Owners &
Installation
LISTINGS AND CODE APPROVALS
These gas appliances have been
tested in accordance with AG 103,
NZS 5262 and have been certified by
the Australian Gas Association for
installation and operation as
described in these Installation and
Operating Instructions.
Your unit should be serviced
annually by an authorised service
person.
Freestanding Gas Stove
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper installation, adjustment, altera-
tion, service or maintenance can cause
injury or property damage. Refer to this
manual. For assistance or additional infor-
mation consult an authorized installer, serv-
ice agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flamma-
ble vapours and liquids in the vicinity of this
or any other appliance.
Installation and service must be performed
by an authorized installer, service agency or
the gas supplier.
Australia
P.O. Box 533
Braeside, Victoria
3195
918-186
Models: F38-NG1
F38-LP1
FOR YOUR SAFETY
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electrical
switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fire
department.
New Zealand
1-37 Mt
Wellington Hwy.Panmure,
P.O. Box 14349
Auckland 6.
Ph.
(9) 570-9009
Fax. (9) 527-1294
Natural Gas
Propane
06/24/03
Advertisement
Table of Contents
Related Manuals for Masport F38-NG1
Summary of Contents for Masport F38-NG1
- Page 1 Owners & Installation Freestanding Gas Stove Models: F38-NG1 Natural Gas F38-LP1 Propane PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, altera- What to do if you smell gas: tion, service or maintenance can cause Do not try to light any appli- injury or property damage.
-
Page 2: Specifications
The models F38-NG1, and F38-LP1 of this series has been approved by AGA for both safety and efficiency. As it also bears our own mark, it promises to provide you with economy, comfort and security for many trouble free years to follow. -
Page 3: Table Of Contents
Front Door Installation ..........11 Parts List ..............20 Test for Flue Spillage ..........11 Optional Wall Thermostat ..........12 Warranty Optional Remote Control ..........12 Warranty ..............23 Final Check ..............12 Wiring Diagram ............13 Masport F38-1 Freestanding Gas Heater... -
Page 4: Safety Label
SAFETY LABEL This is a copy of the label that accompanies NOTE: Masport units are constantly being im- each Freestanding Gas Stove. We have print- proved. Check the label on the unit and if there ed a copy of the contents here for your review. -
Page 5: Installation
10) Installation and any repairs to this appliance should be done by an authorised service GLASS, AND SHOULD STAY AWAY The Masport Freestanding Gas Heater can be person. An authorised service person TO AVOID BURNS OR CLOTHING installed in a wide variety of ways and will fit should be called to inspect this appliance nearly any room layout. -
Page 6: Installation Checklist
This heater is equipped with 10) Final check, page 12. a flue safety shutoff system. F38-NG1 & F38-LP1 Clearances Before leaving this unit with the customer, the WARNING: Operation of this heater when A Side Wall to Unit 7-1/2"... -
Page 7: Gas Connection
Fasten but do not penetrate the inner sleeve of F38-1 the flue when tightening the screw. 1) Gas cock knob F38-NG1: For 0 to 610 meters altitude 2) Manual high/low adjustment The minimum flue required is 3.3m from floor F38-LP1: For 0 to 610 meters altitude level. -
Page 8: Conversion From Natural Gas To Propane
(E) supplied with the kit. Tighten screws securely. with the appliance. 15) Check operation of flame control. 6) Pull off the pilot cap to expose the pilot 16) Check for proper flame appearance and orifice. glow on logs. Masport F38-1 Freestanding Gas Stove... -
Page 9: Aeration Adjustment
1) Carefully remove the logs from the box and unwrap them. The logs are fragile, handle with care - do not force into position. 2) Sprinkle the embers on the left and right sides of the firebox base. Embers Embers Masport F38-1 Freestanding Gas Heater... - Page 10 8) Place the lava rock in the area between the left and right logs, leaving a space in the middle for log (F) 02-47. Ensure that the lava rocks are not placed directly over the burner ports. A)02-65 B)02-56 E)02-45 C)02-44 Masport F38-1 Freestanding Gas Stove...
-
Page 11: Front Door Installation
If they are too hard or too easy to close, you may want to adjust them by loosening the latch catch. See diagram 3. 5) Remove the blue plastic protective coating from the glass. Masport F38-1 Freestanding Gas Heater... -
Page 12: Optional Wall Thermostat
THERMOSTAT Before leaving this unit with the customer, the installer must ensure that the appliance is firing Use the Masport Remote Control Kit approved A wall thermostat may be installed if desired. correctly. This includes: for this unit. Use of other systems may void Connect the wires as per the wiring diagrams. -
Page 13: Wiring Diagram
Caution: Ensure that the wires do not should be plugged directly into a prop- touch any hot surfaces and are away erly grounded three-prong receptacle. from sharp edges. Do not cut or remove the grounding prong from this plug. Masport F38-1 Freestanding Gas Heater... -
Page 14: Operating Instructions
If you smell gas, follow DO NOT BURN THE APPLIANCE OPERATION the instructions on the front of this manual. WITHOUT THE GLASS FRONT IN If you don't smell gas continue on to the next PLACE. step. Masport F38-1 Freestanding Gas Stove... -
Page 15: Copy Of Lighting Plate Instructions
2) Turn off all electric power to the appliance if clockwise to “OFF”. Do not force. service is to be performed. DO NOT REMOVE THIS INSTRUCTION PLATE 908-649 WARNING: DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IN OPERATION. Masport F38-1 Freestanding Gas Heater... -
Page 16: Pilot Adjustment
Blower: Masport gas appliances use high tech blowers to push heated air farther into the room. It is not unusual for the fan to make a "whirring" sound when ON. This sound will increase or decrease in volume depending on the speed setting of your fan speed control. -
Page 17: Maintenance
PLACED ON OR NEAR THE APPLI- ANCE. 1) Always shut the valve off before cleaning. Your Masport heater is supplied with high For relighting, refer to lighting instructions. temperature, 5mm Neoceram silica coated ce- Keep the burner and control compartment... -
Page 18: Fan Maintenance
Note: The unit MUST NOT be operated without the fan access panel se- curely in place and correctly sealed. Diagram 1 Masport F38-1 Freestanding Gas Stove... -
Page 19: Removing Valve
Note: Use a lay the panel on a soft cloth so it doesn't get magnetic type screwdriver. marked up. See diagram below. 8) Remove eight 1/4" hex head screws hold- ing the burner tray assembly in place. Masport F38-1 Freestanding Gas Heater... -
Page 20: Parts List
20) 756-520 Side Panel Door Assy (Left Side) 21) 560-031 560242 Hinge for Side Panel *Not available as a replacement part. 23) 904-258 551891 Side Panel Door Magnet 24) 948-255 556074 Door Latch c/w Hook Masport F38-1 Freestanding Gas Stove... - Page 21 93) 902-231 Left Top Log 94) 902-232 Center Log 95) 902-226 Middle Right Log 96) 902-230 Middle Left Log 97) 902-229 Front Right Log 98) 902-228 Front Left Log *Not available as a replacement part. Masport F38-1 Freestanding Gas Heater...
- Page 22 Ceramic Paper 106) 940-323/P Side Glass 107) 936-243 Glass Gasket 108) 940-322/P Centre Glass 111) * Door Frame Fibre Paper 112) 750-015 Door Glass Extrusion 208) 940-325/P Wrap Glass *Not available as a replacement part. Masport F38-1 Freestanding Gas Stove...
-
Page 23: Warranty
WARRANTY THE MASPORT EXPRESS WARRANTY All new Masport Gas appliances are warranted, subject to the This Express Warranty Does Not Cover: following conditions, to be free from defects in material or 1. Defects, malfunctions or failures caused by incorrect workmanship under normal use. The Express Warranty on all... - Page 24 © FPI Fireplace Products International Ltd. 2003 Printed in Canada...
