAL CHECK Use the Masport Remote Control Kit approved Before leaving this unit with the customer, the installer must ensure that the appliance is firing for this unit. Use of other systems may void your correctly. This includes: warranty. -
Page 13: Operating Instructions
DO NOT ATTEMPT TO CLEAN THE GLASS WHILE IT IS STILL HOT! DO NOT BURN THE APPLIANCE WITH- OUT THE GLASS FRONT IN PLACE. Masport FG38 FireGenie Freestanding Gas Stove... -
Page 14: Flame Height Adjustment
(+) button once will Blower: increase the flame height to the next available Masport gas appliances use high tech blowers high setting. to push heated air farther into the room. It is not unusual for the fan to make a "whirring" sound Decrease - If the unit is switched on, pressing when ON. -
Page 15: Copy Of Lighting Plate Instructions
You may shut off the pilot during prolonged non use periods to conserve fuel. 918-247 DO NOT REMOVE THIS INSTRUCTION PLATE WARNING: DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IN OPERATION. Masport FG38 FireGenie Freestanding Gas Stove... -
Page 16: Maintenance
REPLACEMENT ICING AN APPLIANCE MUST BE REPLACED PRIOR TO OPERAT- Any maintenance required accessing the Your Masport heater is supplied with high glass door of the unit must be performed by ING THE APPLIANCE. temperature, 5mm Neoceram silica coated ce- an authorized service person. -
Page 17: Fan Maintenance
Diagram 2 Replacing FG38 Fan: Reverse the above steps (1 to 4). If necessary install a new gasket before replacing the fan access panel. Make sure the fan wires and the ground wire are reattached. Masport FG38 FireGenie Freestanding Gas Stove... -
Page 18: Removing Valve
See diagram below. 12) To replace the burner tray assembly, sim- ply reverse these instructions. 9 Pin Connector Masport FG38 FireGenie Freestanding Gas Stove... -
Page 19: Parts List
910-912 Ignition Module to Valve Cable 910-906 Reset Switch 910-083 Ignition Module (1) 910-916 Ignition Module (2) 910-514 Jumper * Note: The Control Box Cable wires for the FG38 come separately: 910-502, 910-505, 910-506, 910-507, 910-509 Masport FG38 FireGenie Freestanding Gas Stove... -
Page 20: Main Assembly
Pedestal Back 948-217 Logo Plate 918-244 Manual 19) 756-518 Side Panel Door Assy (Right Side) 20) 756-520 Side Panel Door Assy (Left Side) *Not available as a replacement part. 21) 560-031 Hinge for Side Panel Masport FG38 FireGenie Freestanding Gas Stove... -
Page 21: Burner & Log Assembly
93) 902-231 Left Top Log 94) 902-232 Center Log 95) 902-226 Middle Right Log 96) 902-230 Middle Left Log 97) 902-229 Front Right Log 98) 902-228 Front Left Log *Not available as a replacement part. Masport FG38 FireGenie Freestanding Gas Stove... -
Page 22: Door Assemblies
Ceramic Paper 106) 940-323/P Side Glass 107) 936-243 Glass Gasket 108) 940-322/P Centre Glass 111) * Door Frame Fibre Paper 112) 750-015 Door Glass Extrusion 208) 940-325/P Wrap Glass *Not available as a replacement part. Masport FG38 FireGenie Freestanding Gas Stove... -
Page 23: Warranty
WARRANTY THE MASPORT EXPRESS WARRANTY All new Masport Gas appliances are warranted, subject to the This Express Warranty Does Not Cover: following conditions, to be free from defects in material or 1. Defects, malfunctions or failures caused by incorrect installa- workmanship under normal use. - Page 24 Printed in Canada © Copyright 2005, FPI Fireplace Products International Ltd. All rights reserved.
