Description
Meter Description
1. LCD Display
2. MAX‐MIN / Down Button
3. Backlight‐Laser Pointer / Up Button
4. Laser pointer lens
5. IR Thermometer lens
6. SET Button
7. Measurement Scan Trigger
8. Battery Compartment
Display Description
Emissivity value indication
Laser pointer active icon
Scan mode (active while the trigger is pulled; displayed
temperature tracks the temperature of the scanned surfaces)
Hold mode (displayed temperature freezes with trigger release)
Maximum/Minimum temperature icons
Battery capacity indicator (flashes when battery voltage is critical)
Display Backlight icon
Temperature units (°F /°C)
Temperature Alarm icons and audible alarm disable icon
1
2
3
3
IRT25‐en‐GB_V1.0 2/17
EXTECH INSTRUMENTS
4
5
6
7
8
