Introduction
Congratulations on your purchase of the Model IR400 IR Thermometer. The IR400 is capable of
non-contact (infrared) temperature measurements at the touch of a button. The built-in laser pointer
increases target accuracy while the backlit LCD and handy pushbuttons combine for convenient,
ergonomic operation. This meter is shipped fully tested and calibrated and, with proper use, will
provide years of reliable service.
Safety
Use extreme caution when the laser pointer beam is on
•
• Do not point the beam toward anyone's eye or allow the beam
to strike the eye from a reflective surface
Do not use the laser near explosive gases or in other
•
potentially explosive areas

Meter Description

Meter Description
1. Laser pointer beam
2. IR Sensor
3. Measurement Trigger
4. Battery Compartment
5. LCD Display
6. Pushbuttons
7. Handle Grip
Display Description
1. Temperature scan in progress (trigger held)
2. Last reading held (trigger released)
3. Laser pointer ON
4. Emissivity (0.95 fixed)
5. Max or MIN value displayed
6. Temperature display
7. Low battery icon (replace battery)
8. Temperature units
