Meter Description
1. LCD Display
2. Push-buttons (UP/Picture, ESC, and DOWN/VIDEO)
3. Measurement Trigger
4. Retractable Lens Cover
5. Camera, Lasers, and IR sensor
6. Compartment for Type-K jack, USB jack, Reset button
7. Handle Grip and cover for Micro SD memory card slot and
Rechargeable Battery
Rear Panel
1
Display
2
▲ and Camera button
3
Power and ESC button
4
ENTER button
5
▼ and Video button
Front View
1
Camera lens
2
IR thermometer lens
3
Measurement trigger
4
Battery
5
Battery cover
6
Laser pointers
7
Micro SD card port
Note: A tripod mount is located on the bottom of the handle
1
2
1
2
3
1
2
3
4
5
3
5
4
3
6
7
5
4
6
7
