Freestanding Gas Stove
PLEASE KEEP THESE INSTRUCTIONS
FOR FUTURE REFERENCE
WARNING:
Improper
installation,
alteration, service or maintenance can
cause injury or property damage. Refer to
this manual. For assistance or additional
information consult an authorised installer,
service agency or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapours and liquids in the vicinity
of this or any other appliance.
Installation and service must be performed
by an authorised installer, service agency or
the gas supplier.
Head Office - New Zealand
1-37 Mt Wellington Hwy.Panmure,
P.O. Box 14349
Auckland 6.
918-363
Models: FG37-NG
FOR YOUR SAFETY
adjustment,
What to do if you smell gas:
Do not try to light any appli-
ance
Do not touch any electrical
switch: do not use any
phone in your building.
Immediately call your gas
supplier from a neighbour's
phone. Follow the gas sup-
plier's instructions.
If you cannot reach your
gas supplier, call the fire
department.
Australia
P.O. Box 533
Braeside, Victoria, 3195
FG37-LPG
01/06/05
Advertisement
Table of Contents
Related Manuals for Masport FireGenie FG37-NG
Summary of Contents for Masport FireGenie FG37-NG
- Page 1 Owners & Installation Freestanding Gas Stove Models: FG37-NG FG37-LPG PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE WARNING: FOR YOUR SAFETY Improper installation, adjustment, What to do if you smell gas: alteration, service or maintenance can Do not try to light any appli- cause injury or property damage.
-
Page 2: Specifications Diagram
Fireplace Products International. The Masport Gas Series of hand crafted appliances has been designed to provide you with all the warmth and charm of a woodstove, at the flick of a switch. The models FG37-NG, and F37-LPG of this series has been approved by Warnock Hersey for both safety and efficiency. -
Page 3: Table Of Contents
Gas Pipe Pressure Testing ........17 Valve Description ............17 Warranty ..............31 Louvre Installation ............17 Optional Remote Control Installation ......18 Final Check ............... 18 Wiring Diagram ............18 FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 4: Data Plate
AGA Approval number to accordance with Code AG103 6240 6240 installation instructions provided with the appliance Serial Electrical: 240VAC 50Hz 1.0 amp max. N2134 Number 918-364 (Australia Only) FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 5: Installation
Make it a practice to have all of BURNERS AND CIRCULATING AIR your gas appliances checked annually. PASSAGEWAYS OF THE APPLI- 13) Do not slam shut or strike the glass door. ANCE BE KEPT CLEAN. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 6: Installation Checklist
This unit can be installed on a solid combustible surface like a wood floor. This unit can also be installed directly on carpeting or vinyl when the bottom pedestal cover plate (provided with unit ) is installed. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 7: Exterior Flue Terminal Locations
(IV)A flue terminal of this type shall not be located under a roofed area unless the roofed area is fully open on at least two sides and a free flow of air at the appliance is achieved. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 8: Fluing Installation Precautions
For corner installation, Restrictor must For straight rear installation, Restric- be set at 1-1/4" (32mm) open. tor must be set at 1-1/8" (29mm) open. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 9: Fluing Arrangements - Vertical Terminations
Tighten the screws. Vent Restrictor Vent Restrictor Vent Vent (fully open) Restrictor Restrictor Plate Plate FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 10: Fluing: Residential And Manufactured
MOBILE HOMES INSTALLATIONS You will require the following components with your new Masport Rear Flued Room Sealed Freestanding Gas Stove. Please review your product to make sure you have everything you need. In the event that you are missing any part, contact your dealer. - Page 11 See diagram 5. Diagram 4 FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater...
-
Page 12: Vertical Termination With Co-Linear Flex System
System Data - FG37 with flashing Burner Inlet Orifice Sizes: Max. Input Rating 31.7 mj Min. Input Rating 16 mj Supply Pressure min. 1.13 kPa min. 2.75 kPa Manifold Pressure .89 kPa 2.55 kPa FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 13: Conversion From Ng To Lpg
15) Carefully pull out the control box. Pilot Tube Note: The control box is held in place by velcro. 16) Remove the control box cover by undoing the 3 screws. Maneuver through antenna. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... - Page 14 Put back the modulator plastic cap. WARNING: To ensure the correct opera- tion of the modulator it is necessary that the plastic cap (A) is returned to its original location. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater...
-
Page 15: Aeration Adjustment
Caution: Carbon will be produced if the air shutter is closed too much. Embers Embers Note: Any damage due to carboning re- sulting from improperly setting the aeration controls is NOT cov- ered under warranty. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 16: Door Installation
Note: The door latch may require ad- justment as the door gasket ma- terial compresses after a few fires and after glass replace- E)02-45 ment. Turn the latch catch in- ward or outward. Notch Cutout Diagram 3 FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 17: Gas Pipe Pressure Testing
6) When finished reading manometer, turn off the gas valve, disconnect the hose and tighten the screw (clockwise) with a 1/8" flat screwdriver. Note: Screw should be snug, but do not over tighten FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 18: Optional Remote Control Installation
This appliance is equipped with a three pronged (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-prong receptacle. Do not cut or remove the grounding prong from this plug. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 19: Operating Instructions
DO NOT ATTEMPT TO CLEAN THE GLASS WHILE IT IS STILL HOT! DO NOT BURN THE APPLIANCE WITH- OUT THE GLASS FRONT IN PLACE. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 20: Normal Operating Sounds Of Gas Appliances
Unit Body/Firebox: Different types and thicknesses of steel will expand and contract at different rates resulting in some "cracking" and "ticking" sounds will be heard throughout the cycling process. Front of Burner FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 21: Copy Of Lighting Plate Instructions
Turn off all electric power to the unit if service is to be performed. DO NOT REMOVE THIS INSTRUCTION PLATE 918-332 WARNING: DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IN OPERATION. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 22: Maintenance
Replace the embers - do not block the pilot or burner ports. 5) Keep the area near the appliance clear and free from combustible materials, gasoline and other flammable vapours and liquids. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 23: Latch Adjustment
(3) c. tighten top & bottom inside corners (2) 1) Remove the door from the unit and place on a soft surface to prevent scratching. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 24: Fan Maintenance
Do not cut or remove the grounding prong from this plug. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 25: Removing Valve
13) To replace the burner tray assembly, pedestal door is open it doesn't scratch the reverse these instructions. paint. See diagram below. 6) Disconnect the manual switch cable and reset cables. Manual Switch Reset Cables Cable FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... -
Page 26: Parts List
Cable Tie Mounting Button (Right Side) 20) 730-525 Side Panel Door Assy (Left Side) 21) 560-031 Side Panel Door Hinge 23) 904-258 Side Panel Door Magnet 24) 948-255 Door Latch - c/w J-Hook FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater... - Page 27 Front Right Log 71) 730-528 Log Stand Front Left Log 904-390 Pilot Orifice #52 - NG 75) 730-935 Log Set *Not available as a replacement part. 78) 730-550 Burner Assy - NG/LP FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater...
- Page 28 Side Glass 107) 936-243 Glass Gasket 108) 940-322/P Centre Glass 111) * Door Frame Fibre Paper 112) 750-015 Door Glass Extrusion 208) 940-325/P Wrap Glass *Not available as a replacement part. FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater...
- Page 29 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ ____________________________________________________________ __________________________________________________________ ____________________________________________________________ _______________________________________________________ _____________________________________________________ __________________________________________________________ _________________________________________________________ _________________________________________________________ ______________________________________________________ ______________________________________________________ _______________________________________________________________ ___________________________________________________________ __________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ _____________________________________________________________ __________________________________________________________ __________________________________________________________ _____________________________________________________ ________________________________________________________ _________________________________________________________ _________________________________________________________ FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater...
- Page 30 _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ ____________________________________________________________ __________________________________________________________ ____________________________________________________________ _______________________________________________________ _____________________________________________________ __________________________________________________________ _________________________________________________________ _________________________________________________________ ______________________________________________________ ______________________________________________________ _______________________________________________________________ ___________________________________________________________ __________________________________________________________ ____________________________________________________________ ____________________________________________________________ ____________________________________________________________ _____________________________________________________________ __________________________________________________________ __________________________________________________________ _____________________________________________________ ________________________________________________________ _________________________________________________________ _________________________________________________________ FG37 Masport Rear Flued Room Sealed Freestanding Gas Heater...
-
Page 31: Warranty
WARRANTY THE MASPORT EXPRESS WARRANTY All new Masport Gas appliances are warranted, subject to the This Express Warranty Does Not Cover: following conditions, to be free from defects in material or 1. Defects, malfunctions or failures caused by incorrect installa- workmanship under normal use. - Page 32 Printed in Canada © Copyright 2004, FPI Fireplace Products International Ltd. All rights reserved.
